WilTec 65310 Operation Manual

3-in-1 flat vacuum cleaner

Advertisement

Quick Links

Operation Manual
3-in-1 Flat Vacuum Cleaner
65310–65319
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 65310 and is the answer not in the manual?

Questions and answers

Summary of Contents for WilTec 65310

  • Page 1 Operation Manual 3-in-1 Flat Vacuum Cleaner 65310–65319 Illustration similar, may vary depending on model Read and follow the operating instructions and safety information before using for the first time. Technical changes reserved! Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
  • Page 2 All rights re- served. The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this operating manual, nor in the diagrams and figures shown.
  • Page 3 Submerge pump at a slight angle This symbol indicates that the pump must be submerged into the water at a slight angle to allow the remaining air to escape. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 3 http://www.wiltec.de...
  • Page 4 Never insert any objects or limbs into the device. • This device is not a toy! Keep it away from children and animals. Do not leave the device unat- tended during operation. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 4 http://www.wiltec.de...
  • Page 5 The device must not be used for aggressive, abrasive, caustic, combustible, or explosive pump- ing media, e.g.: Brine or sandy water Food Cleaning agents Fuels (e.g., petrol, diesel) Oils Greases Petroleum Nitro-cellulose thinner Wastewater from toilets and urinal installations © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 5 http://www.wiltec.de 07 2024-1...
  • Page 6 The illustrations in this operating manual feature the device by way of example. Some using or operating functions are similar or the same, but some appearance details will differ from the real device. Fig.1 Fig. 2 © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 6 http://www.wiltec.de...
  • Page 7 When the device is not being used, observe the following storage conditions: • Store in a dry place protected from frost and heat. • Store in an upright position, protected from dust and direct sunlight. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 7 http://www.wiltec.de 07 2024-1...
  • Page 8 Note that the conveying capacity decreases with the increasing length of the water discharge line. Hose Line If necessary, you can cut the reducer (7) to the desired diameter. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 8 http://www.wiltec.de...
  • Page 9 Fig. 6 Fig. 7 Pipe connection Screw the pipe, if possible, directly into the connection with 1½″ internal thread (6) or use a suitable adapter (see Fig. 7). © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 9 http://www.wiltec.de 07 2024-1...
  • Page 10 When using the device in bodies of water with natural, muddy ground, set the device up at a slightly elevated position, e.g., on bricks. • Check whether the hose or pipe is properly connected. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 10 http://www.wiltec.de...
  • Page 11 (see Fig. 12, Position a). • The device will switch off as soon as the float switch (4) reaches the set or minimum switch-off height (see Fig. 12, Position b). © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 11 http://www.wiltec.de...
  • Page 12 2. Pull the device out if necessary, using the nylon cord. 3. Clean the device according to the "Maintenance" chapter. 4. Store the device according to the "Storage" chapter. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 12 http://www.wiltec.de...
  • Page 13 The device might have overheated and the thermal protection circuit is activated. In this case, wait for about 10 minutes before restarting the device. If the device does not start, have the electrics checked by a specialist company. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 13 http://www.wiltec.de...
  • Page 14 Check whether the hose line is kinked or blocked. Remove kinks and/or blockages. Note! Wait at least 3 minutes after maintenance and repair work before switching the device back on. © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 14 http://www.wiltec.de...
  • Page 15 Clean the bottom of the pump as well as the impeller with a jet of water. • Reattach the cover panel to the device. Fig. 16 Fig. 17 © by WilTec Wildanger Technik GmbH Item 65310–65319 Page 15 http://www.wiltec.de 07 2024-1...
  • Page 16 This logo indicates that this electric equipment must not be disposed with the domestic waste. The company WilTec Technik GmbH has been registered in the German registry EAR under the WEEE- registration number DE45283704. Disposal of used electrical and electronic appliances...
