Klaxon PNC-0208 Installation Instructions Manual

EN DE
FR
Nexus 110 Sounder-Beacon DC
Installation Instructions
Tone Tone Type
1. 970Hz (BS5839-1:2002)
2 800Hz/970Hz @ 2Hz (BS5839-1:2002)
3 800Hz – 970Hz @ 1Hz (BS5839-1:2002)
4 970Hz 1s OFF/1s ON (Apollo Fire Systems Alert Tone, BS5839-1:2002)
5 970Hz, 0.5s/ 630Hz, 0.5s (Apollo Fire Systems Evacuate Tone, BS5839-1:2002)
6 554Hz, 0.1s/ 440Hz, 0.4s (France – AFNOR NF S 32 001 )
7 500 – 1200Hz, 3.5s/ 0.5s OFF (Netherlands – NEN 2575:2000 Dutch Slow Whoop)
8 420Hz 0.625s ON/0.625s OFF (Australia AS1670 Alert tone)
9 500 – 1200Hz, 0.5s/ 0.5s OFF x 3/1.5s OFF (Australia AS1670 Evacuation tone)
10 550Hz/440Hz @ 0.5Hz
11 970Hz, 0.5s ON/0.5s OFF x 3/ 1.5s OFF (ISO 8201 Low tone)
12 2850Hz, 0.5s ON/0.5s OFF x 3/1.5s OFF (ISO 8201 High tone)
13 1200Hz – 500Hz @ 1Hz (DIN 33 404)
14 400Hz
15 550Hz, 0.7s/1000Hz, 0.33s
16 1500Hz – 2700Hz @ 3Hz (Vandal Alarm)
17 Simulated Bell
18 2130Hz
19 660Hz
20 660Hz 1.8s ON/1.8s OFF
21 660Hz 0.15s ON/0.15s OFF
22 510Hz, 0.25s/ 610Hz, 0.25s
23 800/1000Hz 0.5s each (1Hz)
24 250Hz – 1200Hz @ 12Hz
25 500Hz – 1200Hz @ 0.33Hz.
26 2400Hz – 2900Hz @ 9Hz
27 2400Hz – 2900Hz @ 3Hz
28 800Hz – 970Hz @ 100Hz
29 800Hz – 970Hz @ 9Hz
30 800Hz – 970Hz @ 3Hz
31 800Hz, 0.25s ON/1s OFF
32 500Hz – 1200Hz, 3.75s/0.25s OFF (AS2220)
33 340Hz
34 1000Hz
35 1400Hz – 1600Hz, 1s/1600Hz – 1400Hz, 0.5s (NF 48-265)
36 660Hz 6.5s ON/13s OFF
37 1000Hz/2000Hz, 1s each
38 720Hz, 0.7s ON/0.3s OFF
39 970Hz, 0.25s ON/OFF
40 2800Hz, 1s ON/OFF
41 2800Hz 0.25s ON/OFF
42 2400/2900 @ 2Hz
43 Chime, 554Hz/440Hz Single shot 'ding dong'
44 Chime, 554Hz/440Hz Repeating 'ding dong'
45 Chime, 970Hz/800Hz Single shot 'ding dong'
46 Chime, 970Hz/800Hz Repeating 'ding dong'
47 Hooter, Repeating
48 Gentle alarm - Tone 2, rises slowly to full volume over 30s
49 Time-Out Alarm – As Tone 2, cuts off after 10 mins
50 Time-Out Alarm – As Tone 2, cuts off after 2 mins
51 750Hz 0.33s ON/0.51s OFF
52 750Hz 0.51s ON/0.33s OFF
53 550Hz, 0.33s/1000Hz, 0.7s
54 600Hz – 900Hz/ 0.9s
55 660Hz – 680Hz/ 0.9s
56 670Hz – 725Hz/ 0.9s
57 920Hz – 750Hz/ 0.9s
58 700Hz - 900Hz, 0.3s/0.6s OFF
59 900Hz - 760Hz, 0.6s/0.3s OFF
60 750Hz
61 Power Only – Use with Stage 3 control for manual/intermittent chime triggering
62 Power Only – Use with Stage 3 control for manual/intermittent chime triggering
63 Power Only – Use with Stage 3 control for manual/intermittent horn triggering
Klaxon Signals is a registered trademark of Texecom Ltd. St
Crispin Way, Haslingden, BB4 4PW, UK
Tel: +44 1706 212524 Email: klaxon@texe.com
www.acornfiresecurity.com
NL ES PT
Tone Description /Application
www.acornfiresecurity.com
IT SE
PL
Dip Switch
(S1/S2)
O-O-O-O-O-O
O-O-O-O-O-I
O-O-O-O-I-O
O - O- O - O- I - I
O-O-O-I-O-O
O - O- O - I- O - I
O - O- O - I- I - O
O - O - O - I - I - I
O-O-I-O-O-O
O - O- I - O- O - I
O - O- I - O- I - O
O - O - I - O - I - I
O - O- I - I- O - O
O - O - I - I - O - I
O - O - I - I - I - O
O - O - I - I - I - I
O-I-O-O-O-O
O - I- O - O- O - I
O - I- O - O- I - O
O - I - O - O - I - I
O - I- O - I- O - O
O - I - O - I - O - I
O - I - O - I - I - O
O - I - O - I - I - I
O - I- I - O- O - O
O - I - I - O - O - I
O - I - I - O - I - O
O - I - I - O - I - I
O - I - I - I - O - O
O - I - I - I - O - I
O - I - I - I - I - O
O - I - I - I - I - I
I-O-O-O-O-O
I - O- O - O- O - I
I - O- O - O- I - O
I - O - O - O - I - I
I - O- O - I- O - O
I - O - O - I - O - I
I - O - O - I - I - O
I - O - O - I - I - I
I - O- I - O- O - O
I - O - I - O - O - I
I - O - I - O - I - O
I - O - I - O - I - I
I- O - I - I - O - O
I - O - I - I - O - I
I - O - I - I - I - O
I - O - I - I - I - I
I - I- O - O- O - O
I - I - O - O - O - I
I - I - O - O - I - O
I - I - O - O - I - I
I - I - O - I - O - O
I - I - O - I - O - I
I - I - O - I - I - O
I - I - O - I - I - I
I - I - I - O - O - O
I - I - I - O - O - I
I - I - I - O - I - O
I - I - I - O - I - I
I - I - I - I - O - O
I - I - I - I - O - I
I - I - I - I - I - O
DK
3rd Stage Peak Sound
Tone Level
(dBA @1m, 24-V DC)
18 110
1 110
1 110
1 110
1 110
1 107
1 110
1 105
1 110
19 107
1 110
1 112
1 110
18 105
1 111
1 116
1 112
1 113
10 109
19 108
19 107
1 107
1 111
1 105
1 110
1 116
1 116
1 110
1 110
1 110
1 108
1 110
1 106
18 111
1 110
19 108
1 113
1 106
1 110
1 113
1 113
1 115
1 104
1 107
1 106
1 106
1 107
1 109
1 109
1 109
1 106
1 107
1 111
1 109
1 105
1 107
1 110
1 109
1 110
18 107
43
43
47
Issue 1 (November 2024) INS899
Copyright © Texecom Ltd
www.klaxonsignals.com
