Summary of Contents for Supersonic SC-3226SDVD
- Page 1 32” LED TV COMPATIBLE WITH DVD PLAYER MODEL NO.: SC-3226SDVD USER MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS Safety information CAUTION: DVD/VIDEO CD/CD PLAYER IS A CLASS 1 LASER PRODUCT. HOWEVER THIS DVD/VIDEO CD/CD PLAYER USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD/VIDEO CD/CD PLAYER CORRECTLY AS INSTRUCTED. WHEN THIS DVD/VIDEO CD/CD PLAYER IS PLUGGED TO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS PLAYER. -
Page 3: Laser Safety
Read all instructions before using Do not use this product near water. Install the product in accordance with the operating instructions. Do not set the product near heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. ... -
Page 4: Disc Handling And Maintenance
DISC Handling and Maintenance Handling precautions Hold the disc by the edges so the surface will not be soiled with fingerprints. Fingerprints, dirt and scratches can cause skipping and distortion. Do not write on the label side with a ball-point pen or other writing utensils. ... -
Page 5: Table Of Contents
TABLE OF CONTENTS GETTING STARTED IMPORTANT INSTRUCTIONS...................1-3 ACCESSORIES........................3 FEATURES..........................5 GENERAL PARTS......................6-7 REMOTE CONTROL......................8-9 REMOTE CONTROL PREPARATION.................10 BASIC CONNECTION....................11-13 OPERATIONS BASIC OPERATIONS....................14-20 DVD........................14-19 TV..........................20 LIVE TV......................21-23 CONNECTION.......................24-26 MULTI-SCREEN......................37-28 SMART FUNCTIONS.....................29-31 PICTURE AND SOUND....................32-36 CHANNEL........................37 ACCESSIBILITY......................38 SYSTEM AND SUPPORT....................39-42 FOR REFERENCE MAINTENANCE......................43 WALL MOUNTING……………………………………………………………………..……43 STAND INSTALLATION……………………………………………………………………..……44 SPECIFICATIONS.......................45... -
Page 6: Features
FEATURES 32" LED DISPLAY This player has a built-in LED display window to provide clear vision and low radiation. With Built-in DVD Player Support Auto Program Scanning Function Support Digital Broadcasting Reception Compatible with USB for Music, Photo and Video Playback (TV Mode) Support Multi-languages On Screen Display Support Full Function Remote Control Compatible with LAN, HDMI Input... -
Page 7: General Parts
GENERAL PARTS MAIN UNIT Front View Back View 1. LED display screen 2. Remote control sensor / Power indicator- In standby mode the indicator light is red; when switching on the unit the indicator will turn off. 3. Stand holder 4. - Page 8 GENERAL PARTS Back View 1. Power input (AC cord) 2. Power input (DC) 3. LAN input terminal 4. OPTICAL output terminal 5. RF input terminal- To connect the external antenna. EARPHONE output terminal 7. USB 1/2 input terminal (TV) 8. HDMI1/2/3 input terminal (Only HDMI 3 support ARC)
-
Page 9: Remote Control
REMOTE CONTROL 1 STANDBY(POWER) Set the unit in standby mode; press it again to switch it on. 2 INPUT Press to select desired input source. 3 Number buttons (0-9) Input the number information, such as channel number and so on. 4 MTS To select desired soundtrack in TV mode. - Page 10 Press to enter setup menu in DVD mode. REMOTE CONTROL (HOME) Press to enter home page. 13 VOL +/- Increase/decrease the volume level. 14 CH +/- Play the next/previous program. 15 MUTE Mute the sound. 16 LIVE TV TV source. 17 SLEEP Set desired sleep time.
-
Page 11: Remote Control Preparation
REMOTE CONTROL PREPARATION BATTERY INSTALLATION Install the batteries as the following pictures. Be sure + and – terminals are positioned as indicated in the battery compartment (Fig1). SERVICE LIFE OF BATTERIES - The batteries normally last for one year although this depends on how often the remote control is used. -
Page 12: Basic Connection
BASIC CONNECTION ● Ensure all the cables are disconnected from the main unit before connecting to AC power source. ● Read through the instructions before connecting other equipments. CONNECTING TO AC POWER SOURCE To power outlet CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture. -
Page 13: Hdmi Connection
HDMI CONNECTION Use HDMI cable to connect the unit with HDMI cable (Not included) other devices to receive high-definition multimedia signal. Back of DVD/VCR EARPHONE CONNECTION Earphone cable (Not included) -
Page 14: Usb Connection
USB CONNECTION USB Memory Device (Not included) OPTICAL CONNECTION Use OPTICAL cable (not included) to connect the unit with amplifier or other audio decoding devices for coaxial audio signal output. RJ-45 (Local Area Network) Connection Use a LAN cable (not included) to connect this TV with available network. -
Page 15: Basic Operations
MAKE SURE ALL THE EQUIPMENTS AND POWER PLUG ARE CONNECTED PROPERLY AND THE UNIT IS SET IN CORRECT MODE BEFORE OPERATING. BASIC OPERATIONS - Press STANDBY button on the unit or remote control to power ON the unit (indicator will glow blue); press it again to power OFF (standby mode) the unit (indicator will glow red). -
Page 16: Fast Forward/Fast Backward
NOTE: When player is stopped, the player records the point where STOP was pressed (RESUME function). Press button again, playback will resume from this point. When the tray is taken out or █ (STOP) is pressed again, the RESUME function will be cleared. 5. -
Page 17: Movie Playback
9. Movie playback Insert the disc which contains movie files and after a few seconds, the screen will show all the folders on the disc. Select the folder you want to play by navigation buttons and press the OK button to confirm. -
Page 18: Enjoying Video Cd With Playback Control
11. Enjoying Video CD with playback control a) Press number buttons to select corresponding track. Example: Track 9, press 0 and 9, several seconds later, it will automatically switch to track 9. Track 15, press 1 and 5, several seconds later, it will automatically switch to track 15. NOTE: The function is available when press the MENU button repeatedly to select MENU PLAY “OFF”. - Page 19 1.4 ANGLE MARK - It is used to select whether or not the multi-angle icon is display on screen when a Multi-angle disc is playing. 1.5 LAST MEMORY - Enter another input source during DISC playback, and then back to DVD input source again, this unit will resume playback from the point where last playback was stopped, if LAST MEMORY is ON.
- Page 20 3. PREFERENCE 3.1 TV SYSTEM - Select desired TV system. 3.2 DEFAULT - It is used to reset to factory settings.
-
Page 21: Volume Control
- Press STANDBY button on the unit or remote control to power ON the unit (indicator will glow blue); press it again to power OFF (standby mode) the unit (indicator will glow red). SELECT DESIRED PROGRAM 1. Press CH+ button to play next channel. 2. -
Page 22: Live Tv
LIVE TV Channel Scan Auto Channel Scan > Settings > Channel > Auto Scan Note: Before you select Automatic Scan, you can press > Settings >Channel > Tuner Mode, press OK button into the sub-menu, select Antenna or Cable. Channel List •... - Page 23 Favorite Adding channels to your 'Favorites' list • Press button to call out the channel list, the channel list appears on the right side of the screen. • Press button and Navigation button to select your favorite channel; Press button to confirm. •...
- Page 24 Deleting channels from your 'Favorite' list • Press to call out the channel list, the channel list appears on the right side of the screen. • Press > Favorite, then press > to enter the Favorite list. • Press and Navigation button to choose the desired channel, then press choose Delete Fav.
-
Page 25: Connection
CONNECTION Wired LAN Connecting to the Internet > Settings > Network > Network Configuration You set the TV network by selecting Configuration and press the button to enter the sub-menu. Automatically obtain an IP address 1. If you connect to the wired network, the TV will automatically obtain an IP address and connect to the network. - Page 26 Note: You get access to the Internet through your TV. Connect to an available wireless network. Make sure that you have the wireless router's SSID and password before attempting to connect. Connecting to a Wireless Network > Settings > Network > Network Configuration You set the TV network by selecting Configuration and press the button to enter the submenu.
-
Page 27: Usb Device
the TV. After connection is finished, you can access the menu of the connected device on your TV screen using your TV remote and control the device. Note: HDMI cables must be used to connect HDMI CEC-compatible devices to your TV. The HDMI CEC feature of the connected device must be turned on. -
Page 28: Multi-Screen
Multi-screen Screen Sharing Mirror content from your device to the TV. INPUT > Screen Sharing Turn on the casting function of your Android/Windows10 device. Find the TV name in the searching list of your device and select it. Wait for the connection progress to complete and the content on your device will be displayed on the TV. - Page 29 View media content of your device Press INPUT button on your remote, and select a media content on the screen. Note: • Make sure our device and the TV are connected to the same network. • Some devices may not support content sharing. If your device doesn't support content sharing, you can download an app that supports the function.
-
Page 30: Smart Functions
Smart Functions Media Playing Media contents > Media By default, there are Content Sharing displayed on the Media screen. If your mobile device is connected to the TV, its name also appears on the Media screen. Note: For more information about Content Sharing, refer to its detailed introduction. >... - Page 31 Playing background music during viewing pictures You need to: Choose a picture to playback. Press button to call out playbar. Select Background Music and choose your music to create a Music Playlist. Play the background music during viewing pictures. ...
- Page 32 Home Getting familiar with the Home screen Run the TV more conveniently by selecting the corresponding sections. Press button to enter the Home Page. Manage apps Select the item you want to move, long press OK button on remote control to manage. VIDAA Account Sign in your VIDAA account.
-
Page 33: Picture And Sound
Picture and Sound Adjusting the Picture Quality Adjust current picture mode to apply to all sources or just current source. The menu is only for reference. The following modes may differ from the actual product. Choosing a picture mode > Settings > Picture > Picture Mode You can select the Picture Mode that provides the best viewing experience. - Page 34 Choosing a Picture Size > Settings > Picture > Picture Size You can adjust the picture aspect ratio based on the content you are watching. • Auto • 16:9 • • Movie Zoom Smart Scene > Settings > Picture > Smart Scene Recognise the current scene and enhance the picture quality.
- Page 35 Adjust display setting for each Picture Mode. • Apply Picture Settings: Adjust current picture mode to apply to all sources or just current source. • Backlight: Adjust image backlight. (Optional: Off/Low/High). • Brightness Adjust image brightness. • Contrast: Adjust image contrast. •...
- Page 36 Adjusting the Sound Quality Adjust current sound mode to apply to all sources or just current source. The menu is only for reference. The following modes may differ from the actual product. Choosing a sound mode > Settings > Sound > Sound Mode You can select a favorite sound mode suitable for the content type or the listening environment.
-
Page 37: Hotel Mode
> Settings > Sound > Sound Mode Settings Customize selected Sound Mode. > Settings > Sound > Speakers Select the speakers which you want to use. Hotel Mode > Settings > Sound > Speakers>Balance Press 0548, then the Hotel Mode will display. Press OK to set the Hotel Mode On. -
Page 38: Channel
Channel > Settings > Channel Press Press Navigation buttons to select the option that you want to adjust in the Channel menu. Press OK button to adjust. Tuner Mode Select if you receive TV channel over the air(antenna) or trough a cable set top box. Auto Scan Automatic search can search for effective program channel automatically. -
Page 39: Accessibility
Accessibility Press Navigation button to select Accessibility > Settings > Accessibility • High Contrast Menu: Turn High Contrast Menu On or Off. • Menu Transparency: Set the transparency of menu. (Optional: Off/Medium/High) • Video Description: Enables broadcasted descriptive audio for visually impaired. •... -
Page 40: System And Support
System and Support Setting Time > Settings > System > Time Set the current time based on your location. • Time Format Set the time to display in a 12 or 24-hour format. • Date/Time Set the date and time. •... - Page 41 • Sleep Timer Set the sleep timer to automatically turn the TV Off within a specified time: Off, 15 Minutes, 30 Minutes, 60 Minutes, 90 Minutes, 120 Minutes, User Defined. • Power On Timer Set the clock for the time you want the TV to turn on automatically. You can set the time only once or set the time in specified date weekly.
- Page 42 Voice Service > Settings > System > Voice Service Download the VIDAA APP on your mobile, then you can use your voice to control the TV, other smart home devices and more. Application Manager > Settings > System > Application Manager Set up Application preferences.
- Page 43 Press > Settings > Support System Info View System information. Self Diagnosis Perform self diagnosis to test sound, picture and connections. E-Manual Launch E-Manual and get to know more about your TV. System Upgrade Set your TV to receive the latest firmware. Disclaimer and Privacy Click to read our term and policy.
-
Page 44: Maintenance
MAINTENANCE Be sure to press POWER button to set the player to the standby mode and disconnect ● the power plug before maintaining the player. ● Wipe the player with a dry, soft cloth. ● If the surface is extremely dirty, wipe clean with a cloth which has been dipped in a weak soap-water solution and wrung out thoroughly, and then wipe again with a dry cloth. -
Page 45: Stand Installation
STAND INSTALLATION Your TV is packaged with the Stand and the Cabinet separated. Before enjoying this TV, please carry out the Stand Installation according to the instructions below. Step 1 Place the TV faced down on a soft cloth or cushion to prevent the panel from being damaged. -
Page 46: Specifications
SPECIFICATIONS Display Device 32 inch LED TV Resolution 1366×768 Display Colors 16.7M Contrast Ratio 3500:1 Aspect Ratio 16:9 30,000 Hrs Life Time Supported Discs DVD/CD/CD-RW/CD-R/VCD Compatible Music Multimedia Playback Photo Video POWER SOURCE AC 100-240V, 50/60Hz + DC 12V POWER Max.60W CONSUMPTION OPERATION... -
Page 47: Troubleshooting
GENERAL TROUBLESHOOTING Check the following points before assuming malfunctions of this unit: Symptom[COMMON] Remedy No power. Insert the power plug securely into the power outlet. No picture. Ensure that the equipment is connected properly. ● Ensure that the equipment is connected properly. ●... -
Page 48: Region Code Setting
Region code setting Region coding: All DVD discs are coded by the sales territory. Please note the player is set to region 1 coding by the factory which cannot be changed. This is in compliance with the DVD patent requirements. The region number for this DVD player is... - Page 51 Warranty Basic Warranty Statement Supersonic Inc.("Supersonic") warrants this product to the original purchaser ONLY, to be free from defects in materials and workmanship under normal use, for ninety (90) DAYS from the date of original purchase. Proof of purchase (receipt) required.
