- Page 1 MAXHUB Speakerphone Model: UC BM45 Quick Start Guide V1.3...
-
Page 2: Table Of Contents
Table of Contents Package Contents ................05 II. Product Introduction ..............06 III. Connection ..................07 IV. Installation ..................10 V. Operation .................... 12 VI. Maintenance ..................15... - Page 3 Thank you for choosing MAXHUB product. To ensure that you are able to fully utilize the capabilities of the product, we ask that you please read this quick start guide carefully and thoroughly before using the device. Should you have any questions or require assistance, please do not hesitate to contact our tech- nical support team for guidance.
- Page 4 This device has a built-in lithium battery, please charge it regularly, otherwise the battery will not be able to continue to be charged and used if it is not charged for a long time. • More help For FAQs, technical support, software and user manual download, please visit: www.maxhub.com...
-
Page 5: Package Contents
I. Package Contents Please check that the following items are included in the package: UC BM45 ×1 Table Bracket ×1 Screw ×2 USB-C to USB-A Cable ×1 Ethernet Cable ×1 Power Adapter ×1 (3 m / 9.8 ft) (Cat5e, 3 m / 9.8 ft) NOTE 1. -
Page 6: Product Introduction
II. Product Introduction Front Rear Bottom No. Item No. Item Answer Button Kensingston Lock Hole Hang Up Button Microphone Volume Down Button DC In Volume Up Button RJ45 Connector to Previous BM45 Mute Button RJ45 Connector to Next BM45 Speaker USB Type-C Interface... -
Page 7: Connection
3 UC BM45 speakerphones, with an ideal distance of 4.5 m (15 ft) between each speakerphone unit. USB-A to USB-C cable Ethernet cable Next Previous device device DC In NOTE Please ensure that the DC adaptor is connected to the first UC BM45, even if only one UC BM45 is connected to the PC. - Page 8 Step 1: Connect the first and the fourth UC BM45 speakerphones to the power supply with power cables. Step 2: Use an USB-A to USB-C cable to connect the first UC BM45 speakerphone to the room PC. Step 3: Use Ethernet cables to connect the first UC BM45 speakerphone to the other UC BM45 speakerphones via the "Next device (RJ45 Out)"...
- Page 9 Option 3: Connect to the MAXHUB XBoard V7 (Daisy Chain) Step 1: Use an Ethernet cable to connect the first UC BM45 speakerphone to the LAN port of the MAXHUB XBoard V7. Step 2: Use Ethernet cables to connect the first UC BM45 speakerphone to the other UC BM45 speakerphones via the "Next device (RJ45 Out)"...
-
Page 10: Installation
IV. Installation For UC BM45 speakerphone, you can put it on the tabletop directly or fix it to the tabletop with the bracket provided. Before installation, make sure that all devices you need are properly connected. Please follow the steps below to install the bracket of the speakerphone: 1. - Page 11 4. Use a 1/4”-20 outer diameter screw to secure 3. Drill a hole on the corresponding tabletop, and the speakerphone to the hole on the tabletop. the recommended hole diameter is 7 mm. tabletop 7 mm tabletop NOTE The effective thread length of the bracket is 8 mm. Please prepare a 1/4-20 screw according to the thickness of the tabletop. Or you can secure it with a tripod.
-
Page 12: Operation
V. Operation Function Description: Button Description Press to answer the call. Press and hold for two seconds to exit the conference. Press to increase or decrease the volume. Press to mute/unmute. Change the sound mode: Standard Volumne mode, Enhanced Volume mode. Press the answer button five times, then press the mute button once to switch between the two modes. -
Page 13: Status Led
Status LED: Status Indication Power on / Not connected Flashing white Connected Solid white Muted Microphone button with solid red 1. Incoming call: Answer button flashing green and hang up button with solid red. On a meeting call 2. After answering: Answer button with solid green and hang up button with solid red. -
Page 14: Firmware Upgrade
Firmware Upgrade: You can update the firmware version through the Align application. On the UC BM45 Upgrade page, you can update the firmware version via Local Upgrade and Online Upgrade. For local upgrade, you can download the firmware from the download centre of the website: https://www.maxhub.com/support/trigger-... -
Page 15: Maintenance
Hereby, Guangzhou Shirui Electronics Co., Ltd. declares that the this product is compliant with the essential requirements. The complete Declaration of Conformity may be requested through the following postal address: MAXHUB EUROPE B.V. BEURSPLEIN 37, 3011AA ROTTERDAM, NETHERLANDS This symbol, affixed to the product or its packaging, indicates that the product must not be processed with househaold waste. - Page 16 MAXHUB.Global sales@maxhub.com...
