3000295.1
Please read all instructions carefully before use and
retain for future reference.
Veuillez lire attentivement ces instructions avant
utilisation et conservez-les pour pouvoir les consulter
à l'avenir.
Bitte lesen Sie die Anleitung sorgfältig und bewahren Sie
sie als Referenz auf.
Leed todas las instrucciones detenidamente antes de
usar y retened para futuras consultas.
Si prega di leggere attentamente tutte le istruzioni prima
dell'uso e conservarle per una futura consultazione.
Prosimo, da pred uporabo pazljivo preberete celotna
navodila in jih stranite za bodočo uporabo.
Protect your eyes, ears and hands.
Protégez vos yeux, vos oreilles et vos mains
Schützen Sie Ihre Augen, Ohren und Hände.
Proteja sus ojos, oídos y manos.
Proteggi occhi, orecchie e mani.
Zaščitite oči, ušesa in roke.
CAUTION Potential finger trap/pinchment points
ATTENTION Vous pourriez vous pincer/coincer les
doigts
VORSICHT Finger einklemmen/quetschen möglich
PRECAUCIÓN Posibles puntos de captura de dedos
AVVERTENZA Potenziale pericolo di intrappolamento
delle dita
POZOR Potencialna past za prste/blazinice prstov
A5P | 01
35kg/77lb
Maximum.
Maximum.
Maximal.
Máximo.
Massimo.
Maksimum.
VESA compatibility -
300 x 200
75 x 75
300 x 300
100 x 100
300 x 400
100 x 100
400 x 200
100 x 200
400 x 400
150 x 100
150 x 150
200 x 100
200 x 200
