ULTIMATE SPEED CL002 Operating And Safety Instructions Manual

BOOSTER SEAT
Operating and safety instructions
Congratulations!
With your purchase, you have chosen a high-quality product from our company.
These instructions for use represent an integral part, and must be kept on the
product and accessible to the user throughout its service life. If you pass the booster
seat on to a third party, be sure to include these instructions for use.
Intended use
Read the instructions for use carefully, especially the safety instructions,
before using the booster seat. Only use the booster seat as described
in these instructions for use and for the specified area of use. Any other
use is considered improper and may result in damage to property or personal
injury. The booster seat is for private use only and is not a toy. The manufacturer
accepts no liability for damage caused by improper use.
Warning and safety instructions
• To provide your child with the greatest possible level of safety, please read
these instructions for use carefully and follow them.
• The rigid objects and plastic parts of the booster seat shall be arranged and
installed in such a way that they cannot be trapped by a moving seat or in a
vehicle door during daily use of the vehicle.
• Do not use any load-bearing points other than those described in the
instructions for use and marked on the booster seat.
• Only use this booster seat in the car. It is not suitable for use at home,
for example.
• For safety reasons, the booster seat must be secured in the vehicle even if
there is no child in it.
• Never overload the booster seat by carrying more than one child or
additional loads.
• All straps holding the booster seat to the vehicle should be tight.
• It is important that low-fitting harnesses firmly enclose the child's pelvis.
• The lap belt must be positioned as low as possible so that the pelvis is held
correctly.
• The booster seat should be replaced if it has been subjected to severe stress in
an accident.
• It is dangerous to make changes or additions to the product without the
approval of a competent authority. Failure to follow the manufacturer's
assembly, warning and safety instructions also poses risks to the child's safety.
No modifications may be made to the booster seat.
• Never leave the child unattended in the booster seat.
• Make sure that there are no heavy or sharp objects in the vehicle (e.g. on the
parcel shelf) that could injure passengers in the event of an accident.
Ensure that luggage or other items that could cause injury in a collision are
properly secured
• The booster seat must not be used without the seat cover – without the seat
cover, the child could suffer burns as a result of the heated plastic seat.
• Ensure that the seat cover of the booster seat is not replaced with one other
than that recommended by the manufacturer. The textile cover is an essential
part of the product.
• Please protect the booster seat from sunlight when it is not in use, otherwise it
could become too hot for the child.
PRODUCT DESCRIPTION
Type: 1
Body height: 125 - 150 cm
Direction of installation: Forward-facing
Installation: 3-point car seat belt
Permit type: Universal Booster
NOTE
This is an improved child restraint system of the "universal" category with cushions
that facilitate a compensation for height. It has been approved in accordance
with UN Regulation No 129 for use on those vehicle seats which are suitable for
"i-Size" and "universal" category enhanced r estraint systems as specified by the
vehicle manufacturer in the vehicle manual. If in doubt, the manufacturer of the
improved child restraint system or the retailer should be consulted.
Use in the vehicle
• This product is suitable for children with a height of 125-150 cm.
The installation is carried out in forward-facing direction only. The child is
strapped in together with the booster seat using the car's 3-point belt.
• Never use this child restraint system in seating positions where an active front
airbag is installed.
• An active front airbag can cause death or serious injury to your child in the
event of an accident.
IAN 491971_2404
GB IE NI
GB DK FR NL BE DE
• Please read the instructions carefully and keep them safe for future reference.
• You can use your booster seat in the following seating positions:
Installation in the vehicle with 3-point safety belt
1. Place the booster seat in the direction of travel on the rear seat or passenger
seat. Make sure that the booster seat rests completely on the seat surface of
the car seat and is pressed up against the backrest. Do not place wedges or
cushions under the booster seat to change the seating position.
2. Place the child on the booster seat. Make sure the child is sitting up straight
and leaning.
3. Fasten your child with the 3-point safety belt of your vehicle until you hear a
click. Make sure that the belt runs underneath both armrests along the green
belt guide. The belt must not be twisted. It is important that the shoulder pad is
centred on the shoulder. The lap belt must firmly enclose the child's pelvis.
The belt's buckle must lie smoothly against the booster seat.
1. 2.
Care instructions
The black plastic core can be wiped with a damp cloth, without detergent.
The textile cover is washable:
Safety self-check
Should you experience problems with the installation, please contact the
manufacturer. Check the seat belt regularly to ensure it is functioning properly.
Also check the booster seat regularly for any signs of visual damage.
Do not use a damaged product.
What to do after an accident
After an accident, please do not use the booster seat. Replace the booster seat
with a new one after an accident.
Disposal
Dispose of the product in accordance with the laws and regulations in force in
your country.
Warranty and service handling
You will receive a 3-year guarantee on this product from the date of purchase.
Statutory rights are not restricted by this guarantee. If a material or manufacturing
defect occurs within the warranty period, we will – at our discretion – repair or
replace the product for you free of charge or refund the purchase price.
This warranty does not cover product parts that are subject to normal wear and
tear. This warranty service is provided after submission of the sales receipt and
documentation of the defect. The warranty period is not extended by the warranty.
The repair or replacement of the product does not start a new warranty period.
Repairs required after the expiry of the warranty period are subject to a charge.
Processing in the event of a
warranty claim
• Send the sales receipt together with a description of the defect and the item
number IAN 491971_2404 to the following address:
Netsend GmbH, Nachtwaid 6,
79206 Breisach / Germany
Hotline: 00800 80040044
(hotline free of charge - 8 am - 8 pm),
e-mail: info@mynetsend.de
• Depending on the nature of the defect, our service partner will decide how
the warranty claim will be handled (repair, replacement or refund).
AT CH
3.
