Wenglor SR4E4D01S Operating Instructions Manual

Safety relay add-on module

Advertisement

Quick Links

Operating Instructions
SR4E4D01S
Safety Relay Add-on Module
EN
Translation of the original operating instructions
Subject to change without notice
Available as PDF file only
Version 2.0
www.wenglor.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR4E4D01S and is the answer not in the manual?

Questions and answers

Summary of Contents for Wenglor SR4E4D01S

  • Page 1 Operating Instructions SR4E4D01S Safety Relay Add-on Module Translation of the original operating instructions Subject to change without notice Available as PDF file only Version 2.0 www.wenglor.com...
  • Page 2: Table Of Contents

    5.4 Internal Circuit Diagram............................... 10 6 Initial Start-Up ................................11 6.1 Function Test ..................................11 7 Maintenance Instructions ............................. 12 8 Removal..................................13 9 Proper Disposal ................................14 10 Declarations of Conformity............................15 Table of Contents | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 3: Operating Instructions

    • The selection and installation of the devices, as well as the integration of their controls, require the machine manufacturer to have qualified knowledge of relevant laws and normative requirements. 1 ‒ Operating Instructions | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 4: Use For Intended Purpose

    The add-on modules for use in safety circuits are intended for installation in control cabinets. They are used to reliably evaluate the signals of a safety evaluation unit suitable for the application and their safe contact multiplication. 2 ‒ Use for Intended Purpose | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 5: Safety Precautions

    • This device is intended as an output expansion. The safety function is only achieved with connec- tion to the basic module. For this, the device must be connected according to the suggested cir- cuit. 3 ‒ Safety precautions | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 6: Technical Data

    Pluggable screw terminal Terminal tightening torque 0.6 Nm Service life 10 million switching cycles Clampable wire cross-section 0.25…2.5 mm² Connection line Rigid or flexible Vibration resistance 10…55 Hz, amplitude: 0.35 mm Shock resistance 10 g / 11 ms 4 ‒ Technical Data | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 7: Sensor Connection

    Safety Enabling Circuit 1 23-24 Safety Enabling Circuit 2 33-34 Safety Enabling Circuit 3 43-44 Safety Enabling Circuit 4 51-52 Auxiliary Contact 1 61-62 Auxiliary Contact 2 X1-X3 Feedback Circuit Housing Dimensions 4 ‒ Technical Data | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 8: Control Panel

    92 = channel 1/2 Complementary Products wenglor offers you the right connection and mounting technology as well as other accessories for your product. You can find this at www.wenglor.com on the product details page at the bottom. 4 ‒ Technical Data | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 9: Installation And Electrical Connection

    (EMC) section of DIN EN 60204-1. Connection Example • Single-channel control at terminal A1 on expansion module SR4E4D01S by means of a basic module safety release. • Terminals X1 and X2 of the expansion module must be connected to the feedback loop or single-but- ton circuit of the basic module.
  • Page 10: Internal Circuit Diagram

    Internal Circuit Diagram 23 33 43 51 24 34 44 52 5 ‒ Installation and Electrical Connection | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 11: Initial Start-Up

    The safety function of the safety relay must be tested. The following must be ensured in advance: • Tight fit • Cables must be correctly routed and connected • Check output expansion housing for damage 6 ‒ Initial Start-Up | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 12: Maintenance Instructions

    The device must be included in the regular inspections in accordance with the Industrial Safety Regu- lation (BetrSichV), however, at least 1× annually. Damaged or defective devices must be replaced. 7 ‒ Maintenance Instructions | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 13: Removal

    Removal The safety relay module may only be removed in a de-energized state. Press the bottom of the housing upward and unhook it by tilting slightly forward. 8 ‒ Removal | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 14: Proper Disposal

    Proper Disposal wenglor sensoric GmbH does not accept the return of unusable or irreparable products. Respectively valid national waste disposal regulations apply to product disposal. 9 ‒ Proper Disposal | SR4E4D01S ‒ Safety Relay Add-on Module...
  • Page 15: Declarations Of Conformity

    Declarations of Conformity Declarations of conformity can be found on our website at www.wenglor.com in the product’s separate download area. EU Konformitätserklärung EU Declaration of Conformity (DoC) Name und Anschrift des Herstellers / Name and address of manufacturer: wenglor sensoric GmbH wenglor Straße 3...
