ENGLISH
• Hold the drill firmly with two hands to control its twisting
action.
• DO NOT CLICK THE TRIGGER OF A STALLED DRILL
OFF AND ON IN AN ATTEMPT TO START IT. DAMAGE
TO THE DRILL CAN RESULT.
• Minimize stalling on breakthrough by reducing pressure
and slowly drilling through the last part of the hole.
• Keep the motor running while pulling the bit out of a drilled
hole. This will help reduce jamming.
• Make sure switch turns drill on and off.
Drilling in wood
Holes in wood can be made with the same twist drill bits used
for metal or with spade bits. These bits should be sharp and
should be pulled out frequently when drilling to clear chips
from the flutes.
Drilling in metal
Use a cutting lubricant when drilling metals. The exceptions
are cast iron and brass which should be drilled dry. The cutting
lubricants that work best are sulfurized cutting oil or lard oil.
Drilling in masonry
For drilling in masonry, set the collar (3) to the hammer drilling
position by aligning the symbol with the marking. Slide the
speed selector (5) towards the front of the tool (2nd gear).
SCREWDRIVING
• Always use the correct type and size of screwdriver bit.
• If screws are difficult to tighten, try applying a small
amount of washing liquid or soap as a lubricant.
• Always hold the tool and screwdriver bit in a straight line
with the screw

Troubleshooting

Problem Possible cause
Unit will not start. Battery pack not
charged.
Battery pack will Charger not
not charge. plugged in.
Surrounding air
temperature too
hot or too cold.
10
(Original instructions)
Possible solution
Check battery pack
charging requirements
Plug charger into a
working outlet.
Move charger and
battery pack to a
surrounding air
temperature of above
40 degrees F (45ºC) or
below 105 degrees F
(+40.5ºC)
(Übersetzung der ursprünglichen
Anweisungen)
Problem Possible cause
Unit shuts off Battery pack has
abruptly. reached its maxi-
mum thermal limit.
Out of charge. (To
maximize the life
of the battery pack
it is designed to
shutoff abruptly
when the charge is
depleted

MAINTENANCE

Your BLACK+DECKER tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
 WARNING! Before performing any maintenance on the
tool, remove the battery from the tool. Unplug the charger
before cleaning it.
• Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
• Regularly clean the motor housing using a damp cloth.
• Do not use any abrasive or solvent-based cleaner.
• Regularly open the chuck and tap it to remove any dust
from the interior.

Protecting the Environment

Products/batteries are recyclable, but if marked with the
crossed-out bin, they must not be disposed of with normal
household waste.
Run the batteries down completely and separate them, and
separate any light sources from the product if possible. It
is the user's responsibility to delete personal data from the
product. Then take the waste to an official waste collection
centre or a participating retailer who will often accept it free of
charge. Packaging should be discarded based on the marked
material code. Operating and safety instructions should only
be discarded once the applicable product is no longer in use.
Please check with your local community/municipality for
waste management guidance. For further information, visit
www.2helpU.com and scan the above QR code.
Technical Data
Voltage
No-load speed
DEUTSCH
Possible solution
Allow battery pack to
cool down.
Place on charger
and allow to charge.
BLD683 Type 1
V 18
DC
Min-1 0–450 / 0–1800
