- Page 1 BO-105 Scale Helicopter Smart He l i uic Start Guide...
-
Page 2: Flight Environment Requirements
1.Check whether the main blades ,tail blades, helicopter body and landing skids are damaged or distorted, please replace them with the genuine Fly Wing RC parts. 2.Check whether the flight control linkages and fuselage are fixed firmly, and whether the GPS unit is correctly fixed on the helicopter tail boom (horizontally placed, straight line behind the main mast ) H1 Unit is fixed firmly on the double sided foam pad either at the front or at the back of the main mast. - Page 3 and other functions will not be available. lease make a reasonable judgment on the flight condition by naked eye observation, and set the corresponding flight and return altitude according to the flight environment. Disclaimer： The remote control model is not a toy. This product is o u tab e to adults o a e e e e ce...
- Page 4 About transmitter UH-1 using FS-i6S transmitter which is 2.4GHz, 1km* control distance Please don't touch your transmitter menu it has been factory set, if the setting is changed incorrectly, you will not be able to start the helicopter. * For the first time, you need to connect a computer to activate this function The maximum communication distance is measured in the experimental environment for reference only.
-
Page 5: Install Blade
Assemble BO-105 1.Insert GPS Insert the GPS wire into the flight control GPS interface correctly, confirm that the self locking bayonet is in place, and confirm that the GPS unit is fixed on the tail pipe. 2. Install blade Insert the blade as shown in the figure first, then rotate it clockwise, and then pull the blade out outward. - Page 6 Operate BO-105 1. Starting transmitter Hold the two power buttons at the same time for two seconds to turn on the transmitter. If the transmitter shows any warning please flip the motor run switch to top position motor off action then turn the mode switch to GPS position.
-
Page 7: Ready To Fly
. Ready to fly lease place the helicopter in a flat open outdoor area with user facing the tail. GPS mode unlock take off take mode as an example ● 2、Move the helicopter outdoors, away from buildings 1 Turn the transmitter motor run switch to stop position, mode switch to GPS, and trees, turn on the power, and wait for the search satellite... -
Page 8: Home Mode
Unlock /take off in 3D mode take mode 2 as an example ● 2、Move the helicopter outdoors, away from buildings 1 Dial the motor run switch to stop position, dial and trees, turn on the power, and the LED is Blue. the mode switch to position. - Page 9 • Users can increase or decrease the return voltage according to the flight demand, or turn off the low power return function. It is recommended to set the return voltage between 3.65 V and 3.75 V, which will affect the actual flight duration and return distance When the transmitter signal is normal, the transmitter can be used to control the landing position during the return landing.
-
Page 10: Compass Calibration
6. Compass calibration Compass is easy to be disturbed by strong electric field, strong magnetic field and strong electromagnetic field, which will lead to abnormal compass and even cause flight accidents. Regular calibration can make the compass works at its best. alibration precautions 1. -
Page 11: Get More Information
7. . Model 1/Model 2 change 1、When the helicopter is powered off, press hort press the wrench icon to enter the and hold the screen lock icon for about menu seconds to unlock the screen nter the Y T menu and click sticks mode elect the corresponding mode on the right side of the screen and press the arrow in the upper left corner to return... - Page 12 FLY WING Youtube Facebook 宜 F lywingRC. com WWW. 一...
