- Page 1 Model No. DHD5000BiSRCO 5000 WATT DUAL FUEL INVERTER GENERATOR OPERATOR’S MANUAL DO NOT RETURN TO STORE! STOP HAVE QUESTIONS OR NEED SERVICE? 866-591-8921...
-
Page 2: Safety Warnings And Notices
Table of Contents Introduction Safety Warnings and Notices Thank you for choosing DieHard! This manual provides instruction on how to operate and use your generator safely and corectly; be sure to read and understand this manual before using your generator. -
Page 3: Safety Instructions
Safety Instructions Before operating your generator, you must read and understand the Operator's Manual and familiarize yourself with the safe operation practices. - Page 4 Safety Instructions CO Sentry Parallel Kit Precautions CO Sentry Indicator Lights Carbon Monoxide Safety...
-
Page 5: Names Of Components
Names of Components Left Exterior Cover Fuel Source Switch Exterior Cover Knob Wheel Propane Inlet Right Exterior Cover... -
Page 6: Control Panel
Control Panel Control Panel Features Main Switch: Manage battery power and shutdown. Tip: If you 120V AC 30A TT-30R Outlet: The outlet is capable of carrying a ① ⑥ do not use the generator for more than 120 hours, please press maximum of 30 amps. -
Page 7: Control Functions
Control Functions Fuel Source Switch Remote Control Pairing: 1. Long press the start button for 5 seconds until the green light is Gasoline - Use gasoline as a fuel for the generator. steady on. 2. Press the remote control ON or OFF, the start button turns OFF the LPG - Use Propane as a fuel for the generator. - Page 8 Control Functions Preparing Your Generator Engine Oil Fuel Tank Cap Reset If the inverter is overloaded, the reset breaker will trip. The engine will continue to run, but there will be no output from the inverter. Unplug the devices and reduce the load. Push in the reset breaker to reset it.
- Page 9 Preparing Your Generator 1.53 US gallon(5.8L)
-
Page 10: Starting The Generator
Preparing Your Generator Grounding The Generator Connecting The Battery 1. Loosen the knob on the right exterior cover and remove the right exterior cover. OPEN Starting The Generator 2. A quick-connect battery plug is pre-installed on the battery. Remove the cable tie securing the plugs, align colors, then push rmly to connect them. - Page 11 4. Move the switch to "OFF" when starting the generator. OFF Button ON Button To prevent battery drain, your Pulsar model DHD5000BiSRCO remote control feature will enter ‘sleep mode’ after 120 hours of inactivity. To reset the remote feature, simply cycle the power switch off then on again.
-
Page 12: Shutting Down The Generator
Starting The Generator LPG To Gasoline ECO Switch Parallel Operation Shutting Down The Generator Overload Indicator 1. The total load of each generator outlet should not exceed the operating power of the generator. 2. Stop the generator a. Button Stop: Press the button to turn off the generator. Low Oil Indicator... - Page 13 Shutting Down The Generator b. Remote Stop: Hold down the OFF button on the remote start key for one second. OFF Button ON Button 5. After the generator has completely cooled down, remove propane hose if applicable and store the generator in a cool, dry, sheltered storage area.
-
Page 14: Using The Generator
Using The Generator Operating Range Of The Generator Connecting Grounding Ideal Atmospheric Conditions Standard Deration: Connecting Loads To The Generator Range Of Application... -
Page 15: Service And Maintenance
Service and Maintenance... - Page 16 Service and Maintenance Adjustment Of The Carburetor Oil Change Spark Plug ① ② Loosen the knob on the right cover and remove the right cover ③ ② ① Re ll crankcase with 15 ounces (0.45L) 10w-30 engine oil; check with dipstick. Air Filter...
-
Page 17: Storage And Transport
Service and Maintenance Fuel Filter Screen Air Filter 1). Loosen the knob on the right cover ① and remove the right ② cover ② ① Storage and Transport Generator Long Term Storage 1). Turn off the generator and allow it to cool completely. -
Page 18: Troubleshooting
Storage and Transport Generator Transport Low Compression Engine Runs, No Power Output Troubleshooting Engine No-Start Insufficient Engine Oil Ignition System 1) Make sure the generator is off. -
Page 19: Technical Parameters
Technical Parameters 165F/P-1 65×48 8.5:1 4.8/4500 Electric and Manual Recoil 1.53 Gallon (5.8L) Fuel Type Unleaded Gasoline / LPG (Propane) Engine Oil Capacity 15 Ounces (0.45L) Oil Type Noise dB (@ 7m)(1/4 load) 4.0(Gasoline)/3.6(Propane) 5.0(Gasoline)/4.5(Propane) 20.9”x12.2”x19.7” 59.5lbs.(27kg) -
Page 20: Electrical Schematic
Electrical Schematic...
