DC6TE SERIES
CONDENSING UNIT
Air Conditioning Installation
& Service Reference
Important Safety Instructions
The following symbols and labels are used throughout this
manual to indicate immediate or potential safety hazards.
It is the owner's and installer's responsibility to read
and comply with all safety information and instructions
accompanying these symbols. Failure to heed safety
information increases the risk of personal injury, property
damage, and/or product damage.
NOTE: This equipment is approved to use only with R-32
refrigerant.
Only personnel that have been trained to install, adjust,
service, maintenance or repair (hereinafter, "service")
the equipment specified in this manual should service the
equipment.
This equipment is not intended for use by persons
(including children) with reduced physical, sensory or
mental capacities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the equipment.
The manufacturer will not be responsible for any injury
or property damage arising from improper supervision,
service or service procedures. If you service this unit, you
assume responsibility for any injury or property damage
which may result. In addition, in jurisdictions that require
one or more licenses to service the equipment specified in
this manual, only licensed personnel should service the
equipment. Improper supervision, installation, adjustment,
servicing, maintenance or repair of the equipment specified
in this manual, or attempting to install, adjust, service
or repair the equipment specified in this manual without
proper supervision or training may result in product
damage, property damage, personal injury or death.
Our continuing commitment to quality products may mean a change in specifications without notice.
© 2024
IOD-1064A
08/2024
WARNING
19001 Kermier Rd. Waller, TX 77484
www.daikincomfort.com
INSTALLATION INSTRUCTIONS
Do not bypass safety devices.
HIGH VOLTAGE
Disconnect all power before servicing or
installing this unit. Multiple power sources
may be present. Failure to do so may cause
property damage, personal injury or death.
Shipping Inspection
Always keep the unit upright; laying the unit on its side
or top may cause equipment damage. Shipping damage,
and subsequent investigation is the responsibility of
the carrier. Verify the model number, specifications,
electrical characteristics, and accessories are correct
prior to installation. The distributor or manufacturer will not
accept claims from dealers for transportation damage or
installation of incorrectly shipped units.
Codes & Regulations
This product is designed and manufactured to comply
with national codes. Installation in accordance with such
codes and/or prevailing local codes/regulations is the
responsibility of the installer. This unit DC6TE090 or
DC6TE120 is a partial unit air conditioner, complying with
partial unit requirements for international standard IEC
60335-2-40, and must be only connected to other units that
have been confirmed as complying to corresponding partial
unit requirements of international standard IEC 60335-2-40.
The manufacturer assumes no responsibility for equipment
installed in violation of any codes or regulations. Rated
performance is achieved after 20 hours of operation. Rated
performance is delivered at the specified airflow. See
outdoor unit specification sheet for split system models
or product specification sheet for packaged and light
commercial models. Specification sheets can be found at
www.daikincomfort.com for Daikin brand products. Within
the website, please select the residential or commercial
products menu and then select the submenu for the type
of product to be installed, such as air conditioners or heat
pumps, to access a list of product pages that each contain
links to that model's specification sheet.
WARNING
WARNING
