Summary of Contents for ITS Telecom EKSELANS SEKUR IP
- Page 1 USER MANUAL SEKUR IP 261021 IP ALARM KIT ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés · Barcelona (Spain) Phone: +34935839543 · info@ek.plus · www.ek.plus...
-
Page 2: Table Of Contents
SEKUR IP USER MANUAL TABLE OF CONTENTS INTRODUCTION............................................3 Alarm System Description......................................3 Important Notes for Users......................................3 About Safety............................................3 Requirements............................................4 System Status & User Authorities.................................... 4 The Outlook..............................................5 Quick Setting Up............................................. 7 Operating by App........................................... -
Page 3: Introduction
SEKUR IP USER MANUAL INTRODUCTION. Alarm System Description. Ekselans by ITS presents the new SEKUR IP alarm with WiFi/IP connection and GSM back-up. This new family appears as an important evolution of the previous GSM-1 system, adding new and very interesting functionalities. -
Page 4: Requirements
SEKUR IP USER MANUAL Requirements. • Wired/Wireless Router compatible with Wi-Fi IEEE 802.11 b/g standard. • Internet Service Provider. • Mobile Telephone SIM card (only GSM/WCDMA/LTE SIM card, not CDMA one). • iPhone or Android smartphone. • iOS version 7.0 or higher. •... -
Page 5: The Outlook
SEKUR IP USER MANUAL The Outlook. STATUS MEANING Normal Status Light ON ARM/DISARM/HOME ARM/SOS Etc. Setting Status Fast Blinking Networking Configure Rebooting Updating Errors Slow Blinking Low Battery Networking Errors Other errors ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés ·... - Page 6 SEKUR IP USER MANUAL ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés · Barcelona (Spain) Phone: +34935839543 · info@ek.plus · www.ek.plus...
-
Page 7: Quick Setting Up
SEKUR IP USER MANUAL Quick Setting Up. Install the latest App. Please search SEKUR IP in App Store or Google Play, or scan the QR code printed on the package to visit the download page directly. Prepare the Internet Networking. Make sure that the router you are using is connected to the internet with DHCP mode enabled. - Page 8 SEKUR IP USER MANUAL When the app asks you to connect to the WiFi ek_xxxxx enter the password 1234567890. NOTE: In some cases, if process can not be completed, and depending on terminal, data from telephone should be disconnected manually in order to be able to finish configuration. Check Setting.
-
Page 9: Operating By App
SEKUR IP USER MANUAL Operating by App. Introducing the Main User Interface. User Settings Device List The entry for all account Switch between all Settings: main boxes of current -Bind Devices user. Add/Remove -Phone/Email/Password main boxes. etc,. System & App Settings Real-time Status Diagram The entry for system Here shows the real-time... -
Page 10: Arming & Other Operations
SEKUR IP USER MANUAL Arming & Other Operations. • Press the buttons listed on the toolbar. • You would hear a feedback sound in App when the operation is done. • It is recommended to add SOS button by customizing the toolbar for convenience. ITS Partner O.B.S S.L ·... -
Page 11: Pairing New Accessories
SEKUR IP USER MANUAL Pairing New Accessories. Scan QR Code: Recommended Tap [Scan QR Code]. Code is printed on every accessory Follow the guideline in App, done. ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés · Barcelona (Spain) Phone: +34935839543 ·... -
Page 12: Emergency Contacts Settings
SEKUR IP USER MANUAL Emergency Contacts Settings. • All App users would be listed in Emergency Contact list automatically. • Users can add mobile phone numbers in [Other Contacts] list. • For the App users, the [Push Notification] option would be enabled by default, while the [SMS Notification] would be disabled by default. -
Page 13: Home Arm Settings
SEKUR IP USER MANUAL Home Arm Settings. • When users are at home and only want to keep some sensors working, they could turn to Home. Arm status in App. • When users tapping [Home Arm] button at the first time, the system would guide you to setup. -
Page 14: App Settings
SEKUR IP USER MANUAL App Settings. In this area, users can do following settings: • Change App Language: It supports multi-languages which can be easily switched in App immediately. • Passcode Lock: By enabling this feature, you would be asked to enter the passcode every time when App is activated from the background. -
Page 15: Share With Others
SEKUR IP USER MANUAL Share with others. The owners can easily share their devices with the family members or friends, even they have not installed the App yet. [Device Settings]-[Share Device] would generate a unique QR code which is linked to the current main box and the assigned authorities. -Users can send this QR code to others by Facebook or WhatsApp. -
Page 16: Panel Management By Gsm
SEKUR IP USER MANUAL Panel management by GSM Although this is primarily an IP alarm with GSM notification back-up, some functionality has been added via GSM in the latest versions of FW. This allows some basic handling in this mode, although both the initial pairing of the panel with App as well as configuration and addition of accessories must always be done first via LAN or Wi-Fi network. - Page 17 SEKUR IP USER MANUAL • If the panel cannot obtain the phone number of the SIM card on its own, this window will appear to enter it manually • Once the number is accepted, a window like this will appear, which is the one that will allow us to interact with the panel.
-
Page 18: How To Operate
SEKUR IP USER MANUAL How to operate: Each time an order is given from the interface, the App will direct the user to the corresponding SMS interface of the mobile phone with the SMS already created. The user will simply have to confirm the shipment. -
Page 19: Specification
SEKUR IP USER MANUAL Specification. CORE PREFERENCES ENVIROMENTAL ARM Cortex-A7 Working temp -20ºC – 60ºC ELECTRICAL PHYSICAL Auxiliary Power CC 5V 2A Installation Desktop, Wall Mounted Backup batteries Rechargeable Lithium Shell Material ABS/PC Polymer battery 2200mAh Stand-by time 8 h (fully charged) KEY FEATURES RADIO RECEIVER Total input...
