CONTENTS Safety regulations Safe use Children and vulnerable people User manual Models Description Information according regulation (EU only) 66/2014 Faults table Installation instruction Safety regulations Service Preparations for installation Sealing tape Gas connection Built in Connecting & testing Conversion instruction Conversion instruction Conversion table Power table (kW-g/h)
SAFETY REGULATIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE! Safe use • The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings. • Damage caused by incorrect connection, incorrect fitting, or incorrect use is not covered by the warranty. •...
Page 5
SAFETY REGULATIONS You might get injured or scalded. • Never cover the appliance with a cloth or something similar. If the appliance is still hot or is switched on, there is a risk of fire. • Do not use the appliance as a worktop. The appliance may accidentally be switched on or still be hot, which means objects could melt, become hot or catch fire.
Page 6
SAFETY REGULATIONS • CAUTION: The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed. Ensure that the kitchen is well ventilated especially when the appliance is in use. Keep natural ventilation holes open or install a mechanical ventilation device (mechanical extractor hood).
SAFETY REGULATIONS • The hob can only function effectively if the burner components have been assembled using the guide ridges. Ensure that the pan supports lie properly against each other and flat on the drip tray. Only then can the pans be positioned stably.
USER MANUAL Information according regulation (EU only) 66/2014 Measurements according EN60350-2 (G20-20 mbar) BG6xB / BG7xA / BG6xA BG6xC BG7xB Model identification BG3xA BG6xD BG6xE / BG9xA / BG6xF BG9xB Type of hob Gas hob Gas hob Gas hob Gas hob Number of gas burners Heating technology Gas burner...
USER MANUAL 12-24cm Ø 15-26cm Ø Min. 1 cm The distance between the pan and a nonheat resistant wall should always be greater than one centimeter. In case of smaller distances the high temperature may cause the knobs or wall to discolour and/or deform. Control: high setting low setting...
USER MANUAL Faults table Following is some advice on rectifying some common problems. What happened...? Possible cause What to do? The burners will not burn. Flame is uneven due to a Have an expert check the gas The ame is uneven / wrong gas power setting.
INSTALLATION INSTRUCTION Safety regulations • This appliance should only be connected by a registered installer. • Prior to installation, ensure that the local distribution conditions (voltage, frequency, nature of the gas and gas pressure) and the adjustment of the appliance are compatible.
INSTALLATION INSTRUCTION • This appliance is not connected to a combustion products evacuation device. It shall be installed and connected in accordance with current installation regulations. Particular attention shall be given to the relevant requirements regarding ventilation. • We recommend that the gas hob be connected by means of a fixed pipe.
INSTALLATION INSTRUCTION Preparations for installation Free space around appliance A (mm) B (mm) C (mm) D (mm) min. 650 min. 600 min. 450 min. 120 min. 650 min. 600 min. 450 min. 120 min. 650 min. 750 min. 450 min. 120 min.
INSTALLATION INSTRUCTION Accessibility oven safety hose metal T >60º C T <60º C oven Sealing tape Stainless steel drip tray Worktop Glass drip tray EN 17...
INSTALLATION INSTRUCTION Gas connection 1/2” ISO 7-1 / EN 10226-1 1/2” ISO 228 1/2” ISO 228 PTFE tape Built in If included Min. 20 mm only for 75 + 90 cm Max. 50 mm Connecting & testing Check if connections are gastight. EN 18...
CONVERSION INSTRUCTION Conversion instruction Adjusting for a different gas type! Attention! Performing of these instructions by a non-qualified person can lead to dangerous situations. The supplier is not responsible for the consequences (the arising of a hazardous situation and/or damage to persons or goods) caused by incorrect performance of these instructions by engineers who are not employees of the supplier.
CONVERSION INSTRUCTION Gas type P mBar Modification BG6xB/E BG6xC/F / BG7xA/B / BG9xA/B nozzle nozzle Convert from G20 / 20 mbar to: Replace nozzle & no action bypass Replace nozzle & screw in 28-30 bypass (see 3A) Replace nozzle & screw in (PL) G30 bypass (see 3A) Replace nozzle &...
CONVERSION INSTRUCTION Converting nozzles Please note: disconnect the appliance from the power supply. Prevent damage of the worktop. Lay down parts of the appliance on a protected base. For converting to a different type of gas, the nozzles have to be changed. The values are also marked on the nozzle.
CONVERSION INSTRUCTION 3A. Screw the by-pass screws (3) of all gas taps completely in by using the flat-blade screwdriver (T2). 3B. Remove the by-pass screws by using the flat-blade screwdriver (T2) and the nose pliers (T3). Place the new by-pass screws with the nose pliers and screw the by-pass screws of all gas taps in, by using the flat-blade screwdriver.
CONVERSION INSTRUCTION Start up 1. Reinstall the knobs, burner parts and pan supports. 2. Check if the appliance is connected to the correct gas type and pressure. 3. Open the main gas valve. 4. Insert the plug into the power socket. Checking operation 1.
ENVIRONMENTAL CONSIDERATIONS Disposal of the appliance and packaging Sustainable materials have been used during manufacture of this appliance. The appliance packaging is recyclable. The following may have been used: • cardboard; • paper; • polyethylene film (PE); • CFC-free polystyrene (PS-rigid foam); •...
