Model CS640B93
Same as model number CS640B91 except substitute the normal conduit elbow (100-7094-90)
with an Appleton enclosure (APP GRLB100-A) which has a grounding lug.
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 800-959-4464
24-hour SensorLine: 716-684-0001
Fax: 716-684-3823
E-mail: imi@pcb.com
Web: www.imi-sensors.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PCB Piezotronics IMI SENSORS CS640B93
Summary of Contents for PCB Piezotronics IMI SENSORS CS640B93
- Page 1 Same as model number CS640B91 except substitute the normal conduit elbow (100-7094-90) with an Appleton enclosure (APP GRLB100-A) which has a grounding lug. Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com...
- Page 2 Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
- Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 Model CS64XB9Y Series Industrial 4-20mA Sensor Operating Guide with Enclosed Warranty Information 3425 Walden Avenue, Depew, New York 14043-2495 Phone (716) 684-0003 Fax (716) 684-3823 Toll Free Line 1-800-959-4IMI MANUAL NUMBER: 57751 MANUAL REVISION: B ECN NUMBER: 51542...
-
Page 7: Table Of Contents
Table of Contents Introduction ........................Page 3 General Features Dimension Drawing ......................Page 4 Operation and Wiring ...................... Page 5 Standard Wiring Taking Measurements ESD Sensitivity ....................... Page 10 Warranty/Servicing Warranty, Service & Return Procedure ................Page 11 Customer Service ......................Page 12 PAGE 2... -
Page 8: Introduction
Introduction The Model CS64XB9Y Series Industrial 4-20mA Sensors combine the capabilities of a piezoelectric vibration sensor and a 4-20mA vibration transmitter. The sensor outputs a 4-20mA signal that is proportional to the overall velocity or acceleration of the machinery. Ideal for monitoring the vibration of process equipment such as fans, motors and pumps, the output of the sensor is used for process control or predictive maintenance. -
Page 9: Dimension Drawing
Dimension Drawing Inch (mm) PAGE 4... -
Page 10: Operation And Wiring
Operation and Wiring Standard Wiring The Model CS64XB9Y Series uses flying leads for all input and output connections and operate from a standard 2-wire, 4-20mA loop. Attach the positive (+) input from the power supply to the red wire and the negative (-) input from the power supply to the black wire. -
Page 11: Taking Measurements
If using a standard DC power supply, install either an ammeter and/or load resistor in line with the return connection to the black wire. The resistor will generate a DC voltage that is proportional to current by: V = IR ... -
Page 12: Esd Sensitivity
Warning 2 – ESD sensitivity This equipment is designed with user safety in mind; however, the protection provided by the equipment may be impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc. Caution 1 – ESD sensitivity Cables can kill your equipment. -
Page 13: Warranty
therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of protection may be exceeded by extremely high voltage. Warranty IMI instrumentation is warranted against defective material and workmanship for 1 year unless otherwise expressly specified. -
Page 14: Customer Service
Customer Service IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any reason, you are not completely satisfied with any IMI product, IMI will repair, replace, or exchange it at no charge. You may also choose to have your purchase price refunded. - Page 15 Model Number Revision: NR LOOP POWERED, CURRENT OUTPUT, INDUSTRIAL VIBRATION SENSOR CS640B93 ECN #: 51542 OPTION AL VERSION S Performance EN GLISH Optional versions have identical specifications and accessories as listed for the standard model except Measurement Range 0.0 to 1 in/sec pk 0.0 to 25.4 mm/s pk where noted below.
- Page 16 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. RELEASED TO DRAFTING 51542 GROUNDING LUG CAPPED ELBOW 1"...
