4 Contents of upgrade kit

The principal contents of the upgrade kits are the new CM30
display unit(s) and the new range selector switch(es), as
required by the upgrade kit that has been ordered.
Also included are all the new internal cable looms to facilitate
the new switch and new display unit, as well as a new fuse
cartridge for each CM30.
Table 1 Upgrade kit
Upgrade kit CM30
part number displays
and fuse
cartridges
3KXG004130L0100 2
3KXG004130L0200 2
3KXG004130L0300 1
3KXG004130L0400 1
Range selector Cable looms
switches
1 3KXG004068U0100
3KXG004068U0200
3KXG004069U0100
3KXG004069U0300
3KXG004064U0100
2 3KXG004068U0100
3KXG004068U0200
3KXG004069U0100
3KXG004069U0200
1 3KXG004068U0100
3KXG004069U0100
0 3KXG004068U0100
3KXG004069U0100
Cable loom description
Upper Cable Loom
Lower Cable Loom
Barrier 1 Loom
Barrier 2&3 Loom
Switch Link
Upper Cable Loom
Lower Cable Loom
Barrier 1 Loom
Barrier 2 Loom
Upper Cable Loom
Barrier 1 Loom
Upper Cable Loom
Barrier 1 Loom
