Domus TROPIX Installation Manual

TROPIX
Thank you for purchasing your new TROPIX bathroom heater, Please take the time to read and understand the instruction sheet
below. Failure to do so may void warranty.
Specifications
Voltage: 240V AC
Heat Wattage: 2150W
IP Rating: IPX2
Fascia Size: 615x315mm
Accessories: 5-Gang Rocker Wall Switch, 3M Flexible Duct, Exterior Grille.
Lumen Output
3000K 4000K 5000K
1800lm 2100lm 1900lm
Included In The Box:
• 1 x 4 in 1 Standard Bathroom Unit
• 1 x Instruction Manual
• 1 x 3M Duct
• 1 x Outlet Grille
• 1 x Cutout Template
• 1 x 5-Gang Rocker Bakelite Wall Switch
• After installation, electricians must tick off all items on the quick checklist and fill out their details towards the back of this Installation and
User Manual.
• The electric mains must be equipped with an automatic circuit breaker with a rated current not less than 10A.
Warranty Procedure*
• For online warranty bookings visit: www.domuslighting.com.au/warranty
• For technical advice call: 1300 236 687 (Monday to Friday from 9am to 5pm EST)
• *Warranty only available within Australia
THE ELECTRIC MAINS MUST BE EQUIPPED WITH AN AUTOMATIC CIRCUIT BREAKER WITH A
RATED CURRENT NOT LESS THAN 10A. MUST BE INSTALLED BY A LICENSED ELECTRICIAN.
To protect your customer's WARRANTY please refer to the Manufacturer's warranty page.
Power: 2250W
Heat Type: PTC Heating Element Air Extraction:
CRI: ≥80
Duct Size: 150mm
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia
enquiries@domuslighting.com.au | www.domuslighting.com.au
Motor Wattage: 60W
500m
Decibel Rating: ≤48dB
Cutout: 595x280mm
Phone: 1300 236 687
Installation Manual
Date: April 4, 2025 2:52 pm
Fan Size: 60W
/h Light Wattage: 25W LED
3
1
