Summary of Contents for Total TVLI20126
- Page 1 PRODUCT MANUAL LITHIUM-ION VACUUM CLEANER TVLI20126 UTVLI20126 TVLI20126xy UTVLI20126xy x(blank,1,2,3,4,5,6,7,8,9,E,S,A,M) y(blank,-1,-2,-3,-4,-5,-6,-7,-8,-9,E,S,A,M)
-
Page 2: General Power Tool Safety Warnings
| English Original Instructions GENERAL POWER TOOL SAFETY WARNINGS ⚠ WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. - Page 3 | English 3) Personal safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
- Page 4 | English pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 5 | English Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion.
- Page 6 | English BATTERY TOOL SAFETY WARNINGS Save these instructions. ⚠ CAUTION Only use genuine original batteries. Use of non-genuine batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury, and damage. It will also void the warranty for the tool and charged and dark areas invite accidents.
- Page 7 | English dirty. Secondary cells and batteries need to be charged before use. Always use the correct charger and refer to the manufacturer's instructions or equipment manual for proper charging instructions. Do not leave a battery on prolonged charge when not in use. After extended periods of storage, it may be necessary to charge and discharge the cells or batteries times to obtain maximum performance.
- Page 8 | English Do not expose battery cartridge to water or rain. A battery short can cause a large current flow, overheating, possible burns and even a breakdown. Do not store the tool and battery cartridge in locations where the temperature may reach or exceed 50°C (122°F). Do not incinerate the battery cartridge even if it is severely damaged or is completely worn out.
- Page 9 | English believed to be accurate at the time the document was created. However, no warranty, expressed or implied, is given. It is the buyer’s responsibility to ensure that its activities comply with the applicable regulations. Protecting the environment Separate collection. This product must not be disposed of with normal household waste.
- Page 10 | English THE SYMBOLS IN INSTRUCTION MANUAL Double insulated for additional protection Read the instruction manual before using. CE conformity. Safety alert. Please only use the accessories supported by the manufacturer. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
-
Page 11: Additional Safety Warnings
| English ADDITIONAL SAFETY WARNINGS Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. ⚠ WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards... -
Page 12: Residual Risks
| English penetration of liquids increases the risk of an electric shock. The vacuum cleaner may only be used and stored indoors. The penetration of rain or moisture into the vacuum cleaner lid increases the risk of an electric shock. m) Do not vacuum hot or burning dusts, and in rooms with and explosion hazard. -
Page 13: Specifications
| English SPECIFICATIONS 1. Dust cup 5. Sling 2. Release button for dust cup 6. Crevice nozzle 3. ON/OFF switch 7. Floor nozzle 4. Host Accessories 1pcs USB Type-C cable 1pcs Crevice nozzle 1pcs Floor nozzle... -
Page 14: Technical Specifications
| English Technical specifications TVLI20126 UTVLI20126 TVLI20126xy UTVLI20126xy Model No. x(blank,1,2,3,4,5,6,7,8,9,E,S,A,M) y(blank,-1,-2,-3,-4,-5,-6,-7,-8,-9,E,S,A,M) Voltage Dust capacity 0.5L Vacuum pressure ≥9kpa... - Page 15 | English ⚠ Warning! Only use original battery pack and battery charger as below for this power tool: Product Battery pack TFBLI2001 Model No. TFBLI20015 TFBLI2001x TFBLI2030 TFBLI2002 TFBLI2001xy ssOutput 20V MAX voltage: Output current: 1.5Ah 2.0Ah 3.0Ah 4.0Ah Product Battery pack Model No.
- Page 16 | English OPERATION PICTURE...
- Page 17 | English OPERATION PICTURE...
-
Page 18: Operation
| English OPERATION Insert the battery pack into the product as shown. (see Figure A~B) • Make sure the latches on the battery pack snap into place and that battery pack • is secured in the product before beginning operation. Make sure the on/off switch is in the off position before remove the battery pack. - Page 19 | English Press the release button for dust cup, open the dust cup. (see Figure J) • Take out the dust cup cover from the dust cup, and clean the dust cup/filter • net/HEPA filter. (see Figure K) If the HEPA filter damages, replace the HEPA filter in time. •...
- Page 20 | English MAINTENANCE&MALFUNCTIONS Possible malfunctions and methods of their eliminations Malfunction Probable causes Actions ● Switch failure ●The power cord or wiring is broken, Disconnect When the machine is turned power cord plug malfunction; machine from the on, the electric motor does ●...
- Page 21 TOTAL TOOLS WORLD MADE IN CHINA T0823.V02 NEWWAY TECHNOLOGY (SUZHOU) CO., LIMITED No. 20 Dagang Road, Fuqiao Town, Taicang City, China...
