&RQWHQWV
Parts and Controls
Definitions
Safety Precautions
Mounting the Attachment
Fitting the Harness
Adjusting Cutter Bar Angle
Applications
Lubricating Gearbox
Lubricating the Drive Shaft
Sharpening the Cutting Blades
Storing the Machine
Specifications
Printed on chlorine-free paper
1999 Andreas Stihl AG & Co, Waiblingen
0458 401 3021. M2. K9. PM. Printed in USA
+/
2
Allow only persons who understand this
2
manual to operate your hedge trimmer
3
attachment. To receive maximum
10
performance and satisfaction from your
12
STIHL hedge trimmer attachment, it is
13
important that you read and understand
13
the maintenance and safety precautions
15
before using your hedge trimmer attach-
16
ment. Contact your STIHL dealer or the
18
STIHL distributor for your area if you do
18
not understand any of the instructions in
18
this manual.
:DUQLQJ
Because a hedge trimmer is a high-
speed cutting tool with a very long reach
some special safety precautions must be
observed to reduce the risk of personal
injury. Careless or improper use may
cause serious or even fatal injury.
STIHL's philosophy is to continually
improve all of its products. As a result,
engineering changes and improve-
ments are made from time to time. If
the operating characteristics or the
appearance of your cultivator attach-
ment differs from those described in this
manual, please contact your STIHL
dealer for information and assistance.
This manual contains warnings,
operating and safety precautions for
the STIHL hedge trimmer attachment.
Pay special attention to the safety
precautions outlined on pages 3 to 10.
,PSRUWDQW ,QIRUPDWLRQ
This STIHL hedge trimmer attachment
may be mounted only to the approved
STIHL power tool models (powerhead
with shaft and handle system). For
approved models, see chapter "Moun-
ting the Hedge Trimmer".
Other combinations of the hedge
trimmer attachment and non-approved
power tools are not permitted since
they may result in accidents or serious
personal injury.
This owner's manual contains only
descriptions of procedures and
conditions in which the attachment and
power tool combination differs from the
basic power tool.
For correct operation of your hedge trim-
mer attachment and powerhead, you
must also refer to the appropriate chap-
ters of the owner's manual for the basic
power tool.
If the basic power tool model is a STIHL
HL 75 or HL 75 K, the owner's manual
for that model applies in its entirety.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Stihl HL 75
Summary of Contents for Stihl HL 75
- Page 1 Printed on chlorine-free paper If the basic power tool model is a STIHL HL 75 or HL 75 K, the owner’s manual for that model applies in its entirety. 1999 Andreas Stihl AG & Co, Waiblingen...
- Page 2 3DUWV DQG &RQWUROV 'HILQLWLRQV &XWWHU EODGHV Steel blades for cutting hedges and shrubs. &XWWHU EODGH JXDUG Covers cutter blade when cultivator is not in use. %ODGH GULYH JHDU Converts rotary motion of angle drive into reciprocating movement of cutter blades $QJOH GULYH Transmits rotary motion of drive shaft to the blade drive gear...
-
Page 3: 6Dihw\ 3Uhfdxwlrqv
Do not lend or rent your hedge trimmer :DUQLQJ without the owner’s manual. Be sure that Have your STIHL dealer show you how anyone using your hedge trimmer Prolonged use of a hedge trimmer (or to operate your hedge trimmer. Observe... - Page 4 Most STIHL power tools are available Heavy-duty, nonslip gloves improve your Therefore, to reduce the with an anti-vibration ("AV") system grip and help to protect your hands.
- Page 5 Only attachments supplied by STIHL or expressly approved by STIHL Never use a hedge trimmer that is dama- for use with the specific STIHL hedge ged or not properly maintained. When trimmer models are authorized. Although not in use, always check your hedge...
- Page 6 Select bare ground for fueling 15m (50ft) and move at least 10 feet (3 m) from the Your STIHL hedge trimmer uses an oil- fueling spot before starting the engine. gasoline mixture for fuel (see the chap- ter on "Fuel" of your owner’s manual).
- Page 7 :RUNLQJ &RQGLWLRQV :DUQLQJ When cutting the top of a taller hedge, :DUQLQJ when visibility is obstructed check back- To reduce the risk of side of the hedge frequently for injury from inhalation bystanders, animals and obstructions. of poisonous fumes, 'DQJHU operate and start your hedge trimmer only The hedge trimmer is not...
- Page 8 To reduce the risk of fire, check fuel filler cap for leaks at regular intervals. Use Always work calmly and carefully, stay Use only STIHL replacement parts for the specified spark plug and make sure alert so as not to endanger others.
- Page 9 :DUQLQJ Do not operate your hedge trimmer if the muffler is damaged, missing or mode- fied. An improperly maintained muffler will increase the risk of fire and hearing loss. Never touch a hot muffler or burn will result. If your muffler was equipped with a spark-arresting screen to reduce the risk of fire (e.g.
- Page 10 The following models are approved for use with the hedge trimmer attachment: FS 25-4*, FS 65-4*, FS 85*, FR 85, FH 75, HL 75, HL 75 K, HLR 85. 9HUVLRQ ZLWKRXW VKDIW 0RXQWLQJ WKH DWWDFKPHQW *Bike handle and loop handle •...
- Page 11 • 9HUVLRQ ZLWK VWXE VKDIW Once the end of the drive tube is Standard procedure after initial inserted beyond the slot in the installation: clamp , push it fully onto the When installing for the first time: • • shaft as far as stop. •...
- Page 12 )LWWLQJ WKH +DUQHVV • $GMXVWLQJ SRVLWLRQ RI KDQGOH RQ XQLWV 6KRXOGHU VWUDS Push stub shaft into the coupling sleeve so that lug ZLWK D ORRS KDQGOH • Put on the shoulder strap . engages the coupling sleeve. • •...
- Page 13 $GMXVWLQJ &XWWHU %DU $QJOH $SSOLFDWLRQV (adjustable version only) Do not use your hedge trimmer attachment during other people’s rest periods, i.e. lunch time, etc. 3UHSDUDWLRQV Use lopping shears to cut out thick branches first. &XWWLQJ VHTXHQFH On this version the angle of the cutter bar relative to the shaft can be adjusted If a radical cut is necessary, cut a little at to 8 positions between 0°...
- Page 14 +RUL]RQWDO FXW 9HUWLFDO FXW 9HUWLFDO FXW ZLWK DQJOHG FXWWHU EDU ZLWK DQJOHG FXWWHU EDU ZLWK VWUDLJKW FXWWHU EDU Cutting close to ground from a standing Cutting without standing directly in front Large working radius even without position, e.g. low shrubs. of the hedge, e.g.
- Page 15 /XEULFDWLQJ *HDUER[ 2YHUKHDG FXW +RUL]RQWDO FXW Use STIHL gear lubricant for hedge ZLWK DQJOHG FXWWHU EDU ZLWK VWUDLJKW FXWWHU EDU trimmers for lubrication of the blade drive gear (see "Special Accessories") Hold the hedge trimmer above your Cutting without standing directly in after every 25 hours of operation.
- Page 16 • • Unscrew the filler plug . Coat dry areas of shaft with STIHL • If no grease can be seen on the About every 50 hours of operation if gear lubricant for hedge trimmers inside of the filler plug, screw the you use your hedge trimmer daily.
- Page 17 • • Push the gearbox onto the drive Coat dry areas of shaft with STIHL tube - turn the gearbox back gear lubricant for hedge trimmers and forth as necessary until end of (see "Special Accessories"). – the drive tube can no longer be...
- Page 18 &XWWHU %ODGHV this helps prevent the carburetor It is best to have the cutting blades diaphragms sticking together. • resharpened by your STIHL dealer on Clean and inspect cutting blade. Bidirectional, • a workshop sharpener. Thoroughly clean the machine -...
