ZEUS
SR
®
INSTALLATION MANUAL
ENGLISH
www.bandg.com
Scan here
to save a copy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEUS SR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for B&G ZEUS SR Series

  • Page 1 ZEUS ® INSTALLATION MANUAL ENGLISH www.bandg.com Scan here to save a copy...
  • Page 2 Copyright ©2025 Navico Group. All Rights Reserved. Navico Group is a division of Brunswick Corporation. Trademarks Reg. U.S. Pat. & Tm. Off, and ™ common law marks. Visit www.navico.com/intellectual-property to review the global trademark rights and ® accreditations for Navico Group and other entities. •...
  • Page 3: Table Of Contents

    CONTENTS 4 In the box 5 Front controls 6 Connectors 7 Memory card reader 8 Installation 8 General mounting guidelines 9 Panel mount 10 Rear mount 10 Gimbal mount 11 Wiring 11 Wiring guidelines 11 Power and other controls 14 NMEA 2000 ®...
  • Page 4: In The Box

    IN THE BOX Display unit Dash gasket Suncover Power cable Fuse and fuse holder Documentation pack Gimbal mount kit - 10" and 12" units • 1x metal bracket • 4x #14x 1 in self-tapping pan head screws • 2x knobs ¼...
  • Page 5: Front Controls

    FRONT CONTROLS Touchscreen Home App menu Scroll wheel Exit Waypoint Power Customizable keys • 1x button on the 10” unit • 2x buttons on the 12” and 16” units Memory card door...
  • Page 6: Connectors

    CONNECTORS 10" unit 12" and 16" units Ethernet (5-pin, yellow connector) Ethernet (X-Coded M12 connector) USB connector - video out Video input NMEA 2000 (Micro-C connector) ® Power and other controls (4-pin connector) Earth-ground connection point (M4 x 0.7) Notes: ¼...
  • Page 7: Memory Card Reader

    Memory card reader A microSD card can be used to: ® • Provide detailed charts • Update software • Transfer user data (waypoints, routes, tracks, and screenshots). Notes: ¼ • If a microSD card and USB storage device are both inserted, by default, data and screenshots ®...
  • Page 8: Installation

    INSTALLATION General mounting guidelines Choose a mounting location that will not expose the unit to conditions that exceed the technical specifications. ⚠ WARNING: Do not install the unit in a hazardous/flammable atmosphere. Always wear appropriate eye wear, ear protection and dust mask when drilling, cutting, or sanding. Remember to check the reverse side of all surfaces whenever drilling or cutting.
  • Page 9: Panel Mount

    Wi-Fi ® It is important to test the Wi-Fi performance at your chosen location before you install the unit. ® It is important to keep your country setting up to date. Go to Settings > Preferences > Country to change the unit’s country setting. Construction material (steel, aluminum or carbon) and heavy structures will affect Wi-Fi performance.
  • Page 10: Rear Mount

    Rear mount Apply the provided gasket (A) to the gasket channel on the display unit. Hand-tighten the four threaded studs (provided) (B) into the brass inserts on the back case, and use the provided Allen (C) key to tighten. Place the the display unit into the dash cutout, fit the rear mount brackets (D) over the studs, and secure with two thumb nuts (E) per stud, turning them clockwise.
  • Page 11: Wiring

    WIRING Wiring guidelines Unless otherwise stated, only use the supplied cable/s. If you need to use a non-supplied cable, ensure it is the correct quality, length and gauge for its intended purpose. Don’t: • Make sharp bends in the cables. •...
  • Page 12: Power And Other Controls

    Power and other controls The power connector is used for power, power control and an external alarm. Power connector details DC negative Power control 12 or 24 V DC External alarm Power connection The unit is designed to be powered by 12 or 24 V DC. It is protected against reverse polarity, under voltage and over voltage (for a limited duration).
  • Page 13 Power controlled by ignition The unit will turn on when the ignition is turned on to start engines. Note: Engine start batteries and house batteries should have a common ground connection. ¼ Power control (yellow) Ignition switch Power controlled by power control bus The yellow power control wire can either be an input that will turn the unit on when power is applied, or an output that turns on other devices when the unit is powered on.
  • Page 14: External Alarm

    External alarm External alarm Connect the blue wire in the power cable to an external buzzer or siren to trigger an external alarm. External alarm output (blue) Siren and relay Buzzer Note: Use a relay for sirens that ¼ draw more than 1 A. NMEA 2000 ®...
  • Page 15: Video Input

    Video input The unit should be turned off prior to connecting or disconnecting a video cable. Note: HDCP-encrypted content is not supported. ¼ Video input cable requirements Video input signal may be compromised on long cable runs. Only use Navico Group cables or other high- quality video cables.
  • Page 16 Ethernet connector (X-Coded M12, GbE) details X-Coded M12 Gigabit Ethernet cable requirements Only use Navico Group cables or other high-quality Cat 6 SF/FTP Ethernet cables. Navico X-Coded M12 GbE cables have keyed connectors to prevent accidental damage to the connector pins.
  • Page 17: Ethernet Expansion Device

    Do not use more than one X-Coded M12 GbE to yellow 5-pin Ethernet adapter when connecting devices. Yellow 5-pin Ethernet connector X-Coded M12 GbE connector M12 GbE to yellow 5-pin adapter Yellow 5-pin Ethernet cable Ethernet connector (yellow, 5-pin) details Transmit positive TX+ Transmit negative TX- Receive positive RX+...
  • Page 18: Nmea 2000® Planning And Installation

    NMEA 2000 PLANNING AND INSTALLATION ® An NMEA 2000 network consists of a powered backbone from which drop cables connect to NMEA ® 2000 devices. The backbone typically runs from bow to stern within 6 m (20 ft) of the locations of the ®...
  • Page 19 Sample voltage drop calculation...
  • Page 20 Voltage drop estimation Left Right Minimum supply voltage 11 V DC 11 V DC (de-rated supply) 3% loss at insertion -0.33 V DC -0.33 V DC Voltage drop -0.688 V DC -0.439 V DC Voltage at the end point 9.982 V DC 10.231 V DC If the voltage at the end point is less than 9.5 V DC, you can: •...
  • Page 21: Supported Data

    SUPPORTED DATA 128267 Water Depth 128275 Distance Log NMEA 2000 PGN (receive) ® 129025 Position, Rapid Update 59392 ISO Acknowledgment 129026 COG & SOG, Rapid Update 59904 ISO Request 129029 GNSS Position Data 60160 ISO Transport Protocol, Data Transfer 129033 Time &...
  • Page 22: Nmea 2000 ® Pgn (Transmit)

    NMEA 2000 PGN (transmit) ® 130074 Route and WP Service - WP List - WP Name & Position 60160 ISO Transport Protocol, Data Transfer 130306 Wind Data 60416 ISO Transport Protocol, Connection M 130310 Environmental Parameters 126208 ISO Command Group Function 130311 Environmental Parameters 126992...
  • Page 23: Optional Accessories

    OPTIONAL ACCESSORIES 000-16461-001 USB to video out female adapter 000-16448-001 M12 GbE to yellow 5-pin male adapter 000-16458-001 16" gimbal bracket For a complete list of compatible accessories, visit www.bandg.com.
  • Page 24: Dimensions

    DIMENSIONS 10" unit 197.27 mm (7.76 in) 176.11 mm (6.93 in)
  • Page 25: 12" Unit

    12" unit 232.82 mm (9.16 in) 208.35 mm (8.20 in)
  • Page 26: 16" Unit

    16" unit 266.42 mm (10.48 in) 241.55 mm (9.51 in)
  • Page 27: Technical Specifications

    TECHNICAL SPECIFICATIONS Display 10″ 12″ 16″ 1280 x 800 1280 x 800 1920 x 1080 Resolution (px) >1200 nits Brightness Touchscreen Full touchscreen (multi-touch) 80° top/bottom, 80° left/right (typical value at contrast ratio = 10) Viewing angles in degrees Electrical 12/24 V DC (10 - 31.2 V DC min - max) Supply voltage Fuse rating...
