SERVICE MANUAL Contents Table of Contents ········································································································· 1 Chapter 1. General Information ·················································································· 2 1-1. General guideline ···························································································· 2 1-2. Insurance Test ································································································ 2 1-3. How to read this Service Manual ······································································ 3 Chapter 2. Product Feature ······················································································ 4 2-1. Specifications ································································································· 4 2-2.
SERVICE MANUAL Chapter Electrical Parts specifications ······························································ 21 Chapter 1 General Information 1-1. General Guidelines When servicing , obse rve the o riginal lead dress. If a short circuit is found, replace all parts which ha ve been overheated or damaged by the short circuit. After se rvicing, see to it that all the pro tective devices such as insulation barriers, insula tion papers shields are properly installed.
SERVICE MANUAL 1-2-2. Photo used in this manual The illustration and photos used in this Manual may not base on the f inal design of products, which may dif f er f rom your products in some way. 1-3. How to read this Service Manual 1-3-1.
SERVICE MANUAL Chapter 3 Installation, adjustments and maintenance 3-1. Unpacking 1. Remove all packaging material; this includes the f oam base and all adhesive tape holding the f reezer accessories inside and outside. 2. Inspect and remove any remains of packing, tape or printed materials bef ore powering on the f reezer. 3-2.
SERVICE MANUAL 3-4.Defrost Def rosting and Draining the Freezer 1. Def rost whenever the f rost becomes 5MM thick. Never use a sharp or metallic instrument to remove the f rost as it may damage the cooling coils.(A punctured coil will void the warranty) 2.
SERVICE MANUAL Chapter 4 Disassembly 4-1. Door assembly (Door, hinge, hinge cover) 1. Unscrew the hinge cover screw with screwdriver, take away the top and bottom cover by pull it, and then unscrew the screws on the hinge, so the whole hinge could be moved. Top hinge cover Bottom hinge cover 4-2.
SERVICE MANUAL 4-3.Control panel assembly (Panel, cover board, knob, indicator light) Stretch your arm into the compartment, push the connector inside, when the clip f alls of f the cabinet, and take of f the control panel and the connective wire cord with an acutilingual plier. 4-4.
SERVICE MANUAL Chapter 5 Control and display system 5-1. Control panel To prevent temperature being accidentally modified, the control is intentionally resistant to turning. To vary the setting, please use a coin or screwdriver. 1. To switch on: Turn the control to the right adjust temperature to 2.
SERVICE MANUAL Chapter 6 System flow principle 6-1. Refrigeration flow chart The ref rigeration system of direct cooling single-system cooler belongs to the category of a single-temperature and single-control ref rigerating system with one evaporators and is controlled by a single temperature control.
SERVICE MANUAL Chapter 8 Trouble shooting 8-1. Normal phenomena Problem Possible Causes What To Do Move the control to a temperature setting. Freezer does Temperature control not operate or in OFF or Min or 0 Power-On Light position. is not on Freezer is Push the plug completely into the outlet.
Page 17
SERVICE MANUAL The fuse is Replace f use or reset the breaker blown/circuit breaker is tripped. Door/lid left open. Check to see if package is holding door/lid open. Closed the door or reduce the times of opening Too frequent or too long door/lid the door openings.
SERVICE MANUAL 8-2. Abnormal phenomena 8-2-1. Compressor doesn’t start Com pressor doesn’ t start Adjustment of thermostat Compressor doesn ’ t start Temperature of sometimes because the environment temperature in case is >30℃ 1-3 grade between starting and stop temperature, should pay 16-30℃...
SERVICE MANUAL Chapter 9 Electrical Parts specifications Spare parts Model The main parameters Picture Compressor SC70CY1 220-240v~/50Hz Volt:...
Page 21
SERVICE MANUAL Sincere forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com Please login the Haier technical support website for more product information. http://community.haierdealer.com/km...
