  • Page 1 SCANNER Operating Manual SICK ICR620E...
  • Page 2 Copyright by Carl Valentin GmbH / 7960081.0819 Information on the scope of delivery, appearance, performance, dimensions, and weight reflect our knowledge at the time of printing. We reserve the rights to make modifications. All rights, including those regarding the translation, are reserved. No part of this document may be reproduced in any form (print, photocopy, or any other method) or edited, copied, or distributed electronically without written permission from Carl Valentin GmbH.

  • Page 3: Table Of Contents

    Scanner SICK ICR620E Table of Contents Table of Contents General Notes ................ 5 Environmentally-Friendly Disposal .......... 5 Product Description ..............6 Technical Data ............... 7 Installation of Scanner Bracket ..........9 Spectra II ................. 9 Vario III .................. 10 Configuration ............... 11 Settings of the Scanner Software ..........
  • Page 4 Table of Contents Scanner SICK ICR620E Operating Manual 08.19...

  • Page 5: General Notes

    Scanner SICK ICR620E General Notes General Notes By means of the scanner option the immediate verification of printed bar codes is possible. Moreover errors such as defective printhead, transfer ribbons etc. can be avoided. The bar code scanner is a state-of-the-art device which complies with the recognized safety-related rules and regulations.

  • Page 6: Product Description

    General Notes Scanner SICK ICR620E 1.2 Product Description Figure 1 Intelligent decoding algorithms for maximum reading performance and high throughput, even with highly reflective or contaminated codes. Variable illumination concept ensures stable reading even in changing light conditions. Maximum reliability on shiny or reflective surfaces thanks to flexible optical accessories.

  • Page 7: Technical Data

    Scanner SICK ICR620E Technical Data Technical Data Features Focus Adjustable focus (electric) Sensor CMOS matrix sensor, grey values Sensor resolution 752 px x 480 px (WVGA) Internal lighting Light source Illumination LEDs: visible red light (λ= 617 ± 15 nm) Feedback spot: visible green light(λ...
  • Page 8 Technical Data Scanner SICK ICR620E Interfaces Serial RS 232, RS 422 Function Host, AUX 0.3 kBaud … 115.2 kBaud, AUX: 57.6 kBaud (RS-232) Data transmission range Remark USB 2.0 (for parameterization only) Function Reading pulse Digital inputs, non-powered, serial interface, CAN, auto...

  • Page 9: Installation Of Scanner Bracket

    Scanner SICK ICR620E Installation of Scanner Bracket Installation of Scanner Bracket 3.1 Spectra II DANGER! Risk of death via electric shock!  Before installation/dismantling of the option scanner, disconnect the label printer from the mains supply and wait for a moment until the power supply unit has discharged.

  • Page 10: Vario Iii

    Installation of Scanner Bracket Scanner SICK ICR620E 3.2 Vario III DANGER! Risk of death via electric shock!  Before installation/dismantling of the option scanner, disconnect the label printer from the mains supply and wait for a moment until the power supply unit has discharged.

  • Page 11: Spectra Ii

    Scanner SICK ICR620E Configuration Configuration The ICR620E must be configured accordingly to operate on a Spectra II or Vario III. For this, the PC software SOPAS Engineering Tool can be downloaded from the SICK webseite (www.sick.com). After installing the software, the scanner must be connected to the PC with a micro USB cable.

  • Page 12: Reading Configuration

    Configuration Scanner SICK ICR620E Figure 5 After selecting a parameter range, the corresponding parameters are displayed on the right side and can be changed there. 4.1.1 Reading Configuration Various settings regarding camera and illumination can be made. Camera Figure 6 Operating Manual 08.19...
  • Page 13 Scanner SICK ICR620E Configuration Illumination Figure 7 Object trigger control Various settings regarding the signal to start the scanner can be made. Figure 8 Do not change the setting 'Start by / User defined command' because the scanner is to be controlled by the printer which sends the start command (STX)21(ETX) and the stop command (STX)22(ETX).

  • Page 14: Code Configuration

    Configuration Scanner SICK ICR620E 4.1.2 Code Configuration Settings regarding the codes to be scanned can be made. An automatic configuration can be performed by placing an existing bar code under the scanner. Figure 9 However, it is also possible to change settings manually for the individual code types.

  • Page 15: Data Processing

    Scanner SICK ICR620E Configuration Settings for Settings for two-dimensional bar codes can be made. 2D bar codes Figure 11 4.1.3 Data Processing Settings for the data processing can be adjusted here. Figure 12 Output control Settings for the output control can be adjusted here.
  • Page 16 Configuration Scanner SICK ICR620E Evaluation conditions Figure 14 Normally no settings are necessary. At print start, the printer sends the number of codes to be scanned (min/max) to the scanner. Matchcode Figure 15 Normally no settings are necessary. Operating Manual...
  • Page 17 Scanner SICK ICR620E Configuration Filter/sorter for the output formatting Figure 16 Normally no settings are necessary. Output format Figure 17 No changes should be made here, othewise the communication between printer and scanner may not work. 05.19 Operating Manual...

  • Page 18: Network/Interfaces/Ios

    Configuration Scanner SICK ICR620E 4.1.4 Network/Interfaces/Ios Serial Figure 18 The interface Serial Host is used as connection between the scanner and printer. If the interface parameters (baud rate, etc) are changed, they must be adjusted accordingly in the function menu 'Scanner' of the printer.

  • Page 19: Saving The Settings In The Scanner

    Scanner SICK ICR620E Configuration Digital outputs / beeper Figure 20 No settings are necessary as the digital outputs are not used. If necessary, the beeper can be switched on as feedback from the scanner. 4.2 Saving the Settings in the Scanner...
  • Page 20 Configuration Scanner SICK ICR620E Operating Manual 08.19...

  • Page 21: Function Menu Scanner

    Scanner SICK ICR620E Function Menu Scanner Function Menu Scanner 5.1 Scanner Mode This display provides the possibility to set the desired scanner mode (Mode), the number of acceptable non-readable (NoRd) as well as the number of label feedings (Flab). Operating mode (Mode) Mode 1 (data comparison), i.e.

  • Page 22: Scanner Type

    Function Menu Scanner Scanner SICK ICR620E 5.2 Scanner Type The different scanners are controlled by different commands and/or the scanners return the scanned data in different manners. Therefore this window provides the possibility to select the scanner model corresponding to the connected scanner.

  • Page 23: Scan Length

    Scanner SICK ICR620E Function Menu Scanner 5.5 Scan Length If this parameter is set to 0 (AUTO), the switch on and off position of scanner is calculated by means of position and height of bar code onto the label. If the parameter Scan Length is not 0, so this defines the length of scan sector.

  • Page 24: Scan Delay

    Function Menu Scanner Scanner SICK ICR620E 5.7 Scan Delay In scan mode 'after print' the scanner is switched On after the label was printed. With this value the time can be specified between printing the label and switching On the scanner.

  • Page 25: Parameter Sets For Scanner Mode

    Scanner SICK ICR620E Parameter Sets for Scanner Mode Parameter Sets for Scanner Mode Set scanner operating mode SOH F C D M - - r M P N F - - - - ETB M: 0 = Off M: 1 = Mode 1 (data comparison)
  • Page 26 Parameter Sets for Scanner Mode Scanner SICK ICR620E Set scan length SOH F C D M B - r N N N N - - - - ETB N = Scan length in 1/10 mm Enquiry scan length SOH F C D M B - w p p p p p p p p ETB...

  • Page 27: Scanner Variable

    Set scanner type SOH F C D M F - r N N N N - - - - ETB N: 5 = Zebra DS457 N: 6 = SICK ICR620 N: 7 = SICK CLV6XX Enquire scanner type SOH F C D M F - w p p p p p p p p ETB...
  • Page 28 Parameter Sets for Scanner Mode Scanner SICK ICR620E Operating Manual 08.19...

  • Page 29: Error Messages

    Scanner SICK ICR620E Error Messages Error Messages Error message Cause Remedy Scanner The connected bar code Check the connection scanner signals a device error. scanner/printer. Check thescanner (dirty). Scanner NoRead Bad print quality. Increase the contrast. Printhead completely soiled or Clean the printhead or defective.
  • Page 30 Error Messages Scanner SICK ICR620E Operating Manual 08.19...

  • Page 31: Index

    Scanner SICK ICR620E Index Index configuration ..................11 configuration, settings scanner software . 11, 12, 13, 14, 15, 16, 17, 18, environmentally-friendly disposal ............5 error messages .................. 29 function menu scanner interface parameter ................. 24 Scan delay ..................24 scan length ..................
  • Page 32 Carl Valentin GmbH Neckarstraße 78 86 u. 94 78056 Villingen-Schwenningen Phone +49 7720 9712-0 info@carl-valentin.de www.carl-valentin.de...
