Klaxon PNC-0201 Installation Instructions Manual

EN DE FR
Nexus 105 Sounder-Beacon DC
Installation Instructions
Tone Tone Type
1. 970Hz (BS5839-1:2002)
2 800Hz/970Hz @ 2Hz (BS5839-1:2002)
3 800Hz – 970Hz @ 1Hz (BS5839-1:2002)
4 970Hz 1s OFF/1s ON (Apollo Fire Systems Alert Tone, BS5839-1:2002)
5 970Hz, 0.5s/ 630Hz, 0.5s (Apollo Fire Systems Evacuate Tone, BS5839-1:2002)
6 554Hz, 0.1s/ 440Hz, 0.4s (France – AFNOR NF S 32 001 )
7 500 – 1200Hz, 3.5s/ 0.5s OFF (Netherlands – NEN 2575:2000 Dutch Slow Whoop)
8 420Hz 0.625s ON/0.625s OFF (Australia AS1670 Alert tone)
9 500 – 1200Hz, 0.5s/ 0.5s OFF x 3/1.5s OFF (Australia AS1670 Evacuation tone)
10 550Hz/440Hz @ 0.5Hz
11 970Hz, 0.5s ON/0.5s OFF x 3/ 1.5s OFF (ISO 8201 Low tone)
12 2850Hz, 0.5s ON/0.5s OFF x 3/1.5s OFF (ISO 8201 High tone)
13 1200Hz – 500Hz @ 1Hz (DIN 33 404)
14 400Hz
15 550Hz, 0.7s/1000Hz, 0.33s
16 1500Hz – 2700Hz @ 3Hz (Vandal Alarm)
17 Simulated Bell
18 2130Hz
19 660Hz
20 660Hz 1.8s ON/1.8s OFF
21 660Hz 0.15s ON/0.15s OFF
22 510Hz, 0.25s/ 610Hz, 0.25s
23 800/1000Hz 0.5s each (1Hz)
24 250Hz – 1200Hz @ 12Hz
25 500Hz – 1200Hz @ 0.33Hz.
26 2400Hz – 2900Hz @ 9Hz
27 2400Hz – 2900Hz @ 3Hz
28 800Hz – 970Hz @ 100Hz
29 800Hz – 970Hz @ 9Hz
30 800Hz – 970Hz @ 3Hz
31 800Hz, 0.25s ON/1s OFF
32 500Hz – 1200Hz, 3.75s/0.25s OFF (AS2220)
33 340Hz
34 1000Hz
35 1400Hz – 1600Hz, 1s/1600Hz – 1400Hz, 0.5s (NF 48-265)
36 660Hz 6.5s ON/13s OFF
37 1000Hz/2000Hz, 1s each
38 720Hz, 0.7s ON/0.3s OFF
39 970Hz, 0.25s ON/OFF
40 2800Hz, 1s ON/OFF
41 2800Hz 0.25s ON/OFF
42 2400/2900 @ 2Hz
43 Chime, 554Hz/440Hz Single shot 'ding dong'
44 Chime, 554Hz/440Hz Repeating 'ding dong'
45 Chime, 970Hz/800Hz Single shot 'ding dong'
46 Chime, 970Hz/800Hz Repeating 'ding dong'
47 Hooter, Repeating
48 Gentle alarm - Tone 2, rises slowly to full volume over 30s
49 Time-Out Alarm – As Tone 2, cuts off after 10 mins
50 Time-Out Alarm – As Tone 2, cuts off after 2 mins
51 750Hz 0.33s ON/0.51s OFF
52 750Hz 0.51s ON/0.33s OFF
53 550Hz, 0.33s/1000Hz, 0.7s
54 600Hz – 900Hz/ 0.9s
55 660Hz – 680Hz/ 0.9s
56 670Hz – 725Hz/ 0.9s
57 920Hz – 750Hz/ 0.9s
58 700Hz - 900Hz, 0.3s/0.6s OFF
59 900Hz - 760Hz, 0.6s/0.3s OFF
60 750Hz
61 Power Only – Use with Stage 3 control for manual/intermittent chime triggering
62 Power Only – Use with Stage 3 control for manual/intermittent chime triggering
63 Power Only – Use with Stage 3 control for manual/intermittent horn triggering
Klaxon Signals is a registered trademark of Texecom Ltd.
St Crispin Way, Haslingden, BB4 4PW, UK
Tel: +44 1706 212524 Email: klaxon@texe.com
NL ES PT
www.acornfiresecurity.com
Tone Description /Application
Tones are only certified @highest volume adjustment
IT PL SE
Dip Switch
(S1/S2)
O-O-O-O-O-O
O-O-O-O-O-I
O-O-O-O-I-O
O- O- O- O- I - I
O-O-O-I-O-O
O- O- O- I - O - I
O- O- O- I - I - O
O - O - O - I - I - I
O-O-I-O-O-O
O- O- I - O - O - I
O- O- I - O - I - O
O - O - I - O - I - I
O- O- I - I - O - O
O - O - I - I - O - I
O - O - I - I - I - O
O - O - I - I - I - I
O-I-O-O-O-O
O- I - O - O - O - I
O- I - O - O - I - O
O - I - O - O - I - I
O- I - O - I - O - O
O - I - O - I - O - I
O - I - O - I - I - O
O - I - O - I - I - I
O- I - I - O - O - O
O - I - I - O - O - I
O - I - I - O - I - O
O - I - I - O - I - I
O - I - I - I - O - O
O - I - I - I - O - I
O - I - I - I - I - O
O - I - I - I - I - I
I-O-O-O-O-O
I - O - O - O - O - I
I - O - O - O - I - O
I - O - O - O - I - I
I - O - O - I - O - O
I - O - O - I - O - I
I - O - O - I - I - O
I - O - O - I - I - I
I - O - I - O - O - O
I - O - I - O - O - I
I - O - I - O - I - O
I - O - I - O - I - I
I- O - I - I - O - O
I - O - I - I - O - I
I - O - I - I - I - O
I - O - I - I - I - I
I - I - O - O - O - O
I - I - O - O - O - I
I - I - O - O - I - O
I - I - O - O - I - I
I - I - O - I - O - O
I - I - O - I - O - I
I - I - O - I - I - O
I - I - O - I - I - I
I - I - I - O - O - O
I - I - I - O - O - I
I - I - I - O - I - O
I - I - I - O - I - I
I - I - I - I - O - O
I - I - I - I - O - I
I - I - I - I - I - O
DK
Peak Sound
3rd Stage
Level
Tone
(dBA @1m, 24-V DC)
18 105
1 105
1 104
1 105
1 105
1 103
1 108
1 102
1 106
19 104
1 105
1 107
1 109
18 101
1 105
1 113
1 107
1 110
10 102
19 102
19 102
1 103
1 106
1 101
1 108
1 113
1 111
1 104
1 104
1 105
1 103
1 108
1 101
18 106
1 104
19 102
1 108
1 104
1 105
1 106
1 106
1 113
1 100
1 102
1 101
1 100
1 102
1 105
1 105
1 105
1 103
1 103
1 106
1 104
1 101
1 104
1 104
1 104
1 105
18 103
43
43
47
Issue 1 (November 2024) INS897
Copyright © Texecom Ltd
www.klaxonsignals.com
Sounder
Current
(mA Avg, 24V DC)
31
28
25
17
27
20
19
10
13
21
13
16
22
16
25
32
18
26
25
14
14
24
25
23
21
39
39
23
27
28
8
20
17
25
34
9
25
16
17
20
19
38
15
15
36
36
13
28
28
28
8
15
25
31
28
25
30
11
19
22
