- Page 1 IOM6 Hub Hardware User Manual V2.0, July 2024 isystem.com/start...
-
Page 2: General Safety Instructions
General safety instructions Please read the following safety precautions carefully before putting this device to use to avoid any personal injuries, damage to the instrument, or to the target system. Use this instrument only for its intended purpose as specified by this manual to prevent potential hazards. Use included power cord and power supply The enclosed power supply has been approved for use by TASKING. - Page 3 Contents IOM6 Hub ............................... 4 Package content ............................4 Assembling IOM6 Hub on iC5700 ......................5 User Notes ..............................9...
-
Page 4: Iom6 Hub
IOM6 Hub This manual shows how to assemble the Hub on the iC5700 BlueBox. Package content The Hub (Ordering code IC57031) is delivered with the following components: iC5700 Cover IC57031 PCB IC57031 Cover 5x standoffs (B) 8x screws (C) 5x screws (D) -
Page 5: Assembling Iom6 Hub On Ic5700
Assembling IOM6 Hub on iC5700 To assemble the Hub on the iC5700 BlueBox, follow the steps below. Remove the 4 screws (A) using included Torx TX10 and remove the iC5700 cover. The old cover will be no longer required since the new one comes along with the Hub. - Page 6 Carefully place the new cover over the IC5700 and tighten it with 4 torx screws (C). Carefully place the Hub on top and press it down in order to make a good connection.
- Page 7 Tighten the Hub with 5 screws (D) using Phillips’s screwdriver. Tilt the Hub cover and slide it over the FNet connectors. Do not push the rear of the cover down yet!
- Page 8 Bend the FBridge connector’s EMI panel finger shield inward and carefully push the Hub cover down. Tighten the Hub cover with 4 torx screws (C). For further instructions on connecting the assembled device to a target and other iSYSTEM tools, refer to the iC5700 User Manual.
-
Page 9: User Notes
User Notes This page is intentionally left blank. - Page 10 This page is intentionally left blank.
- Page 11 This page is intentionally left blank.
- Page 12 Visit our website for: · Support - isystem.com/support · Tutorials - isystem.com/start · Knowledge Base - kb.isystem.com www.isystem.com...
