ORIGINAL OPERATING INSTRUCTIONS
Thank you for buying a WORKPRO product. Your 750W mini circular saw has been engineered and manufactured
to WORKPRO's high standard for dependability, ease of operation, and operator safety. When properly cared for, it
will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before
using this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
750W MINI CIRCULAR SAW
W125067AU
Manufacturer & Distributed by
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WorkPro W125067AU
Summary of Contents for WorkPro W125067AU
- Page 1 ORIGINAL OPERATING INSTRUCTIONS 750W MINI CIRCULAR SAW Thank you for buying a WORKPRO product. Your 750W mini circular saw has been engineered and manufactured to WORKPRO’s high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ----------------------------------------------------------------------------------------- Know your product --------------------------------------------------------------------------------- General power tool safety warnings --------------------------------------------------------------- Circular saw safety warnings ---------------------------------------------------------------------- Symbols --------------------------------------------------------------------------------------------- Technical data -------------------------------------------------------------------------------------- Operating instructions ------------------------------------------------------------------------------ Working hints for your tool ----------------------------------------------------------------------- 9-12 ... -
Page 3: Know Your Product
KNOW YOUR PRODUCT 1.Hex wrench rack 2.Main handle 3.Safety lock off switch 4.ON / OFF switch 5.Base plate 6.Saw blade retractible safety guard control knob 7.Saw blade retractible safety guard 8.Hex nut 9.Parallel guide locking bolt 10.Spindle lock button 11.Depth locking knob 12.Cutting depth scale 13. -
Page 4: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS Do not use a power tool while you are tired or WARNING! under the influence of drugs, alcohol or Read and understand all instructions. Failure to medication. A moment of inattention while follow the warnings and instructions may result in operating power tools may result in serious electric shock,fire and/or serious injury. -
Page 5: Circular Saw Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS d. Store idle power tools out of the reach of etc., in accord ance with these instructions and in children and do not allow persons unfamiliar the manner intended for the particular type of with the power tool or these instruc tions to power tool, taking into account the working operate the power tool. - Page 6 CIRCULAR SAW SAFETY WARNINGS saw backward while the blade is in motion or ADDITIONAL SAFETY INSTRUCTIONS kickback may occur. Investigate and take FOR PLUNGE TYPE SAWS corrective actions to eliminate the cause of blade Wear ear protectors. Exposure to noise can cause binding.
- Page 7 CIRCULAR SAW SAFETY WARNINGS d. Wheels must be used only for recommended m. Position the cord clear of the spinning applications. For example: do not grind with the accessory. If you lose control, the cord may be cut side of cut-off wheel. Abrasive cut-off wheels are or snagged and your hand or arm may be pulled into intended for peripheral grinding, side forces applied the spinning wheel.
-
Page 8: Symbols
Wear ear protection Warning Wear dust mask Double insulation TECHNICAL DATA Model No..........W125067AU Max. cutting depth at 45°(with 115mm blade) Rated Voltage ......220-240V~50/60Hz .................25.5mm Rated power ............750W Max. cutting depth at 0°(with 120mm blade) ..45mm No load speed .......... -
Page 9: Noise And Vibration
NOISE AND VIBRATION NOISE INFORMATION For cutting wood For cutting metal A weighted sound pressure LpA=91dB(A) LpA=93dB(A) A weighted sound power LwA=102dB(A) LwA=104dB(A) VIBRATION INFORMATION Vibration total values (triax vector sum) determined according to EN 62841: For cutting wood For cutting metal Vibration total value a =5.60m/s =6.12m/s... -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS NOTE: Before using the tools, read the Fig.B instruction book carefully. 1. ON/OFF Switch（See Fig.A） Check the correct function of the base plate before plugging in the power cord. Choose a corresponding saw blade and check its condition and sharpness. - Page 11 OPERATING INSTRUCTIONS Fig.G Fig.D Fig.E 5. Adjusting the cutting angle (See Fig.H) To adjust the cutting angle (0-45°), please follow below steps: 1. Loosen the angle locking knob by hand. 2. Raise/lower the locking knob and set the blade to the required angle as shown on the cutting angle scale.
-
Page 12: Working Hints For Your Tool
OPERATING INSTRUCTIONS 6. Dust collecting (See Fig.I) Fig.I Use of dust collection can reduce dust-related hazards.To prevent personal injuries,make sure to connect a suitable vacuum cleaner to the dust extraction port by means of the dust collecting system adaptor. To connect a dust collection system, fit the dust adaptor(※NOT PROVIDED) to the dust extraction port. -
Page 13: Trouble Shooting
TROUBLE SHOOTING Although your new mini circular saw is really very simple to operate, if you do experience problems, please check the following: Symptom Possible Causes Possible Solution Check to make sure power cord is connected well into a working outlet. -
Page 14: Ukca-Declaration Of Conformity
1. Product: MINI CIRCULAR SAW 750W 2. Model No.: W125067AU 3. Serialnumber: N/A 4. Applicable UKCA Directives: Supply of Machinery (Safety) Regulations 2008 Electromagnetic Compatibility Regulations 2016...
