Denlar Designer Series Installation And User Manual
Hide thumbs
Also See for Designer Series:
- Service & testing manual (13 pages) ,
- Installation and user manual (25 pages)
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Denlar Designer Series
Summary of Contents for Denlar Designer Series
- Page 1 Designer Series (DS) Models Installation and User’s Manual Installation and User’s Manual Version: 2 Version: 2 MODELS: MODELS: DS-30-F DS-30-F DS-30-D DS-30-D DS-30-D-IF DS-30-D-IF (860) 526-9846 www.denlarhoods.com 10 Denlar Dr. Chester CT...
- Page 2 THIS PAGE IS INTENTIONALY BLANK Denlar Clockbox Manual...
-
Page 3: Read And Save These Instructions
Never leave surface units unattended at high DISCLAIMER settings. Boil-overs cause smoking and greasy DENLAR Fire Protection shall not be liable for errors spillovers that may ignite. Heat oils slowly on contained in this Manual or for incidental, low or medium settings. - Page 4 THIS PAGE IS INTENTIONALY BLANK Denlar Clockbox Manual...
-
Page 5: Table Of Contents
HOOD LAYOUT ....................................7 ELEVATION LAYOUT ................................... 8 MOUNTING LAYOUT ................................9-10 POWER CONNECTIONS ..............................11-12 OPERATING THE DESIGNER SERIES HOOD ......................13 MANUAL PULL STATION INSTALLATION (MPK) ....................14 ALARM CONNECTIONS ................................ 15 RANGE ELEMENT DISCONNECT INSTALLATION ....................16 RANGE ELEMENT DISCONNECT SCHEMATIC ....................17-19 HANDICAP ACCESSIBLE CONTROL (ADA) .....................20-21... -
Page 6: Hood Specifications
Material Information Coil Operating Frequency Fuse Weight Mounting Mounting Voltage Phase Fuse Type Current Material (Hz.) (AMPS) (Lbs.) Configuration Height (IN.) (AC) (AMPS) 5X20MM Surface Mount Or See Local DS-FBO 0.25 Plastic Cartidge Flush Mount Codes Denlar Designer Series Manual... -
Page 7: Hood Layout
HOOD LAYOUT Reset Button Denlar Designer Series Manual... -
Page 8: Elevation Layout
120 VAC 15-20A Circuit 120 VAC 15-20A Circuit from Main Breaker from Main Breaker (Not Provided) (Not Provided) Air Flow Air Flow 120 VAC Cable (Not Provided) 120 VAC Cable (Not Provided) Power Disconnect Power Disconnect (Provided) (Provided) Denlar Designer Series Manual... -
Page 9: Mounting Layout
MOUNTING LAYOUT A. DENLAR Designer Series Hood (DS-30) B. Range (for reference purposes (Gas, Electric or Dual Element) C. Electric Power disconnect (shown) D. Gas Power Disconnect (not shown) E. The ClockBox range element lockout system (CLBX option) The Touchscreen (E) is shown, the control module is not shown. - Page 10 There are four knockouts (KO) for the input and output power. It is recommended to use the two KO’s on the right side of the hood, next to the side cover. This allows the wiring to be installed in a more efficient manner. Top View 0.85 Rear View Denlar Designer Series Manual...
-
Page 11: Power Connections
Run a new cable (5, not provided) from the Junction Box to the ClockBox Control Box (if applicable). Wire Nut the Hot leads from the three wires (1, 3, 5) together. Wire Nut the Neutral leads from the three wires (1, 3, 5) together. Connect the grounds accordingly (1, 3, 5). Denlar Designer Series Manual... - Page 12 Connect the cable to the other end to the coil of the Power Source Disconnect (DS-E, DS-G, DS- DRD, or DS-DED). Jumper cable for the DS-DED (if applicable, not provided) Supply Line 120-220 VAC from the Main Breaker Panel to the DS-E for range (not provided). Denlar Designer Series Manual...
-
Page 13: Operating The Designer Series Hood
Fan and Light Operations The Designer Series Hood is equipped with two switches. The switch on the right is for the two lights in the Hood. The light switch is a two-position switch marked “O”, and “I” . The “O” is OFF and “I” turns the lights ON. -
Page 14: Manual Pull Station Installation (Mpk)
Insert the Wire Rope through the Compression Fitting, then through the back of the Pull Tab, and then through the Compression Fitting. Crimp the Compression Fitting. • Attach the pull face to the pull box, collecting the slack into the pull box. Denlar Designer Series Manual... -
Page 15: Alarm Connections
ALARM CONNECTIONS The Designer Series Hood offers a set of Normally Open (NO) or Normally Closed (NC) Contacts to connect to an alarm panel. To access the connection, remove the side cover, there are three red wires inserted into a Four-Position Connector, this mating connector is plugged into the Four-Position Connector. -
Page 16: Range Element Disconnect Installation
Run 120 VAC 15 – 20 Amps or 220 VAC 20 – 50 Amps based on the site requirements, from Main Breaker Panel (Not Provided) to the contactor. This will provide power to the receptacle. Secure the face plate to the electrical disconnect. Denlar Designer Series Manual... -
Page 17: Range Element Disconnect Schematic
RANGE ELEMENT DISCONNECT SCHEMATIC DS-G FIRE SUPRESSION RANGE HOODS DS-E-220 FIRE SUPRESSION RANGE HOODS Denlar Designer Series Manual... - Page 18 Note: If using a Clock Box, connect the M1 coil to the #131 and #102 of the Clock Box. LAB-110191 Part Number (see Schematic LAB-110188) ASY-200068 or ASY-300036 Rev. Date of issue FIRE SUPRESSION RANGE HOODS ASY-200212 or ASY-300037 20200207 2/7/2020 Denlar Designer Series Manual...
- Page 19 RANGE ELEMENT DISCONNECT SCHEMATIC DS-DRD-120/220 DS-FBO Denlar Designer Series Manual...
-
Page 20: Handicap Accessible Control (Ada)
11. The switch on the right of the Metal 2-Gang Enclosure with Black and White wires connected to it is for the light function. NOTE: To turn the light OFF, both the ADA toggle switch and the light switch at the Hood need to be OFF. Denlar Designer Series Manual... - Page 21 HANDICAP ACCESSIBLE CONTROL (ADA) FIRE SUPRESSION RANGE HOODS Denlar Designer Series Manual...
-
Page 22: Tank Removal
Remove Tank Assembly To remove the Designer Series Tank Assembly, a 3/8” socket or Nut Driver is required. Start by removing the Side Cover from the Hood. Inside the housing there is a Six-Position connector with three red wires, two blue wires, and one black wire;... -
Page 23: Designer Series Testing
DESIGNER SERIES TESTING Testing the Designer Series Hood Fan and Light Turn the Light Switch ON and ensure both lights turn ON. Turn the Light Switch OFF and ensure both lights turn OFF. The Fan Switch is a Three-Position rocker switch. - Page 24 If a Manual Pull Station is installed, remove the swivel hook from the glass link. Using a 3/8” socket or Nut Driver, remove the two Tank Securing Nuts. The Designer Series Tank Assembly can be removed safely at this time.
-
Page 25: Designer Series
DESIGNER SERVICE Before servicing the Designer Series Hood, install the Safety Pin for the tank to prevent an accidental discharge. Inspection: Verify that all components are clean, non-damage, and have no corrosion. Corrosion could be a sign that there is an issue with the tank. -
Page 26: Designer Series Schematic
DESIGNER SERIES SCHEMATIC Denlar Designer Series Manual... -
Page 27: Designer Series Device Flow Chart
DESIGNER SERIES DEVICE FLOW CHART Denlar Designer Series Manual... - Page 28 860-526-9846 | sales@denlarhoods.com | www.denlarhoods.com For the Warranty Statement please visit https://www.denlarhoods.com/ For installation or service calls please contact Denlar service at 860-526-9846 or at service@denlarhoods.com For sales questions, please contact Denlar Sales at 860-526-9846 or at sales@denlarhoods.com Denlar is part of a collaboration of companies that engineer and manufacture best-in-class and unique products to makets around the world.
