- Page 1 QUICK START GUIDE EZ-USB™ FX5N Development Kit KIT_FX5N_FMC_001 Kit contents 1. EZ-USB™ FX5N DVK 3. Quick start guide (this document) 2. USB-C cable www.infineon.com/FX5N...
- Page 2 Before you start 1. Ensure that you have a PC with USB-C port that supports USB 3.2 Gen 1x2 or USB 3.2 Gen 2x2 data transfer. You can also use the kit with USB 3.2 Gen 1x1 and USB 3.2 Gen 2x1 ports.
- Page 3 KIT_FX5N_FMC_001 (top view) SWD/JTAG VDDIO header (J6) jumper (J9) Reset switch (SW3) PMODE switch (SW2) VDDIO_P0 jumper (J12) USB-C connector (J2) VBUS jumper (J1) VDDIO_CTRL jumper (J10) VDDIO_P1 jumper (J13) QSPI flash (U4, U5) EZ-USB™ FX5N (U1) Power on LED (PWRON) Page 3 of 4 Quick Start Guide...
- Page 4 KIT_FX5N_FMC_001 (bottom view) USB-C FS connector (J3) GPIO header (J5) FMC mezzanine (J8) See the kit guide available at www.infineon.com/FX5N for more details. All rights reserved. © 2025 Published by Infineon Technologies AG Document number: 002-41203 Rev. *B 81726 Munich, Germany...
