DESCRIPTION OF THE CONTROL PANEL WITH LCD DISPLAY

1 Signal receiver
2 Air conditioning symbol
3 Dehumidifying symbol
4 Fan symbol
5 Temperature indicator
6 Timer symbol
7 Alarm symbol
8 WATERSAVE symbol
9 Speed indicator
10 SMART symbol
11 "No water" symbol
12 BOOST symbol
13 SLEEP symbol
14 AUTOFAN indicator
15 MODE button (selects the modes)
16 FAN button
17 Increase (+) and decrease (-) tem-
perature button
18 ON/Standby button

OPERATING FROM THE CONTROL PANEL

The control panel enables you to manage all the main functions
of the appliance, but to fully exploit its potential, you must use the
remote control unit.
T
URNING THE APPLIANCE ON
• Plug the appliance into the socket.
Two lines appear on the display indicating that the appliance
is in standby (fig. 16).
• Press the ON/STANDY-BY button (18) until the appliance
comes on. The last function active when it was turned off will
appear.
✔
Never turn the air conditioner off by unplugging from the electrical outlet. Always press
the ON/STAND-BY button, then wait for a few minutes before unplugging. This allows the
appliance to perform a cycle of checks to verify operation.
2
10
11
12
13
14
15
17
8
1
3 4
18
16
5
6
7
8
9
16
