O
PERATIONAL
Handling the Remote Controller
Installing/Changing the Remote Controller Batteries:
1. Remove the rear battery cover.
2. If there are already batteries installed, remove
them and insert two fresh AAA size batteries,
ensuring to pay attention to the direction
of their polarities (+/-).
3. Slide the rear battery cover of the remote
back into place.
4. Check that the remote works properly by
pressing the ON button. If on pressing the
ON button no icon appears on the display,
re-install the batteries and con rm that they
are new and have been placed in the correct
orientation.
5. e system is now ready to be controlled.

Description of the Decorative Panel

Display Panel Indicator Descriptions
• Temperature and Error Code Display: Shows the set
temperature, room temperature, and any error codes.
• Power Light: e power light will illuminate when the
machine is turned on and turn o when the machine is
shut down.
• Compressor Operation Indicator Light:
turns on when the compressor is running and turns o
when the compressor stops.
• WIFI Indicator Light: Indicates the status of the WIFI
connection. e light will ash when ready to connect
with a mobile app, and remain on continuously once
the app is successfully connected.
Display Panel Buttons and Function Descriptions
• WIFI Button: Used to enable or disable the WIFI connection.
• Urgency ON/OFF Button: Provides a way to urgently start or
shut down the machine when the remote controller is unavailable.
16
I
NSTRUCTIONS
is light
Temperature
or Error Code
Indicator
support@pdhvac.com | (800)-675-7410 | https://www.pdhvac.com/support/
Power Indicator Wi-Fi Indicator
Compressor
Operation
Indicator
Manual
Operation
Button
