Studer Vista 5 Service Manual

BIOS settings v1.0 MSI 945GT Speedster Series
BIOS v1.0 is installed (as default) in Vista5 desks with serial number up to 1087
Start up the desk and while booting wait for the following invitation on the central screen:
Press F1 to enter setup and <F12> to enter boot menue
Press key F1 as soon as this message appears to enter into the BIOS menu:
Check the pictures as shown on the following pages and change the settings accordingly
Please note:
Pictures with plain pain numbers (e.g.: 2) show the3 main screen picture and picture with a second (sub) number
(e.g. 2.1) shows a sub picture of the main screen.
Scrolling rules:
Use → right and ← left arrow key on the keyboard to select the folder: Main / Advanced / PC Health / Security /
System / Boot / Exit
Use ↑ up and ↓ down keys of the keyboard to select (highlight) the function line where a parameter need to be
changed
Pressing Enter opens the highlighted function line
•
Choose the desired setting with the ↑ up and ↓ down keys of the keyboard
•
Pressing enter accept the selected setting
•
Pressing escape will return to the previous page without changing anything
Pressing Escape excit the submenue and return to the main folder
Picture 1
Vista5 Service Manual BIOS Settings
