Ninja NEVERCLOG COLD JC151EU Manual

PARTS

Tamper
Food Tray
Feed Chute Chamber with Anti-Drip Lever
Pulp Spout
Auger
Black Filter (less pulp)
Orange Filter (lots of pulp)
Motor Base (power cord not shown)
Juice Jug
Pulp Container
Cleaning Brush

BEFORE FIRST USE

Review all warnings at the beginning of this Owner's Guide before proceeding.

warning NOTE: All attachments are BPA free and dishwasher safe.

Remove all packaging materials from the unit.
Wash parts in warm, soapy water, then thoroughly rinse and air-dry all parts.
Wipe control panel with a soft cloth. Allow it to dry completely before using.

ORDERING REPLACEMENT PARTS

To order additional parts and attachments, visit ninjakitchen.eu

FEATURES

USING THE CONTROL PANEL

START/STOP
Press once to start continuous running up to 12 minutes; press again to stop.

HOLD
If the feed chute chamber becomes blocked or ingredients are not processing, press and hold HOLD. There will be a beep and a brief pause, then the auger will rotate in the opposite direction. Release HOLD to stop. Repeat as needed. Press START/STOP to resume normal operation.

USING THE FILTERS FOR PULP CONTROL

Control the amount of pulp by choosing the appropriate filter.

LESS PULP
Use the Black filter with the finest mesh for juice with less pulp.

LOTS OF PULP

Use the Orange filter with the largest mesh for juice with lots of pulp.

warning NOTE: For best results, we recommend using the Orange (Lots of Pulp) filter when processing soft fibrous fruits like pears, berries, seeded melons, and pineapple.

To watch videos on how to use and clean the Ninja NeverClog Cold Press Juicer, scan the QR code.

USING THE JUICER

Review all warnings before proceeding.
DO NOT add frozen fruits and vegetables or ice to the unit.

warning NOTE: If the feed chute chamber becomes blocked or ingredients are not processing, press and hold REVERSE. There will be a beep and a brief pause, then the auger will rotate in the opposite direction. Release REVERSE to stop. Repeat as needed. Press START/STOP to resume normal operation.

Plug in motor base and place on a clean, dry, level surface such as a countertop or table.
Insert the auger into the feed chute chamber, then attach the desired filter onto the auger, with the metal portion of the filter on the bottom of the auger. The filter will sit loosely around the auger.
Attach the pulp spout to the feed chute chamber by installing at an angle on top of the filter, then turning counterclockwise to lock in place.

Align the metal portion of the filter with the bottom of the auger.

Install the assembled feed chute chamber on the motor base at an angle, then turn counterclockwise until it clicks into place.
Install the food tray on the top of the feed chute chamber.
Place the pulp container under the pulp spout, then place the juice jug under the anti-drip lever on the feed chute chamber.

Make sure the anti drip lever is open before juicing.
Select START/STOP, then gradually add ingredients to the feed chute. For best results, allow juicer to process each ingredient before adding more. Use the tamper to push ingredients down through the feed chute, as needed.
When juicing is complete, select START/STOP, then close the anti-drip lever.

To disassemble, press and hold the RELEASE button while turning the feed chute chamber clockwise and removing it from motor base.
Remove the pulp spout from the feed chute chamber by turning clockwise. Remove the filter and auger by gently pulling them out of the feed chute chamber.
Unplug the unit when finished. If moving the unit, grab from the bottom of the base. Refer to the Care & Maintenance section for cleaning and storage instructions.

CARE & MAINTENANCE

DO NOT attempt to clean the unit by adding water to the feed chute chamber while attached to the motor base.

CLEANING

Hand-Washing
Separate all parts and wash in warm, soapy water with a soft cloth. Thoroughly rinse and air-dry all parts.
Dishwasher
All parts, except the motor base, are top-rack dishwasher safe and should NOT be cleaned with a heated dry cycle.
Motor Base
Unplug the motor base before cleaning. Wipe with a clean, damp cloth.
Filters
If there is pulp build up on the metal portion of the filter, use a cleaning utensil or toothpick to remove the excess before washing.

STORING

For cord storage, wrap cord with hook-and-loop fastener near the back of the motor base.
DO NOT wrap the cord around the bottom of the base for storage.
When moving the unit, lift from the bottom of the motor base. Store the auger and filter assembled in the feed chute chamber with the pulp spout installed. Place the juice jug into the pulp container for easy storage.

OVERLOADING THE UNIT

This unit features a unique safety system that prevents damage to the motor and drive system should you inadvertently overload the motor. If the unit is overloaded, the motor will be temporarily disabled. Should this occur, wait 2 minutes, then press START/STOP to start the unit.

If your unit needs servicing, please call Customer Service at 1-877-646-5288. So we may better assist you, please register your product online at registeryourninja.com and have the product on hand when you call.

TROUBLESHOOTING GUIDE

To reduce the risk of shock and unintended operation, turn power off and unplug unit before troubleshooting.

The REVERSE program is not operating.

After pressing and holding REVERSE, there will be a beep and a brief pause, then the auger will rotate in the opposite direction. Release REVERSE to stop. Repeat as needed. Press START/STOP to resume normal operation.

The unit stopped working and is beeping.

The unit was overloaded with ingredients. Wait 2 minutes then press START/STOP to start the unit.

Can I juice fruit with seeds and pits in it?

No. Seeds and pits should be removed from the fruit prior to juicing. For example, remove the seeds from cherries and the pit from a plum.

Can I juice frozen fruits and vegetables or add ice?

No, do not use frozen fruit, frozen vegetables, or ice with this unit.

The unit makes a squeaking noise when I juice certain ingredients.

When the auger is breaking down fibrous ingredients like apples, celery, herbs, and leafy greens, the unit will sometimes make this noise. This is normal and not a cause for concern.

The unit is producing less juice than I anticipated based on the amount of produce I used.

With the Ninja NeverClog Cold Press Juicer, you can expect 450g of produce to yield approximately 250ml of juice.
Depending on the seasonality of ingredients, you may experience lower juice and pulp yield when using the Less Pulp Filter. If this occurs, try using the Lots of Pulp Filter.

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ ALL INSTRUCTIONS BEFORE USE
FOR HOUSEHOLD USE ONLY

	Read and review instructions for operation and use.
	Indicates the presence of a hazard that can cause personal injury, death, or substantial property damage if the warning included with this symbol is ignored.
	For indoor and household use only.

When using electrical appliances, basic safety precautions should always be followed, including the following:

To reduce the risk of injury, fire, electrical shock, or property damage, basic safety precautions must always be followed, including the following numbered warnings and subsequent instructions. Do not use appliance for other than intended use.

Read all instructions prior to using the appliance and its accessories.
Carefully observe and follow all warnings and instructions. This unit contains electrical connections and moving parts that potentially present risk to the user.
DO NOT submerge the motor base or control panel in water or other liquids.
DO NOT spray motor base or control panel with any liquid. Take inventory of all contents to ensure you have all parts needed to properly and safely operate your appliance.
Always make sure pulp spout is securely in place before motor is turned on. DO NOT unfasten parts while juicer is in operation.
Be sure to turn the appliance off after each use. Make sure the motor stops completely before disassembling.
Turn the appliance OFF, then unplug the appliance from the outlet when not in use, before assembling or disassembling parts, and before cleaning. To unplug, grasp the plug by the body and pull from the outlet. NEVER unplug by grasping and pulling the flexible cord.
Before use, wash all parts that may contact food. Follow washing instructions covered in this instruction manual.
Before each use, inspect auger for damage. If auger is bent or damage is suspected, contact SharkNinja to arrange for replacement.
DO NOT use this appliance outdoors. It is designed for indoor household use only.
This appliance has a polarized plug (one prong is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT modify the plug in any way.
DO NOT operate any appliance with a damaged cord or plug, or after the appliance malfunctions, or is dropped or damaged in any manner. This appliance has no user-serviceable parts. If damaged, contact SharkNinja for servicing.
This appliance has important markings on the plug blade. The entire supply cord is not suitable for replacement. If damaged, please contact SharkNinja for service.
Extension cords should NOT be used with this appliance.
To protect against the risk of electric shock, DO NOT submerge the appliance or allow the power cord to contact any form of liquid.
DO NOT allow the cord to hang over the edges of tables or counters. The cord may become snagged and pull the appliance off the work surface.
DO NOT allow the unit or the cord to contact hot surfaces, including stoves and other heating appliances.
ALWAYS use the appliance on a dry and level surface.
DO NOT allow children to operate this appliance or use as a toy. Close supervision is necessary when any appliance is used near children.
This appliance is NOT intended to be used by people with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
ONLY use attachments and accessories that are provided with the product or are recommended by SharkNinja. The use of attachments, including canning jars, not recommended or sold by SharkNinja may cause fire, electric shock, or injury.
DO NOT put your fingers or other objects into the juicer opening while it is in operation. If food becomes lodged in opening, use the tamper or another piece of fruit or vegetable to push it down. When this method is not possible, turn the motor off and disassemble juicer to remove the remaining food.
Keep hands, hair, and clothing out of the container when loading and operating.
During operation and handling of the appliance, avoid contact with moving parts.
DO NOT use the appliance if the rotating sieve is damaged.
DO NOT operate the appliance without the pulp container in place.
DO NOT microwave container or accessories provided with the appliance.
NEVER leave the appliance unattended while in use.
DO NOT juice hot liquids. Doing so may result in pressure buildup and steam exposure that can pose a risk of the user being burned.
NEVER operate the appliance without lids and caps in place. DO NOT attempt to defeat the interlock mechanism. Ensure attachments are properly installed before operation.
Before operation, ensure all utensils are removed from container. Failure to remove utensils can cause container to shatter and potentially result in personal injury and property damage.
DO NOT attempt to remove the feed chute chamber from the motor base while the auger is still spinning. Allow the appliance to come to a complete stop before removing attachments.
If the appliance is overloaded, the unit will temporarily disable the motor. Wait approximately 2 minutes before using again.
DO NOT juice hot ingredients.
Remove the seeds and pits from fruits such as mangoes or plums, as well as peels and tough skins from fruits such as oranges, lemons, and limes, as they could damage the unit.
DO NOT add water to the feed chute while the unit is operating to clean the unit.
DO NOT submerge the motor base or control panel in water or other liquids.
DO NOT spray motor base or control panel with any liquid.
DO NOT attempt to sharpen auger.
Turn off the appliance and unplug the motor base before cleaning.
DO NOT add frozen fruit, frozen vegetables, or ice to the juicer.
Consumers with sensitivity to pulp may wish to strain their juice as a precaution.
