The document is intended for use by end-of-life recyclers or treatment facilities. It provides
the basic instructions for the disassembly of LG products to remove components and
materials requiring selective treatment.
Product Identification
Type of Product
Model name
Displays must be stored in accordance with the requirements stipulated in Appendix VIII
(1) or (2) of Directive 2012/19/EU and must, amongst other things, be stored in a
weatherproof manner. Containers with covers must be used when storing and transporting
the Displays.
Contents
1. Materials and components for Selective Treatment
2. Tools Required
3. Product Disassembly Process
4. Disassembly of External enclosure
Dismantling information
Monitor
32GS60QC-B
This document covers derivation model
which has same conceptual design and
dismantling process
Advertisement
Related Manuals for LG 32GS60QC-B
Summary of Contents for LG 32GS60QC-B
- Page 1 Dismantling information The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of LG products to remove components and materials requiring selective treatment. Product Identification Type of Product Monitor Model name...
- Page 2 1. Materials and components for Selective Treatment Displays may contain hazardous substances like Pb and BFRs which are covered by exemptions under the RoHS directive. However, the majority is present in the PCB assembly. In order to reduce emissions as much as possible, a complete disposal of the old appliance is required. This treatment may only be performed in authorized handling plants.
-
Page 3: Tools Required
2. Tools Required List the type that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool information Screw driver Nipper Plastic Hera Jig... -
Page 4: Product Disassembly Process
3. Product Disassembly Process 1. PCBs and LCD Module Unscrew and disassemble the back cover and disconnect the key connector. Remove all the tape and wire, unscrew the screening can and remove the main board Unscrew the screws and remove the metal and middle front. - Page 5 LCD module(together with their casing) is only left after all other parts like electronic units and casing have been removed. Main Board Control Board LCD module Module PCB...
- Page 6 3. Product Disassembly Process 2. Power cord and signal cables A Power cord plugged into the back of the display can easily be removed by hand or cables are provided as de-attached from the product Adapter, DP cable 4. Capacitors > 25 mm (N/A) Capacitors >...
- Page 7 4. Disassembly of External enclosure Remove the 2ea base screws as shown in the red circle and push down the base as shown in the blue arrow to remove the base Remove the 2ea bracket screws, as shown in the red circle, turn the bracket upward, as shown in the blue arrow, and remove the bracket...
- Page 8 Remove the 4ea rear shell screws Take the disassembling knife, cut the back shell along the joint between the back shell and the front frame, and remove the back shell...
- Page 9 Take the screwdriver, remove the wall mounting screws *2ea, motherboard screws *4ea, bracket adapter screws *4ea, as shown in the red circle, remove the bracket adapter Peel off the Myra and acetate tape, as shown in the red box, and remove the wall hangings...
- Page 10 Remove the LVDS cable, button cable and backlight cable, as shown in the red box, and remove the motherboard Remove the conductive foam on the back of the mainboard, as shown in the red box...
- Page 11 Take the function key combination, break the card hook to both sides, remove the key and the key pad, and then separate the key and the key pad Remove the center frame screw *15ea, and then remove the center frame...
