The cables must be distributed in such a way that the necessary, followed. ground connected driver and the device head are next to the socket. TECHNICAL INFORMATION Nominal voltage Nominal output (motor) light F6297110V 18W LED 3000/4000/6000K 110-120V AC...
100%(completely) remove 2 screws from the moun�ng plate for later use. 70% remove 2 screws from the moun�ng plate. Warning:Failure to disconnect power supply prior to installa�on may result in serious injury. For safety and best opera�ng results,recommend you have a qualified electrician install this fan. Secure moun�ng plate to outlet box by �ghtening moun�ng screws &...
Page 5
Remove 9 screws from the motor. One blade at a �me,insert the blade into the slot through the motor and aligh the blade with the 3 holes. Tighten screws securely. Repeat for the remaining 2 blades. Remove 3 screws from the motor, and then connect the connectors. Install the light pan to the motor with 3 screws.
Remote controller INSTRUCTION OF INSTALLATION AND OPERATION 1. INSTALLING RECEIVER IN CEILING FAN CODE INPUT A.Safety precautions 1. WARNING: HIGH VOLTAGE! Disconnect power CODE by removing fuse or switching off circuit breaker. 2. Do not use with solid state fans. 3.
2. OPERATING TRANSMITTER: Operating the buttons on the panel of the transmitter. LEARN 3 key -for fan high speed. LEARN CODE Open battery compartment CODE 2 key-for fan medium speed. to remove insulation spacer CR2032 CR2032 before use transmitter 1 key-for fan low speed. OFF key-for fan off.
AFTER INSTALLATION WOBBLE” The fan blades have been adjusted in the factory to minimize any wobble NOTE:CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON A RUBBER CROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING, IT WOULD CAUSE EXCESS VIBRATION.
