SEDGEBROOK
Serial Number
Purchase Date
SG24908
Thank you for purchasing this ALLEN + ROTH product.
Questions, problems or missing parts?
Before returning, contact us on:
866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday or ascs@lowes.com.
42IN. ROUND TILE
GAS FIREPIT TABLE
1
ITEM #5998254
MODEL #H24S7420G
ATTACH YOUR RECEIPT HERE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LF allen + roth SEDGEBROOK H24S7420G
Summary of Contents for LF allen + roth SEDGEBROOK H24S7420G
- Page 1 ITEM #5998254 MODEL #H24S7420G 42IN. ROUND TILE GAS FIREPIT TABLE ALLEN + ROTH and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE SEDGEBROOK Serial Number Purchase Date Thank you for purchasing this ALLEN + ROTH product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents...........................3 Hardware Contents..........................4 Safety Information..........................5 Preparation.............................5 Assembly or Installation Instructions ....................8 Operating Instructions ........................12 Care and Maintenance........................12 Troubleshooting.........................12 Warranty..........................13 Replacement Parts List ......................... 13... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Cross Brace Rear Frame Frame A Table Top Cover Frame B Lava Rocks Bottom Frame Front Door... -
Page 4: Hardware Contents
HARDWARE CONTENTS (Not actual size) 4 mm Upper d6.5 x D13 x 1.0 Wrench Connector Washer ST4.8 x 16 mm M6 x 15 mm Screw Qty. 1 Bolt Qty. 1 Qty. 13 Qty. 2 Qty. 13... -
Page 5: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING • Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely assembled. • Some parts may contain sharp edges. Wear protective gloves as necessary. •... -
Page 6: Carbon Monoxide Hazard
WARNING: For Outdoor Use Only Installation and service must be performed by a qualified installer, service agency, or the gas supplier. Warning: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. •... - Page 7 When an appliance is for connection to a fixed WARNING piping system, the installation must conform with local codes or, in the absence of local codes, If the appliance is not in use, the gas must be turned with the National Fuel Gas Code, ANSI Z223.1 off at the supply cylinder.
-
Page 8: Assembly Or Installation Instructions
ASSEMBLY INSTRUCTIONS 1. PARTS REQUIRED: AA, CC, A, B & C Keep the bolts loose. Hardware Used M6 x 15 mm Bolt d6.5 x D13 x 1.0 Washer 2. PARTS REQUIRED: AA, BB, CC, B, C, D & F Keep the bolts loose. Hardware Used M6 x 15 mm Bolt ST4.8 x 16 mm... - Page 9 ASSEMBLY INSTRUCTIONS 4. PARTS REQUIRED: AA, CC, DD, C & E Tighten all bolts by using the supplied Hex key. Hardware Used M6 x 15 mm Bolt d6.5 x D13 x 1.0 Washer 5. PARTS REQUIRED: AA, CC & G Tighten all bolts by using the supplied Hex key.
- Page 10 ASSEMBLY INSTRUCTIONS Caution: The Tank must face this way. Rotate Clockwise Note: The igniter valve should be facing towards the front left side of the appliance. Fire Shield Note: In order to protect the burner system, when the fire is not in use and on rainy days, the cover should be used.
-
Page 11: Care Instructions
ASSEMBLY INSTRUCTIONS INSTRUCTIONS FOR REMOVING THE TANK Counter-Clockwise Plastic Screw Note: Step 2: Close the valve tightly before removing the tank. Remove the tank from the tank-support assembly and through the tank fastener. See Figure 2. Step 1: To remove the fuel supply hose from the tank, Note: rotate counter-clockwise. -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS Assemble on a soft surface, such as a carpet to avoid scratching the product. CARE AND MAINTENANCE • Wash frame, wicker, and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on the frame, wicker, or fabric parts. •... -
Page 13: Warranty
WARRANTY Three years limited warranty. Proof of purchase (dated register receipt) is required for warranty claims. It remains the customer’s responsibility for freight and packing charges to and from the service center. This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your patio furniture, provided your furniture is maintained with care and used only for personal, residential purposes.
