ABOVE & IN-GROUND POOL SAND FILTER
75139
7-WAY
16"
INSTALLATION AND USER'S GUIDE
DANGER
Read all safety warnings and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
75140
7-WAY
19"
75141
7-WAY
24"
75142
7-WAY
22"
75139
75140
75141
75142
Advertisement
Table of Contents
Related Manuals for XtremepowerUS 75142
Summary of Contents for XtremepowerUS 75142
- Page 1 ABOVE & IN-GROUND POOL SAND FILTER 75139 75140 75141 75142 7-WAY 7-WAY 7-WAY 7-WAY 16” 19” 24” 22” 75139 75140 75141 INSTALLATION AND USER’S GUIDE 75142 DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) PACKAGING CONTENTS VALVE FUNCTIONS PRODUCT DIMENSIONS SPECIFICATIONS INSTALLATION FILTER TANK ASSEMBLY INSTALLATION LAYOUT DIAGRAM OPERATION PRIMING THE PUMP VALVE FUNCTIONS TROUBLESHOOTING REPLACEMENT PARTS Parts Diagram DISCLAIMER Customer Service and Technical Support... -
Page 4: Important Safety Instructions
NOTE related to hazards. USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY ATTENTION INSTALLER: This manual contains vital information regarding the installation, operation, and safe use of this product. It is essential to provide this manual to the end user of the product. Failure to read and follow all instructions could lead to severe injuries. -
Page 5: General Safety
IMPORTANT SAFETY INSTRUCTIONS GENERAL SAFETY DANGER • Severe Injury or Death Risk: Improper installation or use of this sand filter can result in serious injury or death. Installers, pool operators, and pool owners must read all instructions and safety warnings before using this sand filter. -
Page 6: Overview (Product Information)
OVERVIEW (PRODUCT INFORMATION) OVERVIEW (PRODUCT INFORMATION) PACKAGING CONTENTS PARTS # PARTS # PARTS # & PARTS # 7-WAY VALVE MEDIA LATERAL MEDIA ASSEMBLY FILTER TANK WITH 1 PC(S) 8 PC(S) W/ AIR RELEASE DRAIN PLUG & BASE 1 SET(S) 1 PC(S) KL1.6 PARTS # PARTS #... -
Page 7: Product Dimensions
OVERVIEW (PRODUCT INFORMATION) PRODUCT DIMENSIONS DIMENSION # 75139 75140 75141 75142 27” 31.7” 38.8” 33.2” 24.6” 29.3” 36.4” 30.8” 31.9” 36.6” 43.7” 39” 15.8” 18.9” 18.9” 18.9” 16” 19” 24” 22” SPECIFICATIONS SKU # 75139 75140 75142 75141 16” 19”... -
Page 8: Installation
INSTALLATION INSTALLATION FILTER TANK ASSEMBLY STEP 1 PARTS # PARTS # PARTS # & PARTS #... - Page 9 INSTALLATION STEP 2 Pool Filter Media Balls (filter balls not included) PARTS # Pool Filter Media Sand REMOVE IT BEFORE (filter sand not included) INSTALL VALVE WARNING Use only POOL FILTER SAND for this step. Sand Selection and Loading Requirements: Commonly used sand: #20 (0.71MM quartz sand) Sand density: 0.1 LB / FT³...
- Page 10 INSTALLATION STEP 3 PARTS # PRESSURE GAUGE PORT PARTS # PRESSURE GAUGE PORT PLUG PARTS # PRESSURE GAUGE PORT TEFLON TAPE KL1.6 PARTS # PARTS # TEFLON TAPE PARTS #...
- Page 11 INSTALLATION STEP 4 PARTS # PARTS #...
-
Page 12: Installation Layout Diagram
INSTALLATION INSTALLATION LAYOUT DIAGRAM POOL POOL OUTLET PORT INLET PORT SWIMMING POOL TO POOL FROM PUMP TO FILTER FROM POOL POOL PUMP POOL FILTER... - Page 13 INSTALLATION STEP 1 ELECTRIC POWER SOURCE WATER FLOW VALVE STEP 2 POOL POOL OUTLET PORT INLET PORT SWIMMING POOL...
- Page 14 INSTALLATION STEP 3 WASTE WATER FILTER TANK DRAIN PORT WATER CONTROL VALVE ON EXISTING FILTER EXISTING FILTER TANK PUMP DRAIN PLUG WATER PUMP...
- Page 15 INSTALLATION STEP 4 WASTE PORT FROM PUMP TO POOL...
- Page 16 INSTALLATION INSTALLATION INSTALLATION STEP 5 POOL POOL OUTLET PORT INLET PORT SWIMMING POOL TO POOL FROM PUMP WASTE OUT KL1.6 TO FILTER FROM POOL POOL PUMP EXISTING FILTER...
- Page 17 INSTALLATION STEP 6 POOL POOL OUTLET PORT INLET PORT SWIMMING POOL WASTE OUT FROM PUMP TO POOL TO FILTER FROM POOL POOL PUMP NEW FILTER...
- Page 18 INSTALLATION STEP 7 POOL POOL OUTLET PORT INLET PORT SWIMMING POOL FROM PUMP TO POOL WASTE OUT TO FILTER FROM POOL NEW FILTER POOL PUMP...
- Page 19 INSTALLATION STEP 8 PUMP DRAIN PLUG PUMP...
-
Page 20: Operation
OPERATION PRIMING THE PUMP STEP 1 STRAINER LID NEW POOL PUMP STEP 2 WATER NEW POOL PUMP... - Page 21 OPERATION STEP 3 STRAINER LID NEW POOL PUMP STEP 4 POOL POOL OUTLET PORT INLET PORT SWIMMING POOL...
- Page 22 OPERATION STEP 5 WATER FLOW VALVE ELECTRIC POWER SOURCE...
-
Page 23: Valve Functions
OPERATION VALVE FUNCTIONS STEP 1 CAUTION Never operate the pump without water. BACKWASH (Initial Run) Use this setting to clean the filter. When the filter pressure gauge rises 5-10 PSI (0.0.34-0.69 BAR, this reading may vary depending on the pool's pump and general piping system) above the start-up clean pressure. - Page 24 OPERATION RINSE (Initial Run) This ensures that all the dirty water from backwashing is rinsed out of the filter and goes to waste, preventing possible return to the pool. • After backwashing, keep the pump off and set the valve to "RINSE" position and start the pump for about 0.5 to 1 minute.
- Page 25 OPERATION FILTER (Regular Operation) For normal filtering and regular vacuuming. • Turn off the pump. Set the valve to the "FILTRATION" position for regular pool filtration. Then, start the pump. • Occasionally check the pressure gauge to ensure pressure remains within the normal range 5-10 PSI (0.0.34-0.69 BAR), this reading may vary depending on the pool's pump and general piping system.
- Page 26 OPERATION RECIRCULATE (Move The Water Around Without Filtering) Only use the it for a short period of time when the filter is malfunctioning, there is a severe algal bloom in the water, chemicals are being added to the pool, or after the filter has been backwashed. •...
- Page 27 OPERATION WASTE (Bypass Filter Media For Direct Water Exit) It enables water to access the filter but avoids passing through the filter media, instead directing it to exit the filtration system entirely. It aids in extracting leaves, dirt, and additional debris. •...
- Page 28 OPERATION CLOSED (Shut Off The Flow To The Filter and Pool) WARNING Avoid activating the pool pump when the 7-way valve is set to CLOSED, as this could result in damaging the filter, the pump, or both. This function involves shutting the valve to prevent water from entering, offering utility in clearing the lines during the pool's opening process and during winterization to expel air through the suction lines, redirecting airflow into the pool.
- Page 29 OPERATION WINTER (For Winterizing) Separate bonding surfaces to prevent freezing damage. NOTE Clearing out all residual water will reduce the risk of freeze damage. • Setting the Valve for Winterization With the pump remaining off, set the valve to the "WINTER" position to open all ports to prevent ◦...
- Page 30 OPERATION WINTER (For Winterizing) (Continued) DANGER Before attempting any corrective actions, ensure that the pump is in the OFF position. To avoid any potential electrical hazards, wait until the remaining power in the capacitor is fully discharged before proceeding with any work on the pump. •...
-
Page 31: Troubleshooting
TROUBLESHOOTING INSTALLATION TROUBLESHOOTING DANGER Before attempting any corrective actions, ensure that the pump is in the OFF position, and the breaker supplying power to the pump is also turned OFF. To avoid any potential electrical hazards, wait until the remaining power in the capacitor is fully discharged before proceeding with any work on the pump. - Page 32 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Incorrect Voltage Check input voltage and wiring connection. Incorrect Wiring Check wiring connections. Manually check rotation of motor shaft for free Mechanical binding movement with no obstruction. Pump Hums but Ensure that the pump is properly primed before its will Not Start first use.
- Page 33 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Contact a qualified repair professional. Block off the bottom port of the skimmer to determine if pump will develop a vacuum. You should have 5”- 6” of vacuum at the strainer cover (Only your Pool dealer can confirm this with a vacuum gauge).You may be able to check by removing the skimmer basket and holding your hand over the bottom port...
- Page 34 TROUBLESHOOTING ISSUE CAUSE CORRECTIVE ACTION Air leak in suction Re-tighten using Teflon tape. (bubbles issuing from return fittings). Low Flow (Cont) Plugged, restricted, or Contact a qualified repair professional. damaged impeller. Clear blockage and replace the impeller seal. Air leak in suction piping, cavitation caused by Correct suction condition or throttle return lines, if restricted or undersized...
-
Page 35: Replacement Parts
REPLACEMENT PARTS REPLACEMENT PARTS PARTS DIAGRAM ITEM REFERENCE # DESCRIPTION 647304071000 7-WAY VALVE 647304072000 FLANGE CLAMP LARGE O-RING Φ174xΦ5.5 5431012080 47305408906 FILTER TANK FILTER TANK BASE 19” 47305009080 647304073000 DRAIN PLUG SET MEDIA ASSEMBLY W/ AIR RELEASE & LATERAL 647305472001 GAUGE MAX SCALE 60PSI/4BAR 5024002000 47304023080... -
Page 36: Disclaimer
DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
