Summary of Contents for Hiland SLG6280 Series
- Page 1 Sliding gate opener SLG6280X user manual (SL18XX) A3 Sliding Gate Opener SLG6280X User Manual (with control board SL18XX)
-
Page 2: Safety Instruction
Sliding gate opener SLG6280X user manual（SL18XX）A3 Dear users, Thank you for choosing this product. Please read the manual carefully before assembling and using it. Please do not leave out the manual if you send this product to a third party. 1. - Page 3 Sliding gate opener SLG6280X user manual（SL18XX）A3 2. Packing List (standard) Picture Name Quantity Main engine Manual release key According to the model already choose Remote control Spring limit switch accessories box / Magnetic limit switch accessories box Spring limit switch block / Magnetic limit switch block Outer hexagonal bolts M8X60...
-
Page 4: Technical Parameters
Sliding gate opener SLG6280X user manual（SL18XX）A3 Packing list (Optional) Picture Name Quantity Metal rack 1m/pc Nylon rack 1m/pc Keypad（different models are optional） Flash lamp（different models are optional） （different models Photocell 1pair are optional） 3. Technical parameters SLG62802 SLG62803 Model SLG62801 SLG62804 Power supply 110VAC/50Hz... -
Page 5: Installation
Sliding gate opener SLG6280X user manual（SL18XX）A3 height Frequency 433.92 MHz 433.92 MHz 433.92 MHz 433.92 MHz Working -20° C - +70° C -20° C - +70° C -20° C - +70° C -20° C - +70° C temperature Package weight 10.10Kg 10.10Kg 10.10Kg... - Page 6 Sliding gate opener SLG6280X user manual（SL18XX）A3 Figure 2 4.2.2 Size of mounting plate 204±0.3 8× 10 Φ Figure 3 4.3 Installation procedures 4.3.1 Preparation work before installation Please ensure that the sliding gate is correctly installed, the gate rail is horizontal, and the gate can glide back and forth smoothly when moved by hands before installing the gate opener.
- Page 7 Sliding gate opener SLG6280X user manual（SL18XX）A3 Cable installation Please bury the motor & power cable and controlling cable with PVC tube, and use two PVC tubes to bury (motor & power cable) and (controlling cable) separately, so as to guarantee normal operation of the gate opener and protect the cables from damages.
- Page 8 Sliding gate opener SLG6280X user manual（SL18XX）A3 gear can be rotated easily; Figure 5 4.3.3 Gear rack installation ⚫ Fix the mounting screws to the rack. ⚫ Put the rack on the output gear, and weld the mounting screw to the gate (each screw with one solder joints firstly).
- Page 9 Sliding gate opener SLG6280X user manual（SL18XX）A3 Figure 7 Warnings · To ensure safety, install safety stop blocks on both ends of the rails to prevent the gate out of the rail. Before installing the main engine, make sure that the safety stop blocks are in place and whether it has the function of preventing the gate from moving out of the rail and out of the safety range.
- Page 10 Sliding gate opener SLG6280X user manual（SL18XX）A3 Figure 9 Magnetic limit switch - The installation site of magnetic limit switch is shown in Figure 10: Figure 10 The installation of magnetic limit switch block is shown in Figure 11: Right side mounting Left side mounting M6×18 M6×18...
-
Page 11: Control Board Wiring
Sliding gate opener SLG6280X user manual（SL18XX）A3 5. Control board wiring 5.1 The opener should be install on the left side of the sliding door because it is set as clockwise when delivery . If needs to install on the right side of the sliding door ,the DIP switch 6 should be changed into the opposite side. - Page 12 Sliding gate opener SLG6280X user manual（SL18XX）A3 DIP1 DIP2 Auto close time DIP3 DIP4 Function DIP5 Soft start function Cancel No auto close Turn on soft start function Disable soft start function DIP6 Right/left side DIP7 DIP8 installation ON or OFF can change the Single button control External limit NC switch current operating...
- Page 13 Sliding gate opener SLG6280X user manual（SL18XX）A3 7. Operational processes 7.1 Three button control process (DIP 7 at OFF position) 7.2 Single button control process (DIP 7 at ON position)
-
Page 14: Maintenance
1. remove the resistance working 2. resistance potentiometer setting too 2. reset the resistance potentiometer low or changes after long time The interpretation and ownership of this manual belong to Hiland company. Any change of the product can be without prior notice.
