- Page 1 O p e r a t i n g m a n u a l High-pressure cleaners Kränzle 2100 Read and conform safety instructions before use! - GB -...
- Page 2 Description Kränzle 2100 Ergonomically shaped handle Cable reel with 5 m cable Receptacle for gun with spray lance (during breaks) Generously dimensioned hose drum with 15 m steel braided high- pressure hose (only available for TST models) Hand crank (only available for TST...
-
Page 3: Table Of Contents
Contents Page Description ..................2 Contents ..................3 Technical data ..................5 Overview “This is what you have purchased” ........... 6 General rules ..................7 Safety precautions – accident prevention ..........8 Extremely important: Water connection – electrical connection ..... 10 Kränzle- technology ................ -
Page 4: Technical Data
Technical data... - Page 5 Kränzle 2100 Operating press. fully adjustable 30 - 100 bar Nozzle size 2503 Permissible overpressure 115 bar Water output at 1,400 r.p.m. 6,5 l/min Water inlet temperature max. 60 °C Suction height 1.5 m Hose drum Steel braided high-pressure hose...
- Page 6 This is what you have purchased Kränzle high-pressure cleaners 2100 with 10 m steel braided high-pressure hose but without hose drum NW 6 Trigger gun with safety catch, insulated handle and screw connection Dirtkiller lance with stainless steel pipe Vario-Jet lance with stainless steel pipe .
-
Page 7: General Rules
General rules Range of application Use machines for cleaning tasks with high-pressure water jet and detergents or with high-pressure water jet without detergents only. Inspections The machine must be inspected according to the “Guidelines for Liquid Spray Devices” at least once every 12 months by a qualified person, to ensure that continued safe operation is guaranteed. -
Page 8: Safety Precautions
Safety precautions Bear in mind that during cleaning tasks with a high-pressure water jet a significant recoil at the lance arises (see technical data on page 4). Apply the safety catch on the trigger gun after each use, in order to prevent unintentional spraying! Always aim the underbody lance! Bear in mind when using a curved or angled... - Page 9 Safety precautions - That`s forbidden! Never direct the water jet at people or animals! Only use power cables which are in perfect working order! Do not damage the power cable or repair it incorrectly! Never pull the high pressure hose if it has formed kinks or “nooses”! Never pull the hose over sharp edges!
-
Page 10: Please Note - Important
The following minimum quantity of water is necessary for a safe and problem-free operation of the high-pressure cleaner: Kränzle 2100 : 6,5 l/min If the metered quantity of water is too small, you have to use a different water connection, guaranteeing the necessary output. - Page 11 Connected load: Kränzle 2100 : 110-115 V ~, 50 Hz Check the line fusing and have the voltage and the available current intensity checked by an expert in case of uncertainty.
-
Page 12: Kränzle Technology
Kränzle technology Water and Cleaning System Water can be connected at mains pressure to the high pressure pump or it can be sucked directly from a storage tank. The water is then forced under pressure by the high pressure pump to the lance. The high pressure jet is formed by the nozzle at the end of the lance. -
Page 13: Motor Protecting Switch
Motor protection switch The motor is protected from overload by a motor protection switch, which cuts out the motor in the event of overload. However should the switch trip frequently, the cause of the malfunction should be located and rectified (see page 11). Replacements and inspection work should only be performed by qualified persons when the machine is disconnected from the power supply, i.e. -
Page 14: Putting Into Operation
Putting into operation Move high-pressure cleaner to the job site. The Kränzle 2100 are movable machines with sturdy trolleys ideally suited for difficult terrain and stairs. Never pull the machine if the water supply hose is still connected! Setting up – Location Neither set up or operate the machine in rooms where there is a risk of fire or explosion nor put it into puddles. - Page 15 Push on lance or Dirtkiller lance to gun. Screw together lance and gun. Push on HP hose to gun. Screw together HP hose and gun. Put HP cleaner into horizontal position. These machines must be operated in horizontal position! Unwind HP hose from hose drum without kinks and nooses.
- Page 16 Putting into operation Connect to circuit. The socket must be protected with a 16A delay action fuse on the mains side. Steplessly adjust operating pressure with handwheel. The maximum pressure is adjusted ex work. Ventilation of the machine: Pull and release the trigger several times.
-
Page 17: Direct Suction
Direct suction Due the suction capacity of its pump (up to 1.5 m suction height, max. hose length 3 m) this high-pressure cleaner can suck in water for cleaning purposes from separate containers or ponds. Prior to starting the first suction the pump resp. the suction hose has to be filled with water! Mount suction hose with suction filter (Kränzle accessories No. -
Page 18: Suction Of Detergents
Suction of detergents with detergent supply: For the Kränzle 2100 a built-in injector provides the facility to suck in detergents. By pushing the Vario-Jet nozzle to the front the machine is adjusted to low pressure and a vaccum is build up in the injector. Thus the detergent can be sucked in via the connected suction hose with filter. -
Page 19: To Shut Down The Pump / Frost Protection
09. Clean power cable and wind up 10. Clean water filter 11. Winter: store the pump in rooms above 0°C Store in a place-saving manner Due to their compact and space saving design these Kränzle-2100 cleaners can be stored practically anywhere. -
Page 20: Small Repairs
Small repairs - do it yourself! No water from the nozzle but the gauge shows full pressure: Most likely the nozzle is blocked. The pressure gauge shows full pressure, but from the nozzle comes only little water or no water at all. (Inside the pressure gauge is no water but a filling with glycol to damp the vibration of the pointer.) - Page 21 Pressure gauge shows little pressure, the water from the nozzle comes in squirts: Most likely the valves are soiled or sticky. The pressure gauge shows little pressure despite fully turned up pressure regulation. The water from the lance comes in squirts. The HP hose vibrates. (Inside the pressure gauge is no water but a filling with glycol to damp the vibration of the pointer.)
-
Page 22: Small Repairs - Do It Yourself
Small repairs - do it yourself! The pressure gauge shows full pressure although the gun has been closed. The pressure switch valve switches constantly. Possible cause no.1: Leakage Having closed th gun, the HP cleaner must shut down and the pressure gauge must show „0“... - Page 23 The pressure gauge shows full pressure although the gun has been closed. The pressure switch valve switches constantly. Possible cause no. 2: The return body is soiled or the sealing ring on the return body is defective. Unscrew pump outlet. Take out check ball and check for soiling or damage of ball or stainless steel seat inside the pump housing.
-
Page 24: Inspection Report For Hp Cleaners
Inspection report for HP cleaners HP cleaners for industrial use have to be checked by an expert every 12 months! Inspection report on annually carried out Labour Safety Inspection (UVV) according to the Guidelines for Liquid Spray Equipment. (This inspection sheet serves as proof for the completion of the retest and must be kept carefully!) Kränzle test seals: Order no. - Page 25 Inspection report for HP cleaners HP cleaners for industrial use have to be checked by an expert every 12 months! Inspection report on annually carried out Labour Safety Inspection (UVV) according to the Guidelines for Liquid Spray Equipment. (This inspection sheet serves as proof for the completion of the retest and must be kept carefully!) Kränzle test seals: Order no.
-
Page 26: Eg - Declaration Of Conformity
2005/88/EC, Art. 13, HP water spraying machines annex 3, part B, chapter 27 Sound level measured: Kränzle 2100 TS / TS T: 87 dB (A) Sound level guaranteed: Kränzle 2100 TS / TS T: 89 dB (A) Applied conformity evaluation procedures... -
Page 27: Guarantee
Guarantee The guarantee is only valid for material and manufacturing errors. Wearing does not fall within this gurantee. The instructions in our operating manual must be complied with.. The operating instructions form part of the guarantee. The Guarantee is void if other parts are used than genuine Kränzle accessory parts or genuine Kränzle spare parts. -
Page 28: Spare Parts List
Spare parts list Kränzle 2100... -
Page 29: Complete Assembly
Scheibe 40 x 6 x 1,5 (Stahl) 45.216 7 Kunststoffsenkschraube 5,0 x 20 45.421 1 Radkappe 46.011 Gummipuffer 20 x 25 48.013 17.1 Frontplatte „K 2100“ 48.002-2100 Knickschutz 48.004 Schraube 5,0 x 14 43.426 O-Ring 9,3 x 2,4 13.273 Hochdruckschlauch NW 6 10 m (TS-Geräte) 43.416... - Page 30 Spare parts list Kränzle 2100...
-
Page 31: Valve Housing
Valve housing 18mm Description Qty. Ord.-No Ventilgehäuse 42.160 3 Ventilstopfen 41.714 Ventilstopfen mit R1/4“ IG 42.026 1 Dichtstopfen M 10 x 1 43.043 Ventile (grün) für APG-Pumpe 41.715 1 O-Ring 16 x 2 13.150 O-Ring 15 x 2 41.716 Dichtstopfen R1/4” mit Bund 42.103 Ausgangsteil (TST) 40.522... - Page 32 Spare parts list Kränzle 2100 Description Qty. Ord.-No Steuerkolben kpl. mit Handrad 40.490 Rep.- Satz Druckschaltermechanik 15.009 3 Druckschalter kpl. 41.300 6 73.1 Ventilgehäuse kpl. ohne Manometer (K2100) 48.050 73.2 Ventilgehäuse kpl. ohne Manometer (K2100) 48.050 1...
-
Page 33: Unloader Valve And Pressure Switch
Unloader valve and pressure switch Description Qty. Ord.-No O-Ring 16 x 2 13.150 O-Ring 13,94 x 2,62 42.167 O-Ring 11 x 1,44 12.256 Edelstahlsitz 14.118 Sicherungsring 13.147 Edelstahlkugel 13.148 Edelstahlfeder 14.119 Verschlussschraube 14.113 Steuerkolben 14.134 Parbaks 16 mm 13.159 Parbaks 8 mm 14.123 Spanstift 14.148... - Page 34 Spare parts list Kränzle 2100...
-
Page 35: Motor
Gegenmutter für PG 13,5 44.253 Kabelverschraubung PG 11 41.419 Gegenmutter für PG 11 44.521 Lüsterklemme 3-polig 43.326 Blechschraube 2,9 x 16 43.036 Kränzle 2100: Motorgehäuse mit Stator Wechselstrom 48.019 14.1 Kabel mit Stecker (Schuko) 41.092 Kondensator 80 µF 43.505 Kondensatorhalterung 41.116 1 Schraube 5,0 x 20 43.018... -
Page 36: Transmission
Transmission Description Qty. Ord.-No Gehäuseplatte für 18 mm Plunger 41.020 2 Öldichtung 18 x 28 x 7 41.031 O-Ring Viton 88 x 2 41.021 1 Plungerfeder 41.033 Federdruckscheibe 18 mm 41.034 Plunger 18 mm 41.032 1 Sprengring 18 mm 41.035 Taumelscheibe 7,2°... - Page 37 Gun ‘Midi’ with lance Description Qty. Ord.-No Rohranschlußteil R1/4“ incl. Pos. 3, 4, 21 12.125 Scheibe 5,3 DIN9021 50.152 Abzug-Hebel kpl. 12.144 1 Rohr kunststoffumspritzt bds. R 1/4“ AG 15.004 2 Überwurfmutter ST 30 M22 x 1,5 IG 13.276 1 Außen-Sechskant-Nippel R 1/4“...
-
Page 38: Dirtkiller With Lance
Dirtkiller with lance Description Qty. Ord.-No Sprühkörper 41.520 O-Ring 6,88 x 1,68 41.521 Düsensitz 41.522 Düse 03 41.523 4 Stabilisator 41.524 O-Ring 40.016 1 Sprühstopfen 41.526 Rohr 400 mm 2x M 12 x 1 41.527 ST 30-Nippel M 22 x 1,5 / M 12 x 1 ISK 13.363 Kappe vorn für Schmutzkiller 41.528 1... -
Page 39: Wiring Diagrams
Wiring diagram Kränzle 2100, 110-115 V / 50 Hz On-Off switch with 20 Ampere overload protection Pressure switch Inlet line via 3 x 1,5 mm Pump motor 110-115 V / 50 Hz 110-115 V / 50 Hz... - Page 40 K r ä n z l e – w o r l d - w i d e : Te c h n i c a l p e r f e c t i o n , t o p d e s i g n . I .
