AIS Instruction manual
ECU v1.5.3, App v0.13.1
AIS After Market Driver Monitoring System
User manual
AIS is Smart Eye's end-to-end Driver Monitoring System for fleet and aftermarket.
Using our proven, automotive-grade DMS software for high intelligence, great
flexibility, and superior performance. Increasing overall road safety for every
installation.
·
·
Smart Eye AB
Första Långgatan 28B, 413 27, Gothenburg, Sweden
smarteye.ai
Advertisement
Table of Contents
Summary of Contents for Smart Eye AIS
- Page 1 AIS After Market Driver Monitoring System User manual AIS is Smart Eye’s end-to-end Driver Monitoring System for fleet and aftermarket. Using our proven, automotive-grade DMS software for high intelligence, great flexibility, and superior performance. Increasing overall road safety for every installation.
-
Page 2: Table Of Contents
Software update ............................... 8 Event Log ................................... 8 Setting speed source ..............................9 ASSEMBLY INSTRUCTION AND INSTALLATION ..............10 Assembly .................................. 10 Install the AIS system ............................11 OPERATING INSTRUCTIONS ....................14 Features ................................... 15 7.1.1 Distraction ..................................15 7.1.2 Drowsiness .................................. -
Page 3: Safety Instructions
200mm due to potential eye damage. Do not use this product if camera, ECU or cables are damaged in any way. Smart Eye is not responsible for any faults or failure caused by installations where these instructions have not been followed. -
Page 4: Parts Overview
3 Parts overview Below parts are included in the AIS system (picture 1): Picture 1. Parts overview. Part Description Camera Coaxial cable Power cables · · Smart Eye AB Första Långgatan 28B, 413 27, Gothenburg, Sweden smarteye.ai... -
Page 5: Technical Details
Active pixels 2 MP Visual angle (vertical x horizontal) 28° x 45° Working distance 400-900mm (AMSD) / 700-1200 mm (AMLD) Frame rate 60 fps Wavelength 940 nm · · Smart Eye AB Första Långgatan 28B, 413 27, Gothenburg, Sweden smarteye.ai... -
Page 6: Maintenance
Keep the camera, ECU and harness clean by wiping with dry or damp cloth. If required, use a small amount of mild detergent. Before performing maintenance, always make sure that the power supply is off. · · Smart Eye AB Första Långgatan 28B, 413 27, Gothenburg, Sweden smarteye.ai... -
Page 7: Ais App
5 AIS app The Smart Eye AIS app supports installation, firmware updates and helps customizing the AIS system settings such as sensitivity levels, volume and warning activation speed. To access the app, contact Smart Eye. 5.1 AIS system installation The app live view function will give instant feedback if the camera is placed correct or not. -
Page 8: Software Update
5.3 Software update To update the AIS system to the latest available software version, make sure you have the latest version of the AIS mobile app by contacting Smart Eye. 1. Use the app to connect to your device via Bluetooth ©... -
Page 9: Setting Speed Source
The AIS system supports multiple sources of vehicle speed input; GNSS, calculates vehicle speed based on satellite positioning updates. CAN, the AIS system collects the vehicle speed information from the vehicle using OBD or Smart Eye UDS protocol. -
Page 10: Assembly Instruction And Installation
Correct mounting of this product ensures best functionality, durability and that Smart Eye warranty conditions are applicable. If Smart Eye installation instructions are not followed, warranty conditions are not valid. There is also risk for system failure, that the warning signals are not triggered properly or warnings could be triggered without reasonable cause. -
Page 11: Install The Ais System
Enable vehicle battery connection and set vehicle ignition to on. Await green led indicator on front of camera. e) In the AIS app on your phone or tablet, navigate to the feature “Adjust camera”. (see section 5, AIS app) f) Place the camera as horizontal as possible, on a surface in front of the driver. - Page 12 (picture 3). Picture 3. Placement of camera. Make sure that the camera is not covered in any way since that could limit functionality and damage the camera. · · Smart Eye AB Första Långgatan 28B, 413 27, Gothenburg, Sweden smarteye.ai...
- Page 13 If needed, fixate the cables to avoid any tear or damage to the cables and to make sure there will be no interference from driver or passengers. The AIS is now installed. The system has an automated calibration functionality, activated at a speed on or above 50 km/h, and does not require any user interference.
-
Page 14: Operating Instructions
The camera unit is equipped with speakers and led lights which alerts with sound signals, voice messages and light signals when making the driver aware that a warning has been initiated (picture 5). Picture 5. Camera overview. · · Smart Eye AB Första Långgatan 28B, 413 27, Gothenburg, Sweden smarteye.ai... -
Page 15: Features
“road target”, the driver is considered to have his or her eyes on the road. If the driver is looking outside of that road target area for too long, the AIS system will issue a distraction warning. -
Page 16: Notifications
(notifications explained in picture 6 below). Picture 6. warning notifications guide. If the AIS reacts to several behaviors at the same time, it will give notification of the highest priority warning. If the driver aborts the dangerous behavior before the voice playback is initiated, the system will cancel the remaining sound playback. -
Page 17: System Error
7.3 System error If the system indicates “System Error”, use the information provided in the AIS app for information and troubleshooting (picture 7). The notification will be turned off automatically when source of error is eliminated. If the system error cannot be eliminated, contact Smart Eye service. -
Page 18: Gps
Note that when starting up the AIS system for the first time, the GPS will require some additional time for initial calibration. If the GPS is unable to determine the vehicle's speed due to a delay in acquiring a signal, no warnings will be given. -
Page 19: Disposal Of Electrical Products
To prevent possible harm to the environment or human health from uncontrolled waste disposal, always dispose electrical items responsibly at an official municipal waste and recycling site. 9 Service Contact Smart Eye AB Front desk: +46 31 60 61 60 info@smarteye.se Manuals and FAQ https://smarteye.se ·...
