PN 130 – 140 – 155 – 155R
N
S
T
R
U
C
T
I
O
N
S
N
S
T
R
U
C
T
I
O
N
S
E
A
N
D
E
A
N
D
U
A
L
N
U
A
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PN 130 and is the answer not in the manual?

Questions and answers

Related Manuals for jurop PN 130

Summary of Contents for jurop PN 130

  • Page 1 PN 130 – 140 – 155 – 155R Rev. 09 04-03-2022...
  • Page 2 2022 – Jurop – Azzano Decimo (PN) Reproduction, electronic storage and dissemination, even partial, are prohibited. Jurop reserves the right to modify the products described in this manual without prior notice. Any product names mentioned herein are the trademarks of their respective owners.

  • Page 3: Table Of Contents

    Precautions when starting the system Maintenance pag. Ordinary maintenance Extraordinary maintenance Malfunctions: pag. troubleshooting Scrapping pag. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 3 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)

  • Page 4: General Warnings

    • Pump has to be fitted with its own tag reporting the following data: Model, Serial number, Year, Max speed, Max pressure. Pic. 1.1 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...

  • Page 5: Technical Data

    Pump PN155R As model PN155. In addition: • Extra air injection cooling system. • High resistant vanes. 2.1. Dimensions and arrangements Direct transmission with splined / smooth shaft [mm] PN 130 777,5 72,5 152,5 PN 140 152,5 PN 155 246,5...
  • Page 6 . 09 – INSTALLATION USE AND MAINTENANCE MANUAL PN130-140-155-155R 04-03-2022 Transmission with gearbox / with hydraulic motor [mm] PN 130 1040 72,5 152,5 PN 140 1070 152,5 PN 155 1078 152,5 PN 155 R 1078 152,5 [mm] Ø (FIX) Ø (ADJUSTABLE)

  • Page 7: Usage Limitations

    : temperature during suction : absolute pressure during delivery : temperature during delivery * Belt drive only for PN155 D and PN155R D: P2= 1,5 abs bar. 2.3. Performances Performances PN 130 PN 140 PN 155 l/min 12900 13850 15200 Air flow at free air condition m³/h...

  • Page 8: Safety And Accident Prevention

    • Please contact JUROP’s Technical dept. if necessary. machine must apply safety signals (pictograms) to warn the operator on the risk still present. These pictograms essentially refer to three categories: −...

  • Page 9: Installation

    − Properly signal the functionality of the inverter according to the position of the manual operating lever or of the pneumatic actuator or of the hydraulic one. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...

  • Page 10: Vacuum - Pressure Line

    The separator must be periodically drained from oil and condensate accumulated in the separator during the normal pump functioning. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it...

  • Page 11: Pump Mounting - Drive Connection

    Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 11 / 32 e-mail: info@jurop.it...
  • Page 12 There is no limit to the operation in vacuum. Attention: If the pump PN155 is run through a belt drive, its working pressure must not exceed 1.5 abs. PN 130 PN 140 PN 155 Max. Speed (rpm) 1350...

  • Page 13: Start Up

    (without manifold with 4-way valve and non-return vale), it is advisable to intercept the working line of the machine when it is stopped, to prevent contrary rotations until the rebalancing of the Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it...

  • Page 14: Maintenance

    • Do not run the pump with oil level under the minimum level: that may lead to dry functioning and cause serious damages. Pic. 6.1 • Tank capacity: 4l. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 14 / 32 e-mail: info@jurop.it...

  • Page 15: Extraordinary Maintenance

    Checking the gear box oil level Pic. 6.3 Pic. 6.5 • Check the level when the pump is cooled: it must almost reach the threaded port. Refill if necessary. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 15 / 32 e-mail: info@jurop.it...
  • Page 16 • Do not flip the seal ring during rotation of the shaft. Do not leave “marked” position. Otherwise, the valve may foreign objects inside the pump. work improperly. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...
  • Page 17 • ½ turn of the adjusting screw causes a variation in the flow of appr. 40 - 80 g/h, depending on using conditions. Pic. 6.12 Pic. 6.13 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 17 / 32 e-mail: info@jurop.it...

  • Page 18: Malfunctions: Troubleshooting

    Do not dispose of in the environment. Dispose of in compliance with the standards in force. Material Cast Iron Steel Alluminum Copper Bronze Rubber Vane Plastic PN 130 86 % 11 % 0.7 % 0.3 % 0.1 % 0.3 % 0.9 % 0.5 % 0.2 % PN 140...

  • Page 19: Spare Part Data Sheet Pn130 M - Pn140 M - Pn155 M - Pn155R M

    04-03-2022 PN130-140-155 DIRECT TRANSMISSION PICTURE SHOWS PN 155 SMOOTH SHAFT COD A350809410 PN 155 SPLINED SHAFT COD. A350709410 PN 130 D COD. A45… PN 140 D COD. A20… PN 155 R D COD. A36… Jurop SpA . +39 0434 636811 F .
  • Page 20 . 09 SPARE PART DATA SHEET – PN130-140-155-155R D 04-03-2022 PN 130 DIRECT TRANSMISSION Pos. Code Description Q.ty Pos. Code Description Q.ty 1401200700 OIL DRIPPER 4023115059 BEARING NJ 309 ECJ/C3-NMQ SMOOTH SH. 1521507200 ROTOR PN130 4023100046 BEARING 6309 SMOOTH SHAFT / HDR...
  • Page 21 SEAL RING 70X55X15 4022200311 O-RING 4975 4022300001 OIL FILTER 4023100046 BEARING 6309 SMOOTH SHAFT Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 21 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 22 SEAL RING 70X55X15 4022200311 O-RING 4975 4022300001 OIL FILTER 4023100046 BEARING 6309 SMOOTH SHAFT Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 22 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)

  • Page 23: Spare Part Data Sheet Pn130 D - Pn140 D - Pn155 D - Pn155R D

    . 09 SPARE PART DATA SHEET – PN130-140-155-155R M 04-03-2022 PN 130-140-155 WITH GEARBOX PICTURE SHOWS PN 155 M (540 RPM) COD. A353209410 PN 130 M COD. A45… PN 140 M COD. A20… PN 155 R M COD. A36… Jurop SpA .
  • Page 24 . 09 SPARE PART DATA SHEET – PN130-140-155-155R M 04-03-2022 PN 130 WITH GEARBOX Pos. Code Description Q.ty Pos. Code Description Q.ty 1401200700 OIL DRIPPER 4026102802 SCREW TE 8.8 M8X12 ZINC. 1521507100 ROTOR PN130 WITH GEARBOX 4026102806 SCREW TE 8.8 M8X20 ZINC.
  • Page 25 BEARING 6309 4024251000 OIL PUMP CW ROTATION 4024251500 OIL PUMP CCW ROTATION 4026101301 SCREW TE 8.8 M6X10 ZINC. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 25 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 26 BEARING 6309 4024251000 OIL PUMP CW ROTATION 4024251500 OIL PUMP CCW ROTATION 4026101301 SCREW TE 8.8 M6X10 ZINC. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 26 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)

  • Page 27: Spare Part Data Sheet Pn130 - Pn140 - Pn155 - Pn155R Fl / Hdr

    ADJUSTABLE CONVEYOR Ø100 4026102807 SCREW TE 8.8 M8X25 ZINC. 4026350706 WASHER GROWER 8 ZINC. * PN130 ONLY PN WITH HYDRAULIC MOTOR Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 27 / 32 e-mail: info@jurop.it...
  • Page 28 . 09 – SCHEDA RICAMBI PN130-140-155-155R FL / HDR 04-03-2022 Pos. Code Description Pos. Code Description PN 130 HYD 4026351506 WASHER M 10 ZINC. 1470102300 HYD JOINT 4026359001 WASHER 33,5X40X1,5 1521507200 ROTOR PN130 SMOOTH SHAFT / HYD 1610021600 FLANGIA TRASMISSIONE IDRAULICA...

  • Page 29: Spare Part Data Sheet Pn155 Sp - Pn155R Sp

    GROWER M12 4026357007 WASHER PIANA M12 4026357007 WASHER M12 1612033900 SUPPORT OILERS 1612033900 SUPPORT OILERS Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 29 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)

  • Page 30: Accessories Spare Part Data Sheet

    SCREW TCEI M8X20 GALV. 4026350505 WASHER GROWER 8 GALV. 4026351505 WASHER M8 GALV. 4027100405 PNEUMATIC ACTUATOR Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 30 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 31 WASHER GROWER 10 GALV. 4026351505 WASHER M8 GALV. 4026401101 PIN 3X12 4029602700 PROTECTION CAP Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 31 / 32 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 32 33082 Azzano Decimo, PN (Italy) Tel. +39 0434 636811 Fax. +39 0434 636812 http://www.jurop.it e-mail: info@jurop.it Jurop SpA reserves the right to modify the products described in this manual without prior notice. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it 32 / 32 Via Crosera n°...

This manual is also suitable for:

Pn 140Pn 155Pn 155r

Table of Contents
