MOVILED SPOT 100
User Manual – Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOVILED SPOT 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mark MOVILED SPOT 100

  • Page 1 MOVILED SPOT 100 User Manual – Version 1.0...
  • Page 2: Safety Instructions

    9. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 10. Only use attachments/accessories specified by MARK. 11. Unplug this device during lightning storms or when unused for long periods of time.
  • Page 3 To achieve these effects, MOVILED SPOT 100 incorporates a 9 color + spot wheel and another 11 fixed gobo + spot wheel, as well as an 8-sided prism with rotation. It also has a ring around the lens that integrates RGB LEDs for additional color effects.
  • Page 4: Installation

    Dimmer: 0-100% dimmer lineal. 3 facet prism with rotation INSTALLATION This product is only suitable for professional use. MOVILED SPOT 100 is designed for indoor use, it is IP20 protection class. This device should be kept dry to avoid moisture, overheating or dusty environment.
  • Page 5 Pin occupation Pin 1: Ground Pin 2: Pin - Pin 3: Pin + To connect more than one unit in a chain, please, follow this picture. The output of the first unit must provide to the next DMX input of the signal, this way it is possible to send the signal to all the devices in the chain.
  • Page 6: Advanced Use

    ADVANCED USE CONTROL PANEL MOVILED SPOT 100 allows to get configurated in different ways thanks to its panel and selection buttons. Press the MENU button (once or several times) until you get to the desired function (according to the following chart), and press ENTER to confirm your selection.
  • Page 7 IR SW EMPTY 000 - 255 COLOR WHEEL OFFSET ColeREV 000 - 255 GOBO WHEEL OFFSET GoboRev 000 - 255 PRISM OFFSET PrimREV 000 - 255 FOCUS OFFSET FousREV 000 - 255 EMPTY FRotREV MotorST 000 - 255 PAN OFFSET Pan REV 000 - 255 TILT OFFSET...
  • Page 8 OPEN 205 - 209 RANDOM PULSE (S>F) 210 - 224 OPEN 225 - 229 MACRO GUST (F>S) 230 - 244 OPEN 245 - 255 0 - 127 INDEX 127 - 129 WHITE + RED 130 - 133 134 - 136 RED + GREEN 137 - 139 GREEN...
  • Page 9 GOBO 5 SHAKE (S>F) 105 - 114 GOBO 6 SHAKE (S>F) 115 - 124 GOBO 7 SHAKE (S>F) 125 - 134 GOBO 8 SHAKE (S>F) 135 - 144 GOBO 9 SHAKE (S>F) 145 - 154 OPEN 155 - 179 CW ROTATION (F>S) 180 - 204 OPEN 205 - 214...
  • Page 10: Troubleshooting

    3- Check if the fuse is not blown, if it is, change it with one that keeps the same technical features. If once the fuse is ok the device again blown it, please, don’t change it again, contact the MARK technical service.
  • Page 11: Indicaciones De Seguridad

    9. Instale y sitúe el dispositivo con garras, abrazaderas o de forma soldada entre su base y la sujeción. 10. Únicamente utilice accesorios especificados por MARK. 11. Desenchufe el dispositivo si no va a ser utilizado en largos periodos de tiempo.
  • Page 12: Descripción General

    Para lograr estos efectos, MOVILED SPOT 100 incorpora una rueda de 9 colores+spot y otra rueda de 9 gobos fijos + spot, así como un prisma de 8 caras con rotación. Además dispone de un aro alrededor de la lente que integra LEDs RGB para efectos de color adicionales.
  • Page 13: Instalación

    MOVILED SPOT 100 se puede colocar en una superficie plana y estable o en un soporte, pero el modo de funcionamiento común es el rigging en un sistema truss. Por favor, compruebe y siga las siguientes...
  • Page 14 en el sistema, el último dispositivo de una cadena DMX debe estar equipado con una resistencia de terminación (120 Ohmios, 1/4 W). Ocupación de los pines Pin 1: Masa Pin 2: Pin - Pin 3: Pin + Para conectar más de una unidad, siga el siguiente esquema. La salida de la primera unidad se conecta a la entrada de la siguiente y así...
  • Page 15 Utilice los botones UP y DOWN para navegar entre cada función para seleccionar el valor correcto. (Pulse ENTER para confirmar la configuración). MENÚ DE CONFIGURACION En la siguiente tabla se muestran todas las opciones para configurar el MOVILED SPOT 100 en la interfaz del menú: MENÚ SUB MENÚ...
  • Page 16 CH13 000 - 255 VACÍO CH14 000 - 255 RESET CH15 000 - 255 VACÍO CH45 LCD CON 60 SEGUNDOS SALVAPANTALLA Display LCD SIN SALVAPANTALLA Tool SundHig 000 - 032 SENSIBILIDAD DE SONIDO IR SW VACÍO 000 - 255 AJUSTE DE LA RUEDA DE COLOR ColeREV 000 - 255 AJUSTE DE LA RUEDA DE GOBO...
  • Page 17 ESTROBO ALEATORIO (F>S) 110 - 124 ABIERTO 125 - 129 FADE-IN ALEATORIO (F>S) 130 - 144 ABIERTO 145 - 149 FADE-OUT ALEATORIO (F>S) 150 - 164 ABIERTO 165 - 169 RÁFAGA (F>S) 170 - 184 ABIERTO 185 - 189 RÁFAGA ALEATORIA (F>S) 190 - 204 ABIERTO 205 - 209...
  • Page 18 GOBO 6 30 - 34 GOBO 7 35 - 39 GOBO 8 40 - 44 GOBO 9 45 - 49 ABIERTO 50 - 64 GOBO 1 SACUDIDO (S>F) 65 - 74 GOBO 2 SACUDIDO (S>F) 75 - 84 GOBO 3 SACUDIDO (S>F) 85 - 94 GOBO 4 SACUDIDO (S>F) 95 - 104...
  • Page 19 MACRO AZUL + ROJO (CW S>F) 200 - 209 MACRO AZUL + VERDE (CW S>F) 210 - 219 MACRO MULTICOLOR (CW S>F) 220 - 229 CAMBIO GRADUAL DE COLOR (S>F) 230 - 239 CAMBIO DE COLOR POR SALTO (S>F) 240 - 249 FIGURA RGB RING 250 - 255 CH10...
  • Page 20 5- Si usted no puede determinar la causa de los problemas que presenta la unidad, no la desmonte o intente reparar por sí mismo ya que perderá la garantía. 6- Devuelva la unidad a servicio técnico de MARK. Si no responde el protocolo DMX Posibles problemas: Verifique que el cable de conexión DMX está...
