Lika ROTAPULS A50 Series Manual

ROTAPULS
Incremental encoder
A50
Series
• Small size hollow shaft encoder
• Ideally suited for motor feedback applications
• Extended standard operating temperature from -40°C to
100°C
• Universal output circuit: 5–30 VDC Push-Pull (Totem Pole)
or NPN/PNP open collector (HTL), or Line Driver (TTL)
• Quadrature output signals with index (ABZ, /ABZ)
ENVIRONMENTAL SPECIFICATIONS
Shock:
Vibrations:
Protection:
Operating temperature range:
Storage temperature range:
Dimensions:
Hollow shaft diameter:
Shaft loading (axial, radial):
Shaft rotational speed:
Starting torque (at 20°C):
Bearings life:
Electrical connections:
Weight:
Resolution (PPR):
Counting frequency:
Output circuits:
Power supply:
Consumption:
Output current (each channel):
Protection:
EMC:
Flange:
Housing:
Bearings:
Shaft:
