R2120-DC RECHARGEABLE MOTOR
Motor Information
This motor range is for indoor use only, do not
use outdoors or in humid environments.
When a motor has no limits set it will operate in
jog mode. Once the blind's top and bottom limits
are set this will change to a continuous operation
between limit positions.
Each motor can be paired with a maximum of 10
controllers.
Please fully charge motor before first use.
Each motor in this motor range has a rechargeable
Li-ion battery with integrated charging management.
Max input voltage: 5V/2A.
An LED on the motor head will flash 8 times at the
start of operation when the battery is running low.
OPERATIING INSTRUCTIONS
Do not operate the motor when charging.
When programming the motor, the operator has a
10 second window to complete each stage. If a stage
is not carried out within the 10 second window, the
motor will automatically exit the current mode and
the motor will not be set.
Limits are saved even if the motor runs out of battery
or is powered off. Removing any or all remotes does
not remove set limits.
During the setup/programming stage the motor will
jog in operation, please do not proceed to the next
step until it has completed this function.
A motor's upper and lower limits cannot be set at the
same position.
The motor can run for a maximum of 6 minutes
continuously.
Advertisement
Table of Contents
Related Manuals for Louvolite R2120-DC
Summary of Contents for Louvolite R2120-DC
- Page 1 R2120-DC RECHARGEABLE MOTOR OPERATIING INSTRUCTIONS Motor Information This motor range is for indoor use only, do not Do not operate the motor when charging. use outdoors or in humid environments. When programming the motor, the operator has a When a motor has no limits set it will operate in 10 second window to complete each stage.
-
Page 2: Remote Layout
NOTE : The LCD remote screen displays the battery of the blind on the LEFT side and the battery of the Remote Layout remote on the RIGHT side. LCD REMOTE LED REMOTE 16 CH 1 CH & 6 CH LED INDICATOR / DISPLAY CHANNEL INDICATOR CHANNEL BUTTONS... -
Page 3: Adding Controller
Adding Controller NOTE: Pairing can not be done under group channel or 0 channel. Pairing Controller : Power on the motor and then add the controller 1) Press and hold 2) Jog x 1 3) Select Channel 4) Press PROG 5) Jog x 2 Motor Head Button... - Page 4 NOTE: Before limits are set the motor is in jog mode. When in jog mode hold UP or Jog Mode / Continuous Mode DOWN for continuous operation. Motor cannot be set to continuous mode before limits are set. Same operation is used to move between both modes 3) Press STOP 1) Press PROG Button 2) Jog x 1...
- Page 5 Remove All Limits NOTE: Motor limits should be set immediately after installation to protect the blind from damage or misuse. Removing all set limits 2) Jog x 1 6) Jog x 1 1) Press PROG Button 3) Press STOP 4) Jog x 1 5) Press PROG button NOTE: Removing controllers does not remove set limits.
-
Page 6: Sleep Mode
Soft Start/Stop NOTE: Soft Start/Stop is on as factory default. Turn Soft Stop/Start On 1) Press PROG Button 2) Jog x 1 3) Press UP button 4) Jog x 1 5) Press UP button 6) Jog x 1 Turn Soft Stop/Start Off 1) Press PROG Button 2) Jog x 1 3) Press DOWN... -
Page 7: Channel Locking
Channel Locking NOTE: For use with the 6 and 16 channel controllers. This function limits the the accessible channels on the controller. Channel Locking on 6 Channel Controller 1) Press and hold 2) Use the CHANNEL + 3) Press STOP button FAV &... -
Page 8: Smart Hub
NOTE: Enables the user to operate the motor when out of range using the hub. User must have LLOneTouch app installed. Smart Hub These steps will put the motor in the correct mode to connect to the app. See separate detailed app instructions for full connection and installation process.
