- Page 1 Router INSTRUCTION MANUAL Frezarka INSTRUKCJA OBSŁUGI Felsőmaró HASZNÁLATI KÉZIKÖNYV Horná fréza NÁVOD NA OBSLUHU Horní frézka NÁVOD K OBSLUZE ІНСТРУКЦІЯ З Фрезер ЕКСПЛУАТАЦІЇ Maşină de frezat verticală MANUAL DE INSTRUCŢIUNI Oberfräse BETRIEBSANLEITUNG RP1802 RP1802F RP1803 RP1803F RP2302FC RP2303FC...
- Page 2 Fig.1 Fig.5 Fig.2 Fig.6 Fig.3 Fig.7 Fig.4 Fig.8...
- Page 3 Fig.9 Fig.13 Fig.10 Fig.14 Fig.11 Fig.15 Fig.12 Fig.16...
- Page 4 Fig.17 Fig.21 Fig.18 Fig.22 Fig.19 Fig.23 Fig.20 Fig.24...
- Page 5 Fig.25 Fig.29 Fig.30 Fig.26 Fig.31 Fig.27 Fig.32 Fig.28...
- Page 6 Fig.33 Fig.37 Fig.34 Fig.38 Fig.35 Fig.39 Fig.36 Fig.40...
- Page 7 Fig.41 Fig.45 Fig.42 Fig.46 Fig.43 Fig.47 Fig.44 Fig.48...
- Page 8 Fig.49...
-
Page 9: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model: RP1802 RP1802F RP1803 RP1803F RP2302FC RP2303FC Collet chuck capacity 12 mm or 1/2″ Plunge capacity 0 - 70 mm No load speed 23,000 min 22,000 min 9,000 - 23,000 min Overall height 312 mm 327 mm Net weight 6.2 kg Safety class... -
Page 10: Ec Declaration Of Conformity
Model RP1803F Use clamps or another practical way to secure Work mode: cutting grooves in MDF and support the workpiece to a stable plat- Vibration emission (a ) : 5.1 m/s form. Holding the work by your hand or against Uncertainty (K) : 1.5 m/s the body leaves it unstable and may lead to loss of control. -
Page 11: Functional Description
Adjust the lowest adjusting hex bolt to obtain the deep- FUNCTIONAL est depth of cut, following the method of "Adjusting the depth of cut". DESCRIPTION Adjust the two remaining adjusting hex bolts to obtain shallower depths of cut. The differences in height of these adjusting hex bolts are equal to the differences in CAUTION: Always be sure that the tool is... -
Page 12: Operation
Constant speed control ASSEMBLY Only for model RP2302FC, RP2303FC Possible to get fine finish, because the rotating speed is CAUTION: Always be sure that the tool is kept constant even under the loaded condition. switched off and unplugged before carrying out any work on the tool. - Page 13 Fine adjusting function for NOTE: Moving the tool forward too fast may cause a poor quality of cut, or damage to the router bit or positioning blade in relation to motor. Moving the tool forward too slowly may burn straight guide and mar the cut.
-
Page 14: Maintenance
(D) and turn the fine be performed by Makita Authorized or Factory Service adjusting screw (1.5 mm per turn). When adjusting the Centers, always using Makita replacement parts. - Page 15 Board-jointing bit NOTE: Some items in the list may be included in the tool package as standard accessories. They may ► Fig.40 differ from country to country. Unit:mm Router bits Straight bit ► Fig.35 Corner rounding bit ► Fig.41 Unit:mm Unit:mm 1/4″...
- Page 16 Ball bearing chamfering bit ► Fig.46 Unit:mm θ 45° 1/4″ 60° Ball bearing beading bit ► Fig.47 Unit:mm Ball bearing cove beading bit ► Fig.48 Unit:mm Ball bearing roman ogee bit ► Fig.49 Unit:mm 16 ENGLISH...
