INSTALLATION MANUAL
WALL MOUNTED INDOOR UNIT
SPLIT-STYLE AIR CONDITIONER
DRAW06F2A, DRAW09F2A, DRAW12F2A,
DRAW18F2A, DRAW24F2A, DRAW33F2A
R-454B 208/230V 1ph 60 HZ
Model Number:
Serial Number:
Purchase Date:
Installing Contractor Company Name:
TIP
Capture relevant information about your Durastar mini-split equipment before it is
installed and write it above for future reference.
R
DURASTAR.COM
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DURASTAR DRAW06F2A
Summary of Contents for DURASTAR DRAW06F2A
- Page 1 DRAW06F2A, DRAW09F2A, DRAW12F2A, DRAW18F2A, DRAW24F2A, DRAW33F2A R-454B 208/230V 1ph 60 HZ Model Number: Serial Number: Purchase Date: Installing Contractor Company Name: Capture relevant information about your Durastar mini-split equipment before it is installed and write it above for future reference. DURASTAR.COM...
-
Page 2: Table Of Contents
• Read the troubleshooting section of this manual as it will help you diagnose and solve common issues. • Visit us on the web at WWW.DURASTAR.COM to download product guides and up-to-date information. • If you need warranty service, our friendly customer service representatives are available via email at QUESTIONS@DURASTAR.COM or by telephone at 1-888-320-0706. -
Page 3: Symbols Used In This Manual
NOTE: The pencil indicates any manufacturer notes relating to surrounding content. These may include further clarifications or call-outs. TIP: A light bulb symbol indicates suggested manufacturer tips for the user to get the most out of the Durastar equipment and to accommodate the best user experience. R-454B WARNING:... -
Page 4: Important Safety Precautions
Do not operate your air conditioner in a wet room such as a bathroom or laundry room. Too much exposure to water can cause electrical components to short circuit. • If the air conditioner is used together with burners or other heating devices, thoroughly ventilate the room to avoid oxygen deficiency. DURASTAR.COM... -
Page 5: Electrical Safety
For units that have an auxiliary electric heater, do not install the unit within 3 feet (1 meter) of any combustible materials. • Do not install the unit in a location that may be exposed to combustible gas leaks. If combustible gas accumulates around the unit, it may cause a fire. DURASTAR.COM... - Page 6 When the refrigerant sensor malfunctions, the indoor unit will display the error code “FHCC”. The refrigerant sensor can not be repaired and can only be replaced by the manufacturer. It shall only be replaced with the sensor specified by the manufacturer. DURASTAR.COM...
- Page 7 All training shall follow the ANNEX HH requirements of UL 60335-2-40 4th Edition. Examples for such working procedures are: • breaking into the refrigerating circuit; • opening of sealed components; • opening of ventilated enclosures. DURASTAR.COM...
-
Page 8: Detection Of Flammable Refrigerants
NITROGEN when using flame to open circuit; and • open the circuit The refrigerant charge shall be recovered into the correct recovery cylinders if venting is not allowed by local and national codes. For appliances containing flammable refrigerants, the DURASTAR.COM... -
Page 9: Charging Procedures
Do not climb onto or place objects on top of the outdoor unit. • Do not allow the air conditioner to operate for long periods of time with doors or windows open, or if the humidity is very high. DURASTAR.COM... - Page 10 : the height of the bottom of the appliance relative to the floor of the room Definitions inst after installation ft (m) WARNING: The minimum room area or the minimum room area of conditioned space is based on releasable charge and total system refrigerant charge. DURASTAR.COM...
-
Page 11: Accessories
When the DRAW33F1B indoor unit is installed with a multi-zone outdoor unit, you must purchase refrigerant pipe with a liquid side size of Φ3/8in (Φ9.52mm) and a gas side size of Φ5/8in (Φ16mm). The refrigerant pipe adapter included with the indoor unit must be installed on the indoor unit. DURASTAR.COM... -
Page 12: Specification Overview
Wire crimper • Burr reamer SPECIFICATION OVERVIEW The table below includes basic specifications for this unit. For more detailed specifications please refer to the submittals on DURASTAR.COM. Durastar reserves the right to change specifications without notice. INDOOR UNIT DIMENSIONS LIQUID SUCTION... -
Page 13: Operating Temperatures
Regularly inspect and clean air filters. NOTE Your Durastar air conditioner's outdoor unit is equipped with a base pan heater, allowing it to continue to operate at freezing temperatures as low as -22°F (-30°C). When outdoor air temperatures are at or below 32°F (0°C), we strongly recommend keeping the unit plugged in at all times to ensure smooth ongoing performance. -
Page 14: Parts Identification
Front Panel Outdoor Unit Power Cable Signal Cable Air Flow Louver Refrigerant Piping Air Freshness (Carbon) Remote Controller Filter NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your mini- split equipment may vary slightly. DURASTAR.COM... -
Page 15: Installation Overview - Indoor Unit
INSTALLATION OVERVIEW - INDOOR UNIT 15cm (5.9in) 12cm 12cm (4.75in) (4.75in) 2.3m (90.55in) Attach Mounting Plate Select Installation Location Determine Wall Hole Position Drill Wall Hole Connect Piping Connect Wiring Wrap Piping and Cable Prepare Drain Pipe STEP Mount Indoor Unit DURASTAR.COM... -
Page 16: Indoor Unit Installation
STEP 2: ATTACH MOUNTING PLATE TO WALL 1. Remove the screw that attaches the mounting plate to the back of the indoor unit. The mounting plate is the bracket on which you will mount the indoor unit. Screw DURASTAR.COM... -
Page 17: Step 3: Drill Wall Hole For Connective Piping
5.1in (130mm) 15.75in (400mm) 5.24in (133mm) 4.13in 4.96in 3.8in (97mm) (105mm) (126mm) DRAW06F2A all hole for connecting piping Φ2.5in(65mm) 1.7in (45mm) Indoor unit dimensions(WxH): Φ3.54 Indoor unit d 32.9in(835mm)x11.65in(296mm) Φ2.5in(65mm) 42.6in (1082m... -
Page 18: Step 4: Prepare Refrigerant Piping
Connect the Drain Pipe. If there is no pre-existing piping, connect the indoor unit’s refrigerant piping to the connective piping that will join the indoor and outdoor units. Refer to the Refrigerant Piping Connections section of your outdoor unit's installation manual for detailed instructions. DURASTAR.COM... -
Page 19: Step 5: Connect The Drain Pipe
NOT CORRECT NOT CORRECT Do not place the end of the Kinks in the drain pipe drain pipe in water or in will create water traps. containers that collect water. This will prevent proper drainage. DURASTAR.COM... -
Page 20: Step 6: Connect Signal Cable
WARNING Before performing any electrical or wiring work, turn off the main power to the system. WARNING DO NOT MIX UP LIVE AND NULL WIRES This is dangerous, and can cause the air conditioning unit to malfunction. DURASTAR.COM... -
Page 21: Cable Sizing
9. Replace the wire cover on the front of the unit and the plastic panel on the back. WARNING All wiring must be performed strictly in accordance with the wiring diagram located on the back of the indoor unit's front panel. DURASTAR.COM... -
Page 22: Step 7: Prepare Refrigerant Piping
Leak Checks section of this manual). STEP 9: MOUNT INDOOR UNIT If you installed new connective piping to the outdoor unit, do the following: 1. If you have already passed the refrigerant piping through the hole in the wall, proceed to #4. DURASTAR.COM... - Page 23 If you find that you don’t have ample room to connect embedded pipes to the indoor unit, the unit can be adjusted left or right by about 1-1/4-2" (30- 50mm), depending on the model. 1-1/4 - 2” 1-1/4 - 2” (30-50mm) (30-50mm) Adjust left or right DURASTAR.COM...
-
Page 24: Troubleshooting
The indoor unit makes A rushing air sound may occur when the louver resets its position. noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts. DURASTAR.COM... - Page 25 • Press ON/OFF button on remote control to restart operation. NOTE If problem persists, contact a local dealer or your nearest customer service center. Provide them with a detailed description of the unit malfunction as well as your model number. DURASTAR.COM...
- Page 26 Incompressible gas or moisture has Evacuate and recharge the system with frequently entered the system. refrigerant. The compressor is broken. Replace the compressor. The voltage is too high or too low. Install a manostat to regulate the voltage. DURASTAR.COM...
- Page 27 If not, disconnect the power, then connect it again. Turn the unit on. If the problem persists, disconnect the power and contact your nearest customer service center. NOTE If your problem persists after performing the checks and diagnostics above, turn off your unit immediately and contact an authorized service center. DURASTAR.COM...
-
Page 28: Wiring Diagram
WIRING DIAGRAMS DRAW06F2A, DRAW09F2A, and DRAW12F2A DURASTAR.COM... - Page 29 DRAW18F2A, DRAW24F2A, and DRAW33F2A DURASTAR.COM...
-
Page 30: Error And Operating Codes
PC 01 ODU voltage protection PC 02 Compressor top (or IPM) temp. protection PC 03 Pressure protection(low or high pressure)(for some models) PC 04 Inverter compressor drive error PC 0L Low ambient temperature protection(for some models) ---- IDUs mode conflict(Multi-zone) DURASTAR.COM... - Page 31 When the unit detects a refrigerant leak, the indoor unit will operate in Turbo mode to mitigate refrigerant collecting in the unit. The minimum airflow of the indoor unit is as follows: MODEL NOMINAL AIR VOLUME DRAW06F2A 400m³/h 235CFM DRAW09F2A 500m³/h...
- Page 32 THIS PAGE INTENTIONALLY LEFT BLANK. ©2024 Durastar DURASTAR.COM V1.0 0924...
