INSTALLATION AND OPERATING MANUAL
ATS Controller
ATyS C55/65
www.socomec.com
To download, brochures,
catalogues and technical manuals.
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATyS C55 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for socomec ATyS C55

Summary of Contents for socomec ATyS C55

  • Page 1 INSTALLATION AND OPERATING MANUAL ATS Controller ATyS C55/65 www.socomec.com To download, brochures, catalogues and technical manuals.

  • Page 2: Table Of Contents

    11.10. The visualization POP-UPS ............34 ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 3 14.1.8. PASSWORDS .............75 ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 4 15.5. Accessories and expansion modules ..........93 ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 5 Annex 16 - 6. ATyS C55/C65 Technical characteristics ....... . .

  • Page 6: General Safety Instructions

    • This manual provides instructions on safety, connections instructions on the SOCOMEC ATyS C55 / C65 ATS controller. • Whether the ATyS C55 / C65 is sold as a loose product, as a spare, in a kit or as part of an enclosed solution or in any...

  • Page 7: Introduction

    2. INTRODUCTION ATYS C55 and C65 ATS controllers are compliant to international product standards and are designed specifically for use in low voltage power applications to ensure the safe transfer of a load supply between a normal and an alternate source.

  • Page 8: Quick Start

    I1 I2 I3 IN GNDGND 67235 BENFELD, FRANCE Non contractual document. © 2023, Socomec SAS. All rights reserved. IEC 61010 The use of this input is optional, when used configure IN6 to «DOOR OPEN» in mode «NC». ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 9: Product Dimensions

    Screw Tightening torque PH1 / 0.2 Nm / 1.77 lb.in Gasket for IP 65 Backplate mounting 0.31 ±0,004 0.25 ±0,1 R 0.24 R 6,25 0.07 Clip the mounting feet in Screws not delivered with product the designated slot ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 10: Controller Wiring

    When powered for the first time the controller will prompt the user to configure using the wizard. To access the wizard input code 1000 then the configuration will go as follow: Switch & Language Time & date Source config Product Name Communication Application For advanced configuration go to parameters menu. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 11 DISPLAY SCHEDULER SOCO SCREEN 1-4 R GENERAL PARAMETERS 6723 DATE AND TIME CUSTOM 1 LED CONFIG CUSTOM 2 Non c © 20 OPTIONS CUSTOM 3 CHANGE PRODUCT NAME CUSTOM 4 C65 only SCREENSAVER TEXT ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 12: General Overview

    4. GENERAL OVERVIEW The ATyS C55/C65 ATS Controller reference includes: - 1 ATS Controller - 1 ATyS C65 IP65 gasket (available as accessory for C55) - 1 ATyS Cx5 door mounting kit - 1 ATyS Cx5 backplate mounting kit - Quickstarts instruction sheet All other components described in this instruction manual are available as accessories and sold separately.

  • Page 13: Environmental

    • 95% humidity without condensation at 55°C. 5.3.3. Altitude • Up to 2000m. 5.4. Storage Conditions 5.4.1. Temperature • From -40 to +70°C. 5.4.2. Hygrometry • Recommendation: to be stored in dry, non-corrosive and non-saline atmospheric conditions. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 14: Storage Duration Period

    1.080 5.4.6. EMC The ATyS C55 & C65 controllers are compliant to EMC requirements as described in IEC 60947-6-1, (Products intended to be installed in an «Industrial, Commercial and/or Residential Environment» therefore respecting both Class A as well as Class B EMC requirements).

  • Page 15: Standard Compliance And Marking

    NFPA 110* (Specific UL Reference). (*) For a UL certified product, SOCOMEC provide reference 1600 0066 (ATyS C66, that is UL61010 listed and UR 1008 recognised as a standalone ATS controller as well as UL1008 listed in association with ATyS FT or ATyS DT transfer switching equipment) 7.

  • Page 16: Installation

    8.66 48,10 8.2. Mounting The ATyS C55/65 can be mounted either on the door or on the backplate of an enclosure (both mounting kits are delivered with the product). 8.2.1. Door mounting The ATyS C55/C65 can be mounted on doors up to with a thickness 4mm (0.15in).

  • Page 17: Backplate Mounting

    STEP 1: Placing the 4 mounting legs on the controller Insert the mounting legs into the 4 slots (2 top side and 2 bottom side, (cf. below top side view). 0.31 ±0,004 0.25 ±0,1 R 0.24 R 6,25 0.07 ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 18: Digital Inputs/Outputs

    C IN6 IN5 IN4 IN3 IN2 IN1 OUT 6 OUT 5 OUT 4 OUT 3 OUT 2 OUT 1 Optional Aux. Supply LATCHING RELAY OUTPUTS (NC-NO-C) OUTPUT RELAYS (NC-NO-C) INPUTS/ENTRÉES (6W) ATyS C65 ATSE Controller ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 19 The configuration and the state (function and active or off) of the additional I/O can be visualized at any time by going to Dashboard 7 "I/O" and selecting sub-menus 7.3 "EXTERNAL INPUTS" and 7.4 "EXTERNAL OUTPUTS". ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 20: Connection

    To help secure the control cables during the wiring, the controller includes seven fixing supports on the back of the controller to retain the cables in place using cable ties. Example of cable way. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 21 - Use 90°C copper wire for installations with ambient temperature from 35-60°C. When the ambient temperature is above 60°C, Use 105°C copper wire. * Impulse voltage withstand tests at 6kV between phases of the same source and 8kV between phases of a different source. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 22: Power Supply

    9.4. DC Power Supply The ATyS C55/65 includes an optional DC power supply input to power the controller in case both sources are off. The DC power supply voltage needed to power up the controller is between 9VDC and 28VDC. The 24VDC power supply is mandatory when using the C65 with additional external I/O modules.

  • Page 23: Energy Backup

    TRANSFORMATEURS DE COURANT : 1A ou 5A SOURCE S2 SOURCE S1 GND GND 120Ω RS485 The configuration for the measurement should be done in the Parameters/Load menu (see chapter "14.1.2. LOAD parameters menu (C65 Only)", page 55). ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 24 GND GND GND GND GND GND C-65 VT - VOLTAGE TRANSFORMER C-65 C-65 C-65 GND GND GND GND WARNING ! One of the GND inputs must be grounded. C-65 C-65 C-65 C-65 GND GND C-65 ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 25: Command Circuits

    Logic Impulse Impulse Maintained Impulse Impulse See chapter specific functions for more details. Impulse duration, time between retries and number of retries can be configured in "MAIN MENU" > "PARAMETERS" > "NETWORK" > "APPLICATION". ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 26 Open* * The ATyS C55/C65 include two bi-stable relays with backup energy, when the controller loses all sources of power supply (DPS, DC supply), the outputs 5 & 6 will activate using their independent backup power after the fail timer has timed out or 60s max from power failure detection. This is a safety feature is designed to ensure power availability to the load in Main-Genset or Genset-Genset application by forcing generators to start in case of total power loss.

  • Page 27: First Power Up - Smart Wizard

    • To use the manual configuration: users will enter manually all network configuration values. The controller will then require the configurator 4-digit password (by default, 1000). ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 28 (it is not possible to set NO PRIORITY in MAIN-GEN application). CAUTION ! Make sure that the settings match your installation for the correct functioning of the transfer switch. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 29 The 7th step will not affect the functioning of the transfer switch but allows the user to select a name for the product. Default name is ATyS C55/65, but it can be changed to any combination of letters, numbers and signs, for instance, “Cooling”, “Line 1”...

  • Page 30: Visualisation Options

    *This is available only for the screens of the dashboard menu All the dashboards have the same display format as follows: Dashboard name Screen name Favourite Date/Time Active alarms Information Screen navigation Optional shortcuts ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 31: Mimic

    2.1 STAT: Informs the user on the availability of each source and which source the load is connected to. 2.2 SYNC: Information on the voltage, frequency and phase angle difference of both sources. This sub-menu is especially useful when using the in-phase transfer function with and ATyS FT type RTSE. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 32: Metering

    4.4 S: total apparent power phase by phase 4.5 Pf: Power factor phase by phase. 4.6 Ea: Active energy. 4.7 Er: Reactive energy. 4.8 Es: Apparent energy. 4.9 RST E : Resets the partial energy counters. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 33: Timers

    I/O modules (if used), as well as if it is “ACTIVE” or “OFF” (“ACTIVE” meaning the contact with common point is closed). 7.1 IN: Controller inputs. 7.2 OUT: Controller outputs. 7.3 E.IN: External inputs (IO10 modules). 7.4 E.OUT: External outputs (IO10 modules). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 34: Maintenance

    "MAIN MENU" > "PARAMETERS" > "DISPLAY" > "OPTIONS" > "POPUP DISPLAYED". Note: if timer pop-ups are deactivated the function to bypass current active timer with inputs or communication will not be functional. (Bypass timers through the TIMER dashboard will still be functional). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 35: Operation And Control

    Long press: Sets the current dashboard screen as favorite (C65 only). Short press: Enter / OK / set a value / accept / confirm. OK/Save & Quit Long press: (only for configuration) Save and Quit (back to previous configuration screen). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 36: Navigation Menu

    Note: in manual mode, if a source is lost, the genset (if any) will start but the controller will not force a transfer. The purpose is to keep the supply of the control and the communications. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 37: Availability Conditions

    Loss of Phase: will be detected in all cases. Note: The controller will not detect any phase/neutral wire failure downstream of the switching device. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 38 The source LEDs will not be impacted by the programmable outputs “FORCE SOURCE UNAVAIL.” & “FORCE SOURCE AVAIL.” (OA1, OA2, OU1, OU2). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 39: Test Operating Mode

    TEST ON LOAD will cause a load supply interruption when testing the transfer function as the load will change from one source to another in open transition. For more information on the tests sequence see "Annex 16 - 5. Operating sequences", page 110. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 40: Main Menus Details

    (to visualize the active mode use dashboard screens, or the LEDs on the HMI). Example: mode can be inhibited, but when entering the menu the mode will say “automatic” (which is not the current mode). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 41: Log/Event History

    As the controller can host a large number of registers in the log, the EVENT BY DATE functions is a search engine that permits to go directly to a selectable date and time and see the events that took place at that moment (C65 only). ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 42 “14.3 Maintenance menu”). Each log will show the fault description and the time & date when it occurred. For more details on faults see chapter “15.2. Fault management and troubleshooting”. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 43: Statistics Menu

    “CUSTOM 2” if both tests are scheduled to occur at the same time. This is to avoid additional constraints on the genset. Only for ATyS C65, ATyS C55 has 1 Custom engine exerciser program. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 44 January 5th at 1pm). (date and hour when first TEST will take place) WARNING ! If using “Manual retransfer” specific function, the transfer to the main source will not take place when the test ends, a user confirmation is required. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 45 In case the start time is the same for 2 or Custom 1 ends more Custom tests, the lowest number properly after its takes over. Therefore here, Custom 1 original duration ends starts fter its uration ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 46: About

    MAIN MENU” > “MAINTENANCE” > ”INTRODUCE PHONE NUMBER” 13.6. Other main menus The menus, parameters, specific functions and maintenance are detailed in the next chapter configuration. For the full menu architecture see "Annex 16 - 7. Full menu architecture", page 115. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 47: Configuration

    14. CONFIGURATION The configuration on the ATyS C55/65 can be done: - Directly on the HMI. - By USB connection to the controller (using Easy Config System software, available for free download at www.socomec.com). - Through communication (DIGIWARE or RS485).

  • Page 48: Network Parameters Menu

    WARNING ! In order to save the settings it’s mandatory to select SAVE CONFIG on the bottom of the screen or press the "OK" button for 1.5s and a pop-up will appear asking for confirmation before “save & exit”. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 49: Application

    SWITCH TECHNOLOGY: This setting defines the type of RTSE / switching technology that is connected to the RTSE options are: - ATyS r/d: Users should select this option when using any Socomec type ATyS r, ATyS d, ATyS dM, ATyS dH, ATyS S/ Sd switches or equivalent motorized three position switch-based (PC Type) RTSE.
  • Page 50 Note: in order to save the settings it’s mandatory to select SAVE CONFIG on the bottom of the screen or press the “OK” button for 1.5s and a pop-up will appear asking for confirmation before “save & exit”. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 51: Op Range S1 And S2

    The hystereses define return to normal levels following an under-voltage or over-voltage. Percentage of nominal value Upper threshold (OV FAIL) Upper threshold hysteresis (OV RESTORE) Time Lower threshold hysteresis (UV RESTORE) Lower threshold (UV FAIL) Source available ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 52: Default Value

    Note: in order to save the settings it’s mandatory to select SAVE CONFIG on the bottom of the screen or press OK button for 1.5s and a pop-up will appear asking for confirmation before “save & exit”. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 53 Source 1 Source 2 Load Load 3P+N 3P+HL Source 1 : Three phase network with neutral Three phase network with neutral 1P+N Source 2 : Single phase network with neutral Source 1 Source 2 Load ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 54 I1, I2, I3, In PT, QT, ST, PFT PT, QT, ST, PFT I1, I2 I1, I2, I3, In I1, I2, I3, In I1, I2, I3 (1) High leg (Neutral) must be between phase 1 and 2. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 55: Load Parameters Menu (C65 Only)

    LINE I1,I2,I3,I4 WAY: This setting defines the direction of the current transformer. For example, if the current transformers have been installed in the opposite direction, using this options it is possible to correct without having to re-install the CT. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 56: Display Parameters Menu

    14.1.3.2. DATE AND TIME The date and time will remain running thanks to the RTC battery even if all sources are off. However users can modify the date and date format using this menu. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 57: Led Config (C65 Only)

    MODULE X” input/output (input/output linked to an I/O module). REPORT IDX: This setting is available only when the “LED FUNCTIONS” has been set to “INPUT REPORT” or “OUTPUT REPORT”. This option selects the input or output number to report. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 58: Options

    To change the name select this menu and press “OK” again, a keyboard will appear in order to select the new name. By default the name of the controller is “ATyS C55” or “ATyS C65” depending on the type of controller, the new controller name is limited to 31 characters.

  • Page 59: Timers Parameters Menu

    By default the “AVAILABLE TIMER” is set to 5s, this timer can be configured from 0s up to 9999s by increments of 1s. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 60: Genset Source 1/2

    If the source is not linked to a generator, verify that the application is set to MAIN-GEN or GEN-GEN and if the application is set to MAIN-GEN check that the current source is not the priority source. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 61 GENSET TIMEOUT TIMER. By default this timer is set to 1800s, the configuration range is from 1s to 9999s. In GEN-GEN The "GENSET TIMEOUT" and "BATT CHARGE DURATION" timers as well as the "BATTERY CHARGER" output will apply only to the secondary genset. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 62: Test On/Off Load

    It is therefore recommended to use pushbuttons rather than selector switches for test functions programmed to “LIMITED”. Note: see "Annex 16 - 5. Operating sequences", page 110 for operational timer graph and see TIMER Annex for more details on configurable values for these timers. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 63: I/O

    If the “OK” or “Return” button is pressed the pop-up message will be cleared but the detection will still be ongoing. Note: I/O module detection and I/O module configuration will not be functional if in the “COMMUNICATION”>”DIGIWARE MODE” the controller is not set to “MASTER OVER I/O”. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 64: External I/O Config

    FUNCTIONS menu. Consult the I/O Annex 16 - 3, page 105104 and Annex 16 - 4, page 107106 to have the full list of functions to be configured on the I/O. Warning! after each menu configuration do not forget to save by pressing "SAVE CONFIG" or pressing the "OK" button for at least 1.5 seconds. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 65: Communication Parameters Menu

    14.1.6. COMMUNICATION parameters menu 14.1.6.1. Connection method for RS485 The MODBUS RTU protocol available on the ATyS C55/C65 communicates via an RS485 series link (2 or 3 wires) which is used to operate, configure or read parameters from a PC or an API.

  • Page 66: Communication (Menu)

    If the controller is set to “MASTER OVER I/O” the controller will be able to detect, program and control I/O modules but it will not be able to share information to other digiware products using the DIGIBUS connection. By default the controller is set to “MASTER OVER I/O”. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 67: Digiware Connection

    I-30 D-70 IO-10 I-30 D-70 IO-10 I-30 M-70 RS485 IO-10 I-30 When the D70 or M70 Socomec gateways are used, the ATyS C55 or C65 can be connected by RS485 or with the DIGIBUS. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 68: I/O Module Connections

    50 m reel + 100 connectors 4829 0185 Note: these cables are specific RJ45 cable for use with the DIGIWARE bus, do not use standard RJ45 cables. The maximum length of the Digiware bus is 100 meters (328 feet). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 69: Alarms Parameters Menu

    The number of available alarm ID depends on the type of alarm: - 4 alarms available for MEASURE - 6 alarms available for MAINTENANCE - 4 alarms available for COMBINATION - 4 alarms available for LOGIC - 8 alarms available for SYSTEM ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 70 “OK” again for 1.5s to confirm overwriting the current configuration. Note: If using the “AUD – Audible alarm” output, this output will only be active when a alarm set to “CRITICAL” is active. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 71: Measure Alarms

    HYSTERESIS (%): When the parameter measured is in the hysteresis value the alarm will be deactivated. The hysteresis value is a percentage of the upper and lower threshold value. Hysteresis can be configured from 0.00% up to 10.0% by increments of 0.1%. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 72 10 000.0A Current amplitude unbalance. Iph sys Total current. 10 000.0A Iunb 10 000.0A Current vectorial unbalance. 10 000.0A Neutral current. Note: Partial energies can be reset using the ENERGY “4.9 RESET ENERGY” dashboard ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 73: Maintenance Alarms

    Maximum of time the input TRIP BRK1 TOTAL TRIP BRK1 Action 10 000 has been switched on Maximum of time the input TRIP BRK2 TOTAL TRIP BRK2 Action 10 000 has been switched on ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 74: Combination Alarms

    Activated if the auxiliary DC supply connected is less than 10 VDC Activated if the source linked to a generator is available 10 seconds after the genset signal GENSET RUNNING has been removed (after cool-down timer). ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 75: Passwords

    Maintenance (access to service menu) 1010 These default passwords can be changed in the “PARAMETERS”> “PASSWORD” WARNING ! If the maintenance password is lost it cannot be restored. Please contact SOCOMEC to retrieve and modify these passwords. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 76: Specific Functions Menu

    It is also possible to program an output to “WAIT MAN RETRANSF”, this output will be active when the controller is waiting for user confirmation to retransfer. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 77: Inphase Transfer (C65 Only)

    At any time, the synchronism status of the 2 sources can be checked on the dashboard 2.2 STATUS / SYNC: Note: in-phase transfer is only available for I-II switches, selected technology must be ATyS FT, this function cannot be enabled when using other technologies. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 78: Return To 0

    Note: This function will only work if both the switch and the controller are still supplied (by the opposite source, an external source, UPS or others, independent from the emergency and normal source). If the typology of the switch (technology) doesn’t allow the function, a message will pop up as follows: ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 79: Load Ctrl (C65 Only)

    POST TRANSFER TIMER (s): After transferring to the priority source the output “FORCED SHEDDING” will remain active for the duration of this timer. This timer can be configured from 0s to 60s, by default it is set to 1s. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 80: Smart Load Shedding (C65 Only)

    In CONTROL mode (manually operating the switch through the controller buttons or via communications), this function will force the controller to take into account the “dead band timer” when transferring from one source to the other. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 81: Hvac Compressor (C65 Only)

    - I NHIBITION: The automatic mode is inhibited, in case of main source failure the generator start signal will not be activated (as long as the controller remains powered on). The manual mode remains accessible. - By default this menu is set to “TOTAL INHIBIT”. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 82 WARNING ! When using a CB type RTSE, if either of the breakers trip without using the “TRIP BRK1” or “TRIP BRK2” inputs this will be considered as an “UNEXPECTED TRANSFER” fault. To avoid such faults it is therefore recommended to use the above function and inputs. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 83: Load Adding Delay

    G G E E N N S S E E T T M M A A I I N N S S M M A A I I N N S S o o u u t t ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 84: Cycler

    When the input is disabled again the controller will return to the 0 position. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 85: Transfer Method

    2 in order to return only after maintenance has been verified on the source 1. By default this function is set to DISABLED. See graphic below for COMMIT function logic: ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 86: Maintenance Menu

    - RESET BYPASS COUNTERS: Resets the number time the bypass was used. - RESET BREAKER 1 COUNTERS: Resets the number of trips on the breaker 1. - RESET BREAKER 2 COUNTERS: Resets the number of trips on the breaker 2. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 87 C65 can stay powered on after it is charged when both sources and auxiliary power is lost. The product is designed to guarantee 15s of backup power for 8 years. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 88: Configuration Through Easyconfig System Software

    14.4. Configuration through EasyConfig System software EasyConfig System is a software tool that permits to fully configure the ATyS C55/C65 and other Socomec products with a very intuitive interface and that permits also preparing configurations when not connected to the product, save preset configurations and loading them to the controller(s) when being in front of the product.

  • Page 89: Maintenance

    SERIAL NUMBER: Serial number of the product. The number can also be found on the top marking of the product as “Nº S/N” followed by a number. This number might be asked by Socomec service team whenever technical support is required.

  • Page 90: Faults Management And Troubleshooting

    The total number of faults logged on the controller is dynamic, as the total number of “faults + alarms” is 100 (not including the events, which are 3000 on C65 and 300 on C55) and uses a FIFO ordering. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 91: Maintenance Of The Controller

    To clean the front face of the equipment, use a soft cloth with water and non-abrasive liquids. The ATyS C55/C65 controller is conceived to be a maintenance free, fit and forget unit. However, it is recommended to perform visual inspections periodically on the device, checking the connections, that the display screen is functional and the LED using the lamp test button and ensuring the correct functioning with the switching device and with any possible associated software.

  • Page 92: Spare Parts

    Controller mounting screws / 1609 0004 Fixing clips (for door mounting) (kit of 4 units) Controller mounting feet (for 1609 0005 back plate mounting) (kit of 4 units) ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 93: Accessories And Expansion Modules

    For the connection between the controller and the accessories and between modules, a RJ45 Digiware cable is needed. There are different sizes available: Length (m) Quantity Reference 4829 0181 4829 0188 4829 0182 4829 0183 4829 0184 4829 0186 4829 0187 50 m reel + 100 connectors 4829 0185 ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 94: Annexes

    16. ANNEXES Annex 16 - 1. Wiring Diagrams The below diagrams detail the connections of the ATyS C55/C65 with ATyS Switches as well as the generic wiring diagram for circuit breakers. 16.1.1. Connection diagram with ATYS d 4A type gG...
  • Page 95 ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 96: Connection Diagram With Circuit Breakers

    "9.6.1. Command circuits", page 25. CAUTION ! Due to the numerous types of RTSE type CB (circuit breakers) available on the market, compatibility and specific wiring designs must be carried out and qualified by others. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 97: With Electrical Interlock

    16.1.2.2. With electrical interlock Check that the DPS is adapted to the RTSE current and the network voltage requirements. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 98: Connection Diagram With Atys Dh

    IN1 IN2 IN3 IN4 IN5 IN6COM INPUTS OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 DIGIWARE DIGIWARE SOURCE 1 SOURCE 2 RS485 L1 L2 L3 N L2 L3 N I1 I2 I3 IN GNDGND ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 99 IN1 IN2 IN3 IN4 IN5 IN6COM INPUTS OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 DIGIWARE DIGIWARE SOURCE 1 SOURCE 2 RS485 L1 L2 L3 N L2 L3 N I1 I2 I3 IN GNDGND ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 100: Connection Diagram With Atys Dm

    16.1.4. Connection diagram with ATyS dM ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 101: Annex 16 - 2. Timers List

    (such as motors) to decay. (1) For the C55 there is only 1 DBT dead band timer, which will be applied for both sources. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 102 External Order Test On Load – End Delay Timer: This time delay ON LOAD POST / starts counting at the end of E2T Timer. The return to the main 0-1800 AFTER supply takes place at the end of E3T time. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 103 External Order Test On Load – End Delay Timer: This time delay LOAD POST / starts counting at the end of E6T Timer. The Genset signal will 0-1800s AFTER (s) switch at the end E7T. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 104 (up to 7 timers). x20s Duration of a cycle for a source, at the end of the cycle S1/S2 CYCLE Cycler 1CY/2CY the controller will initate a transfer based on transfer 0-9999 DURATION (h) settings. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 105: Annex 16 - 3. Input List

    It will bypass the load control delay timer (ELD) when active, if the elevator LOAD CTRL BYPASS function is active. Inhibits source 1. Transfer to the source is forbidden and if the load is on that INHIBIT S1 source it will immediately be transferred to the opposite ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 106 CHANGE PRIO Changes the priority between sources BYPASS STAB S1 Bypasses the stabilisation timer for S1 (S1 return timer) BYPASS STAB S2 Bypasses the stabilisation timer for S2 (S2 return timer) ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 107: Annex 16 - 4. Output List

    Source 2 unavailable: Output activated if source 2 is not considered as available (see conditions of S2 UNAVAIL. availability in the dedicated chapter of the manual) or the source has been inhibited. ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 108 It avoids stressing the compressors in HVAC chillers. NONE OUTPUT NOT USED ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 109 The latching relays can take up to 2 seconds between opposite orders (NO to NC or NC to NO) and for added security when starting a genset will change state based on the timers or when the backup power is exhausted. ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 110: Annex 16 - 5. Operating Sequences

    (DT) Delayed Retransfer Manual retransfer Transition? (DT) autorization active? Source 1 and 2 are Go to CENTER-OFF Return Timer lost? Dead band timer GO TO SOURCE 2 Source 1 is back? UTILITY-GENSET FLOWCHART ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 111 Manual retransfer Transition? (DT) active? autorization active? Source 1 and 2 are Go to CENTER-OFF Return Timer Return Timer lost? Dead band timer GO TO SOURCE 2 Source 1 is back? Source 1 is back? ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 112: Annex 16 - 6. Atys C55/C65 Technical Characteristics

    Annex 16 - 6. ATyS C55/C65 Technical characteristics Mechanical features Casing type Fitted on a door (160x220) or back-plate Case material PC (Polycarbonate) IP65 front panel /IP30 without gasket/ Protection degree IP20 rear panel Screen resolution 350x160 pixels – 8 lines of text...

  • Page 113: Modbus Rtu

    Impulse V withstand Uimp=4kV. Test = 8kV between sources/6kV between phases Installation overvoltage category OVC III Degree of pollution Pollution degree 3 Connection USB 2 Type Type B Micro USB Protocol Modbus RTU on USB ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 114 2kV power access, 1kV signal access Surge Immunity 1kV diff Conducted RF Immunity 10Vrms Radiated RF Emmision Class B Conducted RF Emmision Class B Case Fire reaction of housing and cover self-extinguishing UL94-V0 Service life components MTBF >100yr ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 115: Annex 16 - 7. Full Menu Architecture

    Default 4000 PRESS OK FOR MANUAL MANUAL RETRANSFER RETRANSFER EVENT LOG EVENT BY DATE* IN PROGRESS ALARM LOG PWD: 4000 HISTORY IN PROGRESS PWD: 1000 FAULT LOG HISTORY PRESS OK TO RESET FAULTS STATISTICS ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 116 TEST DURATION (s) START DATE START TIME TYPE SET PERIODIC SCHEDULE CUSTOM 3* TEST DURATION (s) GENSET SCHEDULER PWD: 4000 START DATE START TIME TYPE SET PERIODIC SCHEDULE CUSTOM 4* TEST DURATION (s) START DATE PARAMETERS ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 117 S2 UNDERFREQUENCY FAIL (%) S2 UNDERFREQUENCY RESTORE LOAD STATUS LOAD TYPE Inom LOAD NAME CT PRIMARY CT SECONDARY LOAD* NEUTRAL CT PRIMARY NEUTRAL CT SECONDARY LINE I1 WAY LINE I2 WAY LINE I3 WAY LINE I4 WAY ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 118 TEST BUTTON USE OPTIONS LAMP TEST DURATION (s) POPUP DISPLAYED CHANGE PRODUCT NAME ATS NAME: TEXT POLICE LINE 1 TEXT LINE 2 TEXT SCREENSAVER TEXT LINE 3 TEXT LINE 4 TEXT PREVIEW DEFAULT LOGO ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 119 EXT TEST ON LOAD POST (s) TEST OFF LOAD TEST OFF LOAD (s) EXT TEST OFF LOAD PRE (s) TESTS OFF LOAD EXT TEST OFF LOAD EXT TEST OFF LOAD (s) EXT TEST OFF LOAD POST (s) ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 120 OUTPUT 5 TYPE OUTPUT 6 TYPE EXTERNAL I/O DETECTION* EXTERNAL I/O CONFIG* List of Avalable IO10 Modules MODBUS ADDRESS ADDRESS BAUDRATE RS458 MODBUS STOP PARITY COMMUNICATION BAUDRATE DIGIBUS COMM* STOP PARITY DIGIWARE MODE* MODE ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 121 LOGICAL INPUT TYPE LOGICAL INPUT ACK METHOD LOGICAL ALARMS CONFIG INPUT TYPE ACK INPUT OUTPUT TYPE OUTPUT REPORT CRITICITY ALARM ID STATUS INPUT TYPE ACK METHOD SYSTEM ALARMS CONFIG ACK INPUT OUTPUT TYPE OUTPUT REPORT CRITICITY ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 122 ON DELAY TIMER 5 (s)* ON DELAY TIMER 6 (s)* ON DELAY TIMER 7 (s)* STATUS TRANSFER METHOD S1 CYCLER DURATION (h) CYCLER S2 CYCLER DURATION (h) TRANSFER TIME PRIO SELECTION COMMIT TO TRANSFER* COMMIT TO TRANSFER MAINTENANCE ATyS Controller C55/65 - 549866D - SOCOMEC...

  • Page 123: Annex 16 - 8. Communications Table

    FIRMWARE VERSION (no PWD) COMM ADDR MAINTENANCE TEL All the menus with "*" are only available for ATyS C65. Annex 16 - 8. Communications table Find your product Modbus communication registers online at : www.socomec.com ATyS Controller C55/65 - 549866D - SOCOMEC...
  • Page 124 CORPORATE HQ CONTACT: SOCOMEC SAS 1-4 RUE DE WESTHOUSE 67235 BENFELD, FRANCE www.socomec.com Non contractual document. © 2023, Socomec SAS. All rights reserved.
