P R O - S E R I E S
Base Cabinet
Base (Door, Solid Top, 5 Legs) - Fitting Guide
Cabinet Parts
32x 5/8"
6x 1 1/4"
18x
2x
4x
1x
5x
2x
5x
Legs
Screws
Screws
Cover
Toe Kick
Shelf
Shelf
Door
L-Brackets
Caps
Clips
Pegs
Buffers
Tools Required
Drill
Stud Finder
Jigsaw
Mallet
Screwdriver
Clamp
Spirit Level
Tape Measure
Remember to take care when unpacking. Please keep your workspace clean,
clear, and tidy when working.This will help keep all items safe from damage. Any
waste cardboard or plastic should be flattened down and placed in the trash can.
A minimum of two people will be needed to lift the cabinet.
Page 1
Advertisement
Related Manuals for Wren Kitchens PRO Base Cabinet
Summary of Contents for Wren Kitchens PRO Base Cabinet
- Page 1 P R O - S E R I E S Base Cabinet Base (Door, Solid Top, 5 Legs) - Fitting Guide Cabinet Parts 32x 5/8” 6x 1 1/4” Legs Screws Screws Cover Toe Kick Shelf Shelf Door L-Brackets Caps Clips Pegs Buffers Tools Required...
- Page 2 Removing the frontal Before installing the cabinet, remove the frontal by pulling the release catch. Place the frontal in the door safe pack along its longest length. Removing the fittings Remove all content so the cabinet is empty. All fittings should be kept on a clean, level surface, and the shelf should be placed in the door safe pack along its longest length.
- Page 3 Locating the stud Using a stud finder, locate the studs where the cabinet will be installed and mark the wall where the cabinet will sit. For help on determining the sort of wall you have, please refer to the “Room Preparation Guide.” Lifting the cabinet into place When lifting the cabinet into place, do not tilt, as this can damage the legs.
- Page 4 Drilling the cabinet and wall Drill 2 holes through both the rear top rail and the wall at the marked locations. For guidance on the appropriate wall fixing/ screws for each wall type, please consult the “Room Preparation Guide.” Once complete, lift and move the cabinet away from the wall, then drill a pilot hole at the marked positions.
- Page 5 Finding the shelf height Find where the shelf will be installed (this is down to personal preference). Then insert the shelf pegs into the pre-drilled holes. View of the inside of the cabinet Inserting the shelf into position The shelf touches the back panel when installed, if there is a gap between the back panel and shelf, then the shelf has been installed back to front, and the shelf needs to...
- Page 6 Removing the hinge cover cap Use a flathead screwdriver to remove the hinge cover cap by inserting it into the slot of the cover cap and twisting. Adjusting the hinge To adjust the hinges, use a screwdriver as required at points 1 and 2. Point 1 -Will adjust the frontals left and right.
- Page 7 Cleaning the cabinet Finally, the cabinet should be thoroughly cleaned to remove any debris that may have accumulated during the installation. Store the toe kick clips and the remaining 5/8” screws. These will be used later when attaching the toe kick. Page 7...
