3.1 Dimensions
Overall dimensions ¹
H1 mm
W1 mm
D1 mm
¹ the height, width and depth of the
appliance without the handle and feet
Space required in use ²
H2 mm
W2 mm
D2 mm
² the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air
Overall space required in use ³
1850 H2
595 W3
647 D3
³ the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air, plus the space necessary
to allow door opening to the minimum
angle permitting removal of all internal
1950
equipment
600
3.2 Location
684
W1
W3
W2
mm
mm
mm
Refer to the installation
instructions for the
installation.
ENGLISH 7
1950
765
