Summary of Contents for Kontron XMC403
- Page 1 User Guide XMC403 Dual SFP+ 10 Gigabit Ethernet XMC Module User Guide, Rev. 0.92 Doc. ID 1074-3725 www.kontron.com...
- Page 2 XMC403- User Guide, Rev. 0.92 This page has been intentionally left blank // 2 www.kontron.com...
-
Page 3: Disclaimer
In cases of doubt, please contact Kontron. This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the express written permission of Kontron. -
Page 4: Intended Use
(collectively, “high risk applications”). You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at your risk. To minimize the risks associated with your products and applications, you should provide adequate design and operating safeguards. -
Page 5: Revision History
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order Terms & Conditions. Visit www.kontron.com/terms-and-conditions. For contact information, refer to the corporate offices contact information on the last page of this user guide or visit... -
Page 6: Symbols
XMC403- User Guide, Rev. 0.92 Symbols The following symbols may be used in this user guide DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. - Page 7 XMC403- User Guide, Rev. 0.92 Security This symbol indicates general information and guidelines regarding the product’s cyber security to ensure secure installation, operation, maintenance and disposal of the product within the user’s end environment. This symbol indicates general information about the product and the user guide.
-
Page 8: For Your Safety
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are requested to conform with the following guidelines. -
Page 9: Lithium Battery Precautions
General Instructions on Usage In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received from Kontron Support as a special handling instruction, will void your warranty. -
Page 10: Table Of Contents
XMC403- User Guide, Rev. 0.92 Table of Contents Disclaimer ..................................3 Intended Use ................................. 4 Revision History ................................5 Symbols ..................................6 For Your Safety ................................8 High Voltage Safety Instructions ........................... 8 Special Handling and Unpacking Instruction ......................8 Lithium Battery Precautions .......................... -
Page 11: List Of Tables
Table 10: XMC Connector J1 Signal Description ......................28 Table 11: Carrier Voltages for XMC403 ........................35 Table 12: Power Consumption - XMC403 Module with Windows Server ..............36 Table 13: Statement of Memory Volatility ........................42 List of Figures Figure 1: XMC dual SFP+ 10 Gigabit Ethernet Module .................... -
Page 12: 1/ Introduction
1/ Introduction 1.1. Module Overview The XMC403 dual SFP+ 10 Gigabit Ethernet module is an XMC mezzanine card designed for use with compliant carrier boards or CPU boards that support XMC modules with PCI Express 3.0 interconnection. The XMC403 incorporates a very flexible design that allows simple and easy integration of 10 Gigabit Ethernet functionality to any compliant system. -
Page 13: Module Diagrams
XMC403- User Guide, Rev. 0.92 1.2. Module Diagrams The following diagrams provide additional information concerning module functionality and component layout. 1.2.1. Functional Block Diagram Figure 2: XMC403 Functional Block Diagram 1.2.2. Faceplate Figure 3: XMC403 Module Faceplate 1. SFP+ port (CH B) 3. -
Page 14: Module Layout
XMC403- User Guide, Rev. 0.92 1.2.3. Module Layout Figure 4: XMC403 Module Layout (Top View) 1. SFP+ B port cage 4. SFP+ A port cage 2. SFP+ B port status LEDs 5. Dual-channel, 10 GbE Ethernet controller (Intel® X710-BM2) with heatsink 3. -
Page 15: Technical Specification
Weight 107 grams Reference Example: Kontron CP6007-SA-2.6O-64-4R-T carrier board with processor load of 23 W and SFP+ module with a maximum temperature of 70°C requires an airflow of at least 25 CFM or 43.5 m³/h at an ambient temperature of 55°C. -
Page 16: Environmental Specification
XMC403- User Guide, Rev. 0.92 1.4. Environmental Specification Table 2: XMC403 Environmental Specification Environmental Description Temperature Operating 0°C to +50 °C (32°F to 122°F) Non-operating -55°C to +85°C (-67°F to 185°F) Relative Humidity IEC 60068-2-78 93% RH at 40°C (104°F), non-condensing Altitude +4,000 m (max.) above sea level (13,000 ft.) -
Page 17: Compliance
XMC403- User Guide, Rev. 0.92 1.5. Compliance The XMC403 module plans to comply with the relevant requirements and the approximation of the laws relating to the CE Mark and the standards that are constitutional parts of the declaration. Table 3: CE Compliance CE &... -
Page 18: Related Publications
Rev 4.1 July 6, 2009 All Kontron products General Safety Instruction IPMI FRU data (Board /Product Info) only reachable on Kontron 6U CPCI boards, due to compatibly reasons. XMC slots on these Kontron 6U CPCI boards historically implemented swapped GA[0..2] address signals. // 18... -
Page 19: 2/ General Safety Instructions
Only connect the product to an external power supply providing the voltage type (AC or DC) and the input power (max. current) specified on the Kontron Product Label and meeting the requirements of the Limited Power Source (LPS) and Power Source (PS2) of UL/IEC 62368-1 . -
Page 20: Additional Safety Instructions For Dc Power Supply Circuits
Le non-respect des consignes de sécurité générales suivantes peut entraîner des blessures pour l'utilisateur et/ou des dommages pour le produit. En cas de non-respect des consignes, Kontron Europe est exonéré de la responsabilité en cas d'accident, ceci s'applique également pendant la période de garantie. -
Page 21: Electrostatic Discharge (Esd)
Seuls les accessoires d'origine approuvés par Kontron Europe peuvent être utilisés. Veuillez noter que la sécurité des opérations n'est plus possible lorsque l'une des conditions suivantes s'applique. -
Page 22: Grounding Methods
XMC403- User Guide, Rev. 0.92 2.4. Grounding Methods The following measures help to avoid electrostatic damages to the device: Cover workstations with approved antistatic material. Always wear a wrist strap connected to the workplace, as well as properly grounded tools and equipment. -
Page 23: 3/ Shipment And Unpacking
XMC403- User Guide, Rev. 0.92 3/ Shipment and Unpacking 3.1. Packaging The XMC403 module is packaged in a product specific cardboard package designed to provide adequate protection and absorb shock. 3.2. Unpacking To unpack the XMC403 module perform the following: 1. -
Page 24: 4/ Functional Description
4/ Functional Description 4.1. 10 Gigabit Ethernet Controller The XMC403 module provides one dual-channel 10 Gigabit Ethernet controller (Intel® X710-BM2) optimized to deliver high performance with the lowest power consumption including independent transmit and receive queues as well as a PCI Express 3.0 (8 GT/s) interface that maximizes the use of bursts for efficient bus usage. -
Page 25: Module Interfaces
4.3. Module Interfaces 4.3.1. SFP+ Interfaces The XMC403 module provides two 10 Gigabit Ethernet ports implemented via two SFP+ cages on the faceplate with support for SFP+ direct attach copper cables or SFP+ optical transceivers. The SFP+ uplink ports comply with the SFF-8431 Specifications for Enhanced Small Form Factor Pluggable Module SFP+. -
Page 26: Table 7: Reference Sfp+ Transceivers
XMC403- User Guide, Rev. 0.92 The two SFP+ cages on the faceplate support SFP+ Direct Attach Copper cables or SFP+ transceivers. For a list of the tested reference transceivers, refer to Table 6: Reference SFP+ Transceivers. Table 7: Reference SFP+ Transceivers... -
Page 27: Ethernet Status Leds
Link establishment with 1000Base-T SFP depends on the module’s specific implementation of Auto-Negotiation and control of the LOS signal. SFP+ transceivers are not Kontron accessories and must be purchased by the user. For a list of the reference SFP+ transceivers, refer to Table 6: Reference SFP+ Transceivers. -
Page 28: Xmc Interface
4.3.3. XMC Interface The XMC403 module is equipped with one XMC connector (J1) for connection to a carrier board with a compatible XMC connector. The XMC connector provides the high-speed signals for an x8 PCI Express 3.0 (8 GT/s) interface. -
Page 29: 5/ Installation
5.1. Hardware Installation The XMC403 module can be installed on any carrier board acting as a PCI Express root complex and compliant with the XMC PCI Express Protocol Layer Standard (ANSI/VITA 42.3-2006). -
Page 30: Installation Procedures
The following precautions must be observed before installing the XMC403 module on the carrier board to ensure proper installation and avoid damage to the XMC403 or carrier board. Take care when handling the XMC403, to ensure that neither the XMC403 nor the carrier board is physically damaged. Failure to comply with the installation instruction may damage the module or result in improper system operation. -
Page 31: Removal Procedures
XMC403 module and carrier board together to completely engage the connectors. Ensure that the XMC403 module is properly mated to the carrier board: e.g. XMC bezel flush (Figure 7, pos. 5) with the faceplate, no connector misalignment, no contact between carrier board and XMC403 module except where required. -
Page 32: Installation/Removal Of Sfp+ Transceivers
For SFP+ transceiver connection to the XMC403 module, refer to Table 6: Reference SFP+ Transceivers. When inserting the SPF+ transceiver into the SFP+ cage port do not use force as this may damage the XMC403 module. The SFP+ transceiver makes a clicking sound when locked into the XMC403 modules SFP+ cage. For further information regarding the installation and removal of the SFP+ transceivers, refer to the manufacturer’s instructions... -
Page 33: Figure 8: Sfp+ Optical Transceiver And Sfp+ Direct Attach Copper Cable
XMC403- User Guide, Rev. 0.92 Figure 8: SFP+ Optical Transceiver and SFP+ Direct Attach Copper Cable 1. Retaining clip(s) 3. SFP+ direct attach copper (DAC) cable 2. SFP+ optical transceiver // 33 www.kontron.com... -
Page 34: 6/ Configuration
XMC403- User Guide, Rev. 0.92 6/ Configuration The XMC403 module is designed for plug and play operation, and, as such, it does not have any user configurable module settings that are required for operation. For application usage of module functionality, refer to the appropriate software documentation. -
Page 35: 7/ Power Considerations
The XMC403 module is powered via the XMC connector. To power up the XMC403, the module must be installed on a carrier board. The XMC403 uses two power supplies from the XMC connector VPWR (5 VDC or 12 VDC) and 3.3V (3.3 VDC). -
Page 36: Power Consumption
The values represent the difference in power consumption between a carrier board (CP6007) in idle mode and a carrier board (CP6007) equipped with an XMC403. The XMC403 operates both ports at 10 Gbit/s in full duplex mode using a 100 m fiber optic cable. -
Page 37: 8/ Technical Support
1. Visit the RMA Information website: https://www.kontron.com/en/support/rma-information 2. Download the RMA Request sheet for Kontron Europe GmbH and fill out the form. Take care to include a short detailed description of the observed problem or failure and to include the product identification Information (Name of product, Product number and Serial number). -
Page 38: 9/ Storage And Transportation
The storage facility must meet the products environmental storage requirements as stated within this user guide. Kontron recommends keeping the original packaging material for future storage or warranty shipments. -
Page 39: 10/ Warranty
XMC403- User Guide, Rev. 0.92 10/ Warranty Due to their limited service life, parts that by their nature are subject to a particularly high degree of wear (wearing parts) are excluded from the warranty beyond that provided by law. This applies to the lithium battery, for example. -
Page 40: 11/ Disposal
Kontron recommends performing data sanitization when reusing the product in a different user environment, sending the product in for repair, disposing of the product or decommissioning the product. - Page 41 XMC403- User Guide, Rev. 0.92 General guidelines when performing data sanitization on memory devices containing data sensitive to your business and/or confidential/proprietary data: Before powering down, consider if power is required to perform data sanitization on the product’s memory devices.
-
Page 42: Statement Of Memory Volatility
XMC403- User Guide, Rev. 0.92 11.4. Statement of Memory Volatility The product’s statement of memory volatility provides the user with a detailed list of the product’s memory devices and their volatility, to enable the user to develop a suitable data sanitization plan. -
Page 43: 12/ Cyber Security
Kontron’s Security White paper. Security Measures Kontron is not aware of the final target end user environment in which the product operates. Therefore, it is not possible for Kontron to provide precise instructions for your cyber security measures. Kontron strives to provide hints for considerations for your threat analysis and to point out particular security mechanisms implemented in Kontron products. -
Page 44: Appendix: List Of Acronyms
XMC403- User Guide, Rev. 0.92 Appendix: List of Acronyms Conformitè Europëenne Cubic Feet per Minute Central Processing Unit Direct Current EEPROM Electrical Erasable Programmable Read Only Memory ElectroMagnetic compatibility ElectroStatic Discharge Federal Communications Commission Field Replaceable Unit Ground Benign Giga Bit... -
Page 45: About Kontron
User Guide About Kontron Kontron is a global leader in IoT/Embedded Computing Technology (ECT) and offers individual solutions in the areas of Internet of Things (IoT) and Industry 4.0 through a combined portfolio of hardware, software and services. With its standard and customized products based on highly reliable state-of-the-art technologies, Kontron provides secure and innovative applications for a wide variety of industries.
