OWNER'S MANUAL
WALL MOUNTED INDOOR UNIT
SPLIT-STYLE AIR CONDITIONER
DRAW06F2A, DRAW09F2A, DRAW12F2A,
DRAW18F2A, DRAW24F2A, DRAW33F2A
R-454B 208/230V 1ph 60 HZ
Model Number:
Serial Number:
Purchase Date:
Installing Contractor Company Name:
TIP
Capture relevant information about your Durastar mini-split equipment before it is
installed and write it above for future reference.
R
DURASTAR.COM
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DURASTAR DRAW09F2A
Summary of Contents for DURASTAR DRAW09F2A
- Page 1 DRAW06F2A, DRAW09F2A, DRAW12F2A, DRAW18F2A, DRAW24F2A, DRAW33F2A R-454B 208/230V 1ph 60 HZ Model Number: Serial Number: Purchase Date: Installing Contractor Company Name: Capture relevant information about your Durastar mini-split equipment before it is installed and write it above for future reference. DURASTAR.COM...
-
Page 2: Table Of Contents
• Read the troubleshooting section of this manual as it will help you diagnose and solve common issues. • Visit us on the web at WWW.DURASTAR.COM to download product guides and up-to-date information. • If you need warranty service, our friendly customer service representatives are available via email at QUESTIONS@DURASTAR.COM or by telephone at 1-888-320-0706. -
Page 3: Symbols Used In This Manual
NOTE: The pencil indicates any manufacturer notes relating to surrounding content. These may include further clarifications or call-outs. TIP: A light bulb symbol indicates suggested manufacturer tips for the user to get the most out of the Durastar equipment and to accommodate the best user experience. R-454B WARNING:... -
Page 4: Important Safety Precautions
Do not operate your air conditioner in a wet room such as a bathroom or laundry room. Too much exposure to water can cause electrical components to short circuit. • If the air conditioner is used together with burners or other heating devices, thoroughly ventilate the room to avoid oxygen deficiency. DURASTAR.COM... -
Page 5: Electrical Safety
For units that have an auxiliary electric heater, do not install the unit within 3 feet (1 meter) of any combustible materials. • Do not install the unit in a location that may be exposed to combustible gas leaks. If combustible gas accumulates around the unit, it may cause a fire. DURASTAR.COM... - Page 6 When the refrigerant sensor malfunctions, the indoor unit will display the error code “FHCC”. The refrigerant sensor can not be repaired and can only be replaced by the manufacturer. It shall only be replaced with the sensor specified by the manufacturer. DURASTAR.COM...
- Page 7 All training shall follow the ANNEX HH requirements of UL 60335-2-40 4th Edition. Examples for such working procedures are: • breaking into the refrigerating circuit; • opening of sealed components; • opening of ventilated enclosures. DURASTAR.COM...
-
Page 8: Detection Of Flammable Refrigerants
NITROGEN when using flame to open circuit; and • open the circuit The refrigerant charge shall be recovered into the correct recovery cylinders if venting is not allowed by local and national codes. For appliances containing flammable refrigerants, the DURASTAR.COM... -
Page 9: Charging Procedures
Do not climb onto or place objects on top of the outdoor unit. • Do not allow the air conditioner to operate for long periods of time with doors or windows open, or if the humidity is very high. DURASTAR.COM... -
Page 10: Fcc Compliance Statement
Newport News, VA City, State： 23606 Postal Code： Durastar.com Telephone number or internet contact information： FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Parts Identification
Front Panel Louver Remote Control Air Filter Remote Control Display Window (Behind Front Panel) Holder OUTDOOR UNIT Signal Cable, Air Inlets Refrigerant Pipes, and Drain Hose Wiring Terminal Valve Cover Air Outlet NOTE Outdoor units will vary in appearance. DURASTAR.COM... -
Page 12: Accessories
Mounting Plate Battery Remote Control Wall Anchor (depending Holder on model) Remote Mounting Plate (depending Control Holder Screw on model) Mounting Screw Installation Copper Nut Template Drain Joint Carbon Filter Refrigerant Pipe Adapter Drain Joint Seal (included with DRAW33F1B) DURASTAR.COM... -
Page 13: Operating Temperatures
Regularly inspect and clean air filters. NOTE Your Durastar heat pump's outdoor unit is equipped with a base pan heater, allowing it to continue to operate at freezing temperatures as low as -22°F (-30°C). When outdoor air temperatures are at or below 32°F (0°C), we strongly recommend keeping the unit plugged in at all times to ensure smooth, ongoing performance. -
Page 14: Remote Control
Press to stop the air flow from blowing directly on you if it becomes uncomfortable. See "Advanced Buttons and Features" section. 13. ACTIVE CLEAN Button Turns on and off the ACTIVE CLEAN feature. See "Advanced Buttons and Features" section. 14. LED Button Press to turn on and off the indoor unit's display screen. DURASTAR.COM... -
Page 15: Remote Control Screen Indicators
Not available for This display is blank when this unit operating in FAN mode. NOTE All indicators shown in the above figure are for purposes of clear representation. During actual operation, only the relative indicators are illuminated in the display window. DURASTAR.COM... -
Page 16: Operating Modes
*For this series of mini-splits, changing the temperature in DRY mode does not deviate performance from the above mode description. NOTE The FAN speed cannot be adjusted in AUTO or DRY Mode. NOTE Press and hold the UP and DOWN buttons simultaneously for 3 seconds to switch between °F and °C. DURASTAR.COM... -
Page 17: Advanced Buttons And Features
25% or 50% based on the selection. Press the ECO/GEAR button to turn off this feature. NOTE The overall energy consumption of the unit is affected by many factors and this feature's energy reduction level setting will not result in directly proportional money savings on your energy bill. DURASTAR.COM... - Page 18 Press and hold the TURBO button again for seven (7) seconds to unlock and turn off this feature. The remote will display "OF" for three (3) seconds. NETWORK SETUP ( This feature is only shown if available on this unit. DURASTAR.COM...
- Page 19 GENTLE button to slow the unit and divert the air flow away from you. Press the GENTLE button again to turn this feature off. This feature is only available under COOL, DRY, and FAN modes. This feature is not available in multiple zone configurations. DURASTAR.COM...
- Page 20 The LOCK feature disables the remote's buttons so your settings cannot Clean Turbo be changed. To activate the remote LOCK feature, simultaneously press the CLEAN and TURBO buttons for five (5) seconds. To turn off the LOCK feature, simultaneously press CLEAN and TURBO again for five (5) seconds. DURASTAR.COM...
-
Page 21: Louvered Air Flow
While the unit is on, press the SWING button on the remote control to set the vertical direction of airflow. Swing AUTOMATIC SWING ( ) Press the SWING button once to start the automatic vertical (up and down) movement of the louver. Press again to make it stop. DURASTAR.COM... -
Page 22: Led Display Indicators
Displays when unit is defrosting. This may last 5-10 minutes depending on the outdoor temperature and the amount of frost buildup on the outside unit. REFRIGERANT FHCC. EHC1, Displays if a refrigerant leak is detected. Contact your dealer or certified LEAK EHC2, etc. technician for service. DURASTAR.COM... -
Page 23: Manual Operation (Use Without Remote)
Do not use benzene, paint thinner, polishing powder or other solvents to clean the unit. They can cause the plastic surface to crack or deform. • Do not use water hotter than 104°F (40°C) to clean the front panel. This can cause the panel to deform or become discolored. DURASTAR.COM... -
Page 24: Maintenance: Long Periods Of Non-Use
After long periods of non-use, or before periods of frequent use, do the following: • Inspect for damaged wires. • Clean all filters. • Check for leaks. • Replace batteries. • Make sure nothing is blocking any air inlets or outlets. DURASTAR.COM... -
Page 25: Troubleshooting
The indoor unit makes A rushing air sound may occur when the louver resets its position. noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts. DURASTAR.COM... - Page 26 • Press ON/OFF button on remote control to restart operation. NOTE If problem persists, contact a local dealer or your nearest customer service center. Provide them with a detailed description of the unit malfunction as well as your model number. DURASTAR.COM...
- Page 27 10 minutes. The problem continue may resolve itself. flashing or If not, turn the power off, wait a few minutes. Then, turn the unit on. error code If the problem persists, contact your nearest certified service technician. appears DURASTAR.COM...
- Page 28 Wait three minutes after restarting the been activated unit Timer is activated Turn timer off NOTE If your problem persists after performing the checks and diagnostics above, or an error code remains, turn off your unit immediately and contact an authorized service center. DURASTAR.COM...
-
Page 29: Limited Warranty - Parts
Covered Equipment Parts are warranted to be free from defects in material and workmanship for a period of seven (7) years from the date of installation, under normal use and service. Durastar will, at its option, repair or replace any part determined by Durastar to be defective. Replacement parts carry the balance of the original parts warranty. - Page 30 These items will be required to complete any warranty service. A Durastar authorized representative will verify warranty eligibility and determine appropriate service options. Service will be provided during normal business hours.
- Page 31 THIS PAGE INTENTIONALLY LEFT BLANK. DURASTAR.COM...
- Page 32 THIS PAGE INTENTIONALLY LEFT BLANK. ©2024 Durastar DURASTAR.COM V1.0 0924...
