EVO REPEL
USER GUIDE
Please read the USER GUIDE carefully and keep safe
when using the product.
This product is only for adult and not a toy.
OR07-NR01-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO REPEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FLEXTAIL EVO REPEL

  • Page 1 EVO REPEL USER GUIDE Please read the USER GUIDE carefully and keep safe when using the product. This product is only for adult and not a toy. OR07-NR01-1...
  • Page 2: Product Introduction

    PRODUCT INTRODUCTION Cooling case Heating compartment Repellent indicator light Repellen switch Charging indicator light Lighting switch/ Color temperature button Type-C port Handle Flash light Front Magnetic bottom 1/4"-20 NPT female Bottom...
  • Page 3 OPERATING INSTRUCTIONS NOTE: Please fully charge the product before first use. 1. Locate the Type-C charging port on the back of the product, connect one end of the charging cable to the Type-C port and the other end to a power source/adapt- er;...
  • Page 4 3. This product uses a waterproof Type-C port, please ensure that there is no liquid residue in the port during charging. PLACING/REPLACING MOSQUITO REPELLENT MAT(S) Placing Mosquito Repellent Mat(s) Open the cooling case, and insert one or two repellent mats into device. Heating compartment can accommodate 4 small size repellent mats or two big repellent mats.
  • Page 5 Replacing Mosquito Repellent Mat(s) Please turn off the device nad cool it down before replacing repellent mats. Then, open the cooling case, and replace old repellent mats with new ones. ACTIVATING MOSQUITO REPELLENT FUNCTION The left/right heating area in the heating compartment is controlled by the left/right repellent buttons respectively.
  • Page 6 2. Single-click to transfer to outdoor mode mosquito repellent mode. Red lighte is on. Device is heated to 165°C. Camp Outdoor Mode Mode Press Once 3. Click the left/right repellent button to turn off the left/right repellent function. Outdoor Power Mode Press Once ACTIVATING LIGHTING FUNCTION...
  • Page 7: Indicator Light

    2. When the light mode is on, single click the color temperature button to adjust color temperature from 2200k-6000k. Click to Change 3800k 3300k 2200k 6000k 4300k INDICATOR LIGHT Working Indicator Light지시등 Camp Mode Outdoor Mode Battery Indicator Light When charging, blinking indicator light indicates not fully charged, and four indicator lights on indicate complete charging.
  • Page 8 Each input/output power indicator light represents 25% of the electricity. All lights on indicates full battery, and all lights off indicates power out. Input Output -Use as -Charge for power bank repellent Input Output HOW TO PLACE & CONNECT THE BRACKET Hang...
  • Page 9 Rotate/pull out the handle for support Magnet 1/4"-20 NPT Female...
  • Page 10 Lighting running time 11h(1500lm) / 6h(3000lm) ∞165℃/1h(Camp Mode) Mosquito Repellent Heating Temperature 165℃ (Outdoor Mode) Camp Mode*1: 28h Camp Mode*2: 14h Mosquito Repellent Function Battery Life시간 Outdoor Mode*1: 15h Outdoor Mode*2: 8h EVO REPEL*1, Type-C Charging Cable*1, Package Contents User Manual*1...
  • Page 11: Storage And Transportation

    When not in use, store it in a dry and room-temperature environment. AFTER-SALES SERVICE AND WARRANTY WARRANTY PERIOD: FLEXTAIL provides a one-year warranty service from the date of purchase for customers who purchase products from authorized retailers, covering defects in materials and work-manship.
  • Page 12 Facebook: flextail Instagram: flextail_official YouTube: flextail www.flextail.com Email: service@flextailgear.com...
  • Page 13 FLEXTAIL will send you the same product within 5 natural days after receiving the product in accordance with the above return policy. STILL HAVE QUESTION?
