UFC SPEED BAG WALL MOUNT SET
UHK- 75612
Hardware List
A.Bolt M8x15mm
B.Flat Washer M8
x 4
x 4
F. Bolt M6x30mm
G. Bolt M6x45mm
x 4
x 4
Part List
J. U-shaped Tube
x 2
M. Connector
x 1
C.Nut M8
D. Wrench 4
E. Wrench 5
x 4
x 1
H. Flat Washer M6
I. Nut M6
x 12
K. Triangle Steel Frame
L. Speed Bag
x 2
N. Ball Hook
O. Round Plate
x 1
x 1
UFC SPEED BAG WALL MOUNT SET
UHK- 75612
01
Assembly Instructions
Step 1
Place part N into the hole of the part M.
x 1
x 8
Step 2
Place part M on the surface of part O and connect them together with hardware F, H, I.
x 1
F
F
H
H
I
I
02
